INTRODUCTION • MANUAL USE MODES The section of this manual dedicated to the installation contains information for installers. For this reason we have used technical terms without providing explanations which would be necessary for end users only. THE INSTALLATION MUST BE CARRIED OUT BY AUTHORIZED AND SKILLED PERSONNEL ONLY. ARAG IS NOT RESPONSIBLE FOR ANY OPERATION SPECIFIED IN THIS MANUAL CARRIED OUT BY UNAUTHORIZED OR UNSKILLED PERSONNEL.
INSTALLATION PACKAGE CONTENT Control box complete with power cable. The connection cables must be ordered separately. INSTALLATION - Do NOT install the device in areas where it would be subjected to excessive vibrations or shocks, to prevent any damage or accidental use of the keys;...
INSTALLATION WIRING CONNECTIONS • Use original ARAG harnesses only. • Take care not to break, pull, tear or cut the cables. • Use of unsuitable cables not provided by ARAG automatically voids the warranty. • ARAG is not liable for any damage to the equipment, persons or animals caused by failure to observe the above instructions. General precautions for a correct harness position •...
INSTALLATION 7.2.1 Control unit valve connection Purchase the harness for connection and valve unit separately. Ref. ARAG General Catalog. CABLE CONNECTION MARKING 1 ÷ 7 Relevant section valve Proportional valve Main valve F - S - M - T - X DO NOT CONNECT Connector 1 shall control the valve which in turn is connected to the boom section 1, and so on with the other valves.
INSTALLATION 7.2.2 Hydraulic valve connection Purchase the harness for connection and hydraulic unit separately. Ref. ARAG General Catalog. CONNECTOR CONTROL 1 ÷ 4 A Section movement 1 - 2 - 3 - 4 1 ÷ 4 C Boom height Boom lock Boom leveling Pilot valve Fig.
INSTALLATION / USE 7.2.3 Power supply connection CAUTION: TO AVOID SHORT CIRCUITS, DO NOT CONNECT THE POWER CABLES TO BATTERY BEFORE THE INSTALLATION IS COMPLETED. BEFORE POWERING UP THE SYSTEM, MAKE SURE THE TRACTOR BATTERY VOLTAGE IS AS SPECIFIED (12 VDC). The power source must be connected as indicated in Fig.
MAINTENANCE / DIAGNOSTICS / REPAIRS MAINTENANCE / DIAGNOSTICS / REPAIRS • Clean only with a soft wet cloth. • Do not use aggressive detergents or products. • Do not clean equipment with direct water jets. Troubleshooting CONTROL INVOLVED PROBLEM CAUSE SOLUTION LEDs turn on, but the relevant valves Connectors disconnected.
TECHNICAL DATA 10.5 Connector pin-out Fig. 10 Fig. 11 WATER POWER SUPPLY Signal Signal Signal Main valve Black GND power supply 12 V valve power supply (G, 1, 2, 3) +12V power supply Section valve 6 Section valve 1 Section valve 7 Section valve 4 Proportional valve (1) Proportional valve (2)
END - OF - LIFE DISPOSAL Dispose of the system in compliance with the established legislation in the country of use. GUARANTEE TERMS 1. ARAG s.r.l. guarantees this apparatus for a period of 360 days (1 year) from the date of sale to the client user (date of the goods delivery note).
Page 12
Only use genuine ARAG accessories or spare parts to make sure manufacturer guaranteed safety conditions are maintained in time. Always refer to the Internet address www.aragnet.com 42048 RUBIERA (Reggio Emilia) - ITALY Via Palladio, 5/A Tel. +39 0522 622011 Fax +39 0522 628944 http://www.aragnet.com info@aragnet.com...
