  • Page 1 Bedienungsanleitung (S. 2) Operating manual (p. 30) Funk-Fernbedienung 8 Tasten Remote Control 8 buttons HM-RC-8...
  • Page 2 Lieferumfang Inhaltsverzeichn Anzahl Artikel HomeMatic Funk-Fernbedienung 8 Tasten 1,5 V LR03/Micro/AAA Batterien Bedienungsanleitung 1. Ausgabe Deutsch 06/2014 Dokumentation © 2014 eQ-3 Ltd. Hong Kong Alle Rechte vorbehalten. Ohne schriftliche Zustimmung des Herausgebers darf dieses Handbuch auch nicht auszugsweise in irgendeiner Form repro- duziert werden oder unter Verwendung elektronischer, mechanischer oder chemischer Verfahren vervielfältigt oder verarbeitet werden.
  • Page 3: Hinweise Zu Dieser Anleitung

    Hinweise zu dieser Anleitung Hinweise zu dieser Anleitung Lesen Sie diese Anleitung sorgfältig, bevor Sie Ihre HomeMatic Komponenten in Betrieb nehmen. Bewah- ren Sie die Anleitung zum späteren Nachschlagen auf! Wenn Sie das Gerät anderen Personen zur Nutzung überlassen, übergeben Sie auch diese Bedienungsan- leitung.
  • Page 4: Allgemeine Systeminformation Zu Homematic

    Allgemeine Systeminformation zu HomeMatic Allgemeine Systeminformation zu HomeMatic Dieses Gerät ist Teil des HomeMatic Haussteuersy- ® stems und arbeitet mit dem bidirektionalen BidCoS Funkprotokoll. Alle Geräte werden mit einer Stan- dardkonguration ausgeliefert. Darüber hinaus ist die Funktion des Gerätes über ein Programmiergerät und Softwarekongurierbar.WelcherweitergehendeFunk-...
  • Page 5 Funktion und Geräteübersicht Inbetriebnahm Bedienelemente: A – Tastenpaar 1 B – Tastenpaar 2 C – Tastenpaar 3 D – Tastenpaar 4 E – Geräte-LED F – Entriegelungstaste G – Anlerntaste H – Batteriefach...
  • Page 6 Inbetriebnahme • Legen Sie zwei Batterien vom Typ LR03/Micro/ AAA polrichtig entsprechend den Polaritätsmarkie- rungen in das Batteriefach ein. • Schließen Sie das Batteriefach wieder, indem Sie die Abdeckung auegen und mit leichtem Druck wieder Richtung Gehäuseende schieben, bis sie einrastet.
  • Page 7 Inbetriebnahme 5.2.1 Direktes Anlernen an HomeMatic Geräte Wenn Sie die Fernbedienung an ein oder mehrere HomeMatic Geräte anlernen möchten, müssen Sie die beiden zu verknüpfenden Geräte in den Anlernmodus bringen und die gewünschte Taste bzw. den Kanal zum Anlernen auswählen.
  • Page 8 • steuernundkongurieren, • direkt mit anderen Geräten verknüpfen oder • in Zentralenprogrammen nutzen zu können, muss es zunächst an die HomeMatic Zentrale angelernt werden. Das Anlernen neuer Geräte an die Zentrale er- folgtüberdieHomeMaticBedienoberäche„WebUI“. Sobald eine Komponente an eine Zentrale an- gelernt ist, kann sie nur noch über diese mit an-...
  • Page 9 Inbetriebnahme • Versetzen Sie innerhalb dieser Anlernzeit die Fern- bedienungindenKongurationsmodus,indemSie die Abdeckung abnehmen und kurz mit einem spit- zen Gegenstand auf die Anlerntaste ( ) der Fern bedienung drücken. • DieFernbedienung bendetsich nun imKongu- rationsmodus. Dies wird durch grünes Blinken der Geräte-LED angezeigt.
  • Page 10: Bedienung

    Bedienung Fehler- und Rüc Bedienung Die 8 Tasten sind im Auslieferungszustand als vier se- parate Tastenpaare (TP 1, TP 2, TP 3 TP 4) de- niert. Dabei hat die jeweils rechte Taste die Funktion „An/Heller/Hoch“ und die linke Taste „Aus/Dunkler/Run- ter“.
  • Page 11 Fehler- und Rückmeldungen durch die Geräte-LED Fehler- und Rüc Fehlermeldungen Blinkcode Bedeutung Lösung 5 x kurzes Batterien fast leer Tauschen Sie die rotes Blinken Batterie aus (siehe „5.1.2 Batte- rien wechseln“ auf Seite 10). 1 x langes, 2 Die Fernbedie- Bitte wenden x kurzes rotes nung ist defekt.
  • Page 12: Schwache Batterien

    Langsames Fernbedienung Siehe „5.2.1 Di- grünes Blinkes bereits an Zentrale rektes Anlernen an und bei Ta- angelernt und HomeMatic Geräte“ stenbetätigung damit für direktes auf Seite 12. rotes Leuchten Anlernen gesperrt. Langsames Vorstufe zum Gerät wartet auf rotes Blinken Zurücksetzen auf...
  • Page 13: Werkseinstellungen Wiederherstellen

    Werkseinstellungen wiederherstellen Geräte dürfen bei Erreichen des 1 %-Limits nicht mehr senden, bis diese zeitliche Begrenzung vorüber ist. Ge- mäß dieser Richtlinie, werden HomeMatic-Geräte zu 100 % normenkonform entwickelt und produziert. Im normalen Betrieb wird der Duty Cycle in der Regel nicht erreicht.
  • Page 14: Wartung Und Reinigung

    Wartung und Reinigung Allg 10 Allgemeine H teriewechsel“ auf Seite 11) ist der Fernbedienung zurückgesetzt und einsatzbereit. Mögliche Fehlermeldungen: Der nachfolgende Fehler kann nur auftreten, wenn Sie die Fernbedienung an eine Zentrale angelernt haben. Beginnt die LED nach 5 Sekunden Gedrückthalten nicht zu blinken, sondern leuchtet dauerhaft auf, kann die Fernbedienung nicht zurückgesetzt werden, da sie an die Zentrale angelernt ist.
  • Page 15: Technische Daten

    Technische Daten 11 Technische Daten Geräte-Kurzbezeichnung: HM-RC-8 Versorgungsspannung: 2x 1,5 V LR03/Micro/AAA Stromaufnahme: 40 mA max. Batterielebensdauer: > 5 Jahre (bei ca. 10 Betätigungen am Tag) Schutzart: IP20 Umgebungstemperatur: 5 bis 35 °C Funkfrequenz: 868,3 MHz Typ. Funk-Freifeldreich- weite: > 100 m Empfängerkategorie:...
  • Page 16: Scope Of Delivery

    Scope of delivery Table of contents Quantity Item HomeMatic Remote Control 8 buttons 1.5 V LR03/micro/AAA batteries Operating manual 1st English edition 06/2014 Documentation © 2014 eQ-3 Ltd., Hong Kong All rights reserved. Translation of the original version in German. This manu-...
  • Page 17: Information About This Manual

    Information about this manual Read this manual carefully before beginning operation with your HomeMatic components. Keep the manual so you can refer to it at a later date if you need to. If you hand over the device to other persons for use, please hand over the operating manual as well.
  • Page 18: Function And Device Overview

    Unit. Thus, lights can be switched on and off and shutters can be moved up or down. You can individually denethefunctionsofalleightbuttons.Asinglebutton can be taught-in to work with one or more HomeMatic components. At the push of a button, several functions can be executed simultaneously.
  • Page 19: Inserting And Replacing Batteries

    Start-up Start-up 5.1 Inserting and replacing batteries 5.1.1 Inserting batteries To start up the device, please insert the batteries. To do this, proceed as follows: • Open the battery compartment on the rear (H) by pressingthereleasebutton(F)withyounger(1.) and moving the cover of the remote control to the back (2.).
  • Page 20: Instructions For Disposal

    Please read this entire section before starting the teach-in procedure! To integrate the remote control into your HomeMatic system and enable it to communicate with other Home- Maticdevices,youmustteachitinrst.Youcanteach- in the remote control directly to other HomeMatic de- vices or to the HomeMatic Central Control Unit.
  • Page 21 Start-up • The remote control is now in conguration mode. ThedeviceLEDashesgreentoindicatethis.(To exit conguration mode, briey press the teach-in button again.) • To enter teach-in mode, press the remote control button in to which you wish to teach a function. The device...
  • Page 22 Start-up During teach-in, please make sure you maintain a distance of at least 50 cm between the devic- es and the central control unit. To teach-in your device to the central control unit, pro- ceed as follows: • Open the "WebUI" user interface in your browser. Click the "Teach in devices"...
  • Page 23: Operation

    • Now congure the newly taught-in devices in the inboxasdescribedinthenextsection("Conguring newly taught-in devices"). 5.3  C onguringnewlytaught-indevices Once you have taught-in your device to the HomeMatic Central Control Unit, it is moved to the inbox. Here, you mustcongurethedeviceanditsassociatedchannels in order to make them available for operating and con- guration...
  • Page 24: Errors And Information Indica - Ted By The Device Led

    Errors and information indicated by the device LED Errors and infor Shutters raised Light off Errors and information indica ted by the device LED 7.1 Flashing codes and error messages This information applies to operation with and without a central control unit.
  • Page 25 Errors and information indicated by the device LED Errors and infor 1 s lighting up All actuators You can continue green haveconrmed with operation. the (most recent) bidirectional com- mand. 2 s lighting At least one Please try again. up red actuator has not conrmedthe...
  • Page 26 Errors and information indicated by the device LED the battery has been allowed a brief recovery period. If you are using weak batteries, the device may perform a restart automatically when you press a button. The deviceLEDthenbrieyashesred,greenandorange, andfollowthiswith5briefredashestoindicatethat the batteries are weak. 7.3 Commandnotconrmed If a receiver (at least one in cases where multiple de- vices...
  • Page 27 Restore factory settings > 5 s • To restore the factory settings of the device, press andholdtheteach-inbuttonforatleastanotherve seconds. With the button pressed, the LED starts to ashredfaster. • When you release the teach-in button, the reset process is completed. • TheredLEDstopsashingandtheremotecontrol performs a restart.
  • Page 28 General information about radio operation 10 General information about radio 11 Technicalspe operation Radio transmission is performed on a non-exclusive transmission path, which means that there is a pos- sibility of interference occurring. Interference can also be caused by switching operations, electrical motors or defective electrical devices.
  • Page 29 eQ-3 Entwicklung GmbH Maiburger Straße 36 D-26789 Leer www.eQ-3.de...
