INSTRUCTION MANUAL

800 size BO-105

KIT

Item No.: RCH-BO105xx8

October 2023

Version 1.01

Roban Model

Table of Contents

Need help?

Do you have a question about the BO-105 and is the answer not in the manual?

Questions and answers

Summary of Contents for Roban BO-105

Page 2 DISCLAIMER All instructions, warranties and other collateral documents are subject to change at the sole discretion of Roban Model Limited. For up-to-date product literature, visit robanmodel.com and click on the support or tab for this product. Copyright © 2023 by Roban Model Limited All rights reserved.
Page 3: Table Of Contents
Contents PREFACE ............................. 5 1.1 ..Warning ............................. 5 1.2 ..Flight Safety Advisory ......................... 5 Description of the product ......................6 2.1 ..Purpose of the product ....................... 6 2.2 ..Technical data ..........................6 2.3 ..Product Compliance ........................7 2.4 ..
Page 4 4.6 ..Adjustment of center or gravity ....................36 Operation/Use ......................... 37 5.1 ..How to fly ..........................37 5.2 ..What to do in emergency and exceptional situations ............. 37 5.2.1 Emergency situation ..........................37 Maintenance and cleaning ....................... 38 6.1 ..
Page 5: Preface
1.2 Flight Safety Advisory Roban Model is dedicated to providing its users with a secure and enjoyable flying experience. A comprehensive understanding of flight safety is imperative for safeguarding both personal and environmental safety.
Page 6: Description Of The Product
2 Description of the product 2.1 Purpose of the product The Roban Model Limited remote controlled scale helicopter is a sophisticated hobby product designed for use by experienced hobbyists. The helicopter features a CCPM scale mechanic that requires in-depth knowledge to operate.
Page 7: Product Compliance
EU Compliance Statement: 800 size BO-105 (BO105-8); Hereby, Roban Model Limited declares that the device is in compliance with the following: EU Low Voltage Directive 2014/35/EU, EU EMC Directive 2014/30/EU , RoHS 2 Directive 2011/65/EU, RoHS 3 Directive -Amending 2011/65/EU Annex II 2015/863 WEEE NOTICE: This appliance is labeled in accordance with European Directive 2012/19/EU concerning waste of electrical and electronic equipment (WEEE).
Page 8: Product Components / Contents
31 – Ball link M2 x4 32 – Nut M2 x4 33 – Screw M2x8 x6 34 – Wooden washer x6 35 – Screw M3x25 x4 36 – Ball link x4 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 10: Additional Components Required
Cyanoacrylate adhesive, Epoxied adhesive  Pitch Gauge (for set-up)  Soldering equipment, bullet plugs, and heat shrink tubes (for motor wiring)  Double sided foam tape, cable zip ties, sticky velcro straps Copyright © 2023 Roban Model Limited: all rights reserved.
Page 11: Packaging Groups
4 Scale parts, cockpit, tail wings, accessories 5 Mechanics, rotor head, accesories 6 Fenestron unit, preassembled Fig. 2 Box contents 7 Main blades, tail boom and tail shafts Table 2 Box contents Copyright © 2023 Roban Model Limited: all rights reserved.
Page 12: Safety Instructions
• Always keep parts dry. • Always let parts cool after use before touching. • Always remove batteries after use. • Never operate aircraft with damaged wiring. • Never touch moving parts. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 13: Preparation
1. Don’t store above 50°C/120°F 2. Don’t store lithium batteries above 60°C/140°F or below 0°C/32°F 3. Don’t store with exposure to sunlight. 4. Don’t store under humid conditions of 60%RH or above over prolonged periods. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 14: How To Install The Product
The front section is secured by magnets and two screws, which hold it in place. Please unscrew all of them, then remove the front section carefully and place them on a soft cloth to prevent any damage. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 15 Next, utilize the four screws (35) and washers (27) to fasten and secure the landing gear in place, on both sides in the back and in the front locations. Please exercise caution and avoid overtightening the screws. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 16 Installation of the tail fins and light equipment Connect the red LED (53) with the 90mm (54) and 60mm extension cable (56) as shown and glue it into the tail fin. Glue the cap (55) on. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 17 Once the socket's glue has settled, secure the scale part (39) of the LED with glue as well. Then connect each of them with a 90mm extension cable (54). Copyright © 2023 Roban Model Limited: all rights reserved.
Page 18 It's important to take care with this step, as a poorly adjusted model will look unattractive. When satisfied with the placement, apply sufficient glue to both insets and attach the stabilizers securely to the boom. Ensure a strong bond is achieved. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 19 Start by connecting the prolonging wire (56) to the instrument panel (47) as shown. Then route through the floorboard and glue the center panel in as shown. Then glue the center console (48) onto floorboard as shown. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 20 Next, proceed to install the front seats (49) according to the cutouts on the floorboard, securing them with epoxide glue. Next, proceed to install the back seats (50) according to the cutouts on the floorboard, securing them with epoxide glue. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 21: Assembly Of The Mechanics
Ensure that the distance between the ball link and the L lever is 24mm on all sides. Finally, attach the ball links (70-00025) onto the swashplate's upper disc uni-links (70-00030) by snapping them in place. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 22 Then, insert the tail boom into the tail boom holders (1-70-ZZ-00002, 1-JJ-70-00094). Secure the tube in place with screw M3x8 via the clamp up and additionally with screw M3x6 as shown. Finally, attach the carbon support beams (70-00104-70-00106) onto the main frame and the tail boom clamp (600UH1-007). Copyright © 2023 Roban Model Limited: all rights reserved.
Page 23: Tail Servo Installation
M3x10, washers, and nylon nuts to install the tail servo of your choice into the tail frame as indicated. Be sure to install the servo horn (metal horns only!) and the included uniball. Next, slide the tail rotor control rod (70-00103) Copyright © 2023 Roban Model Limited: all rights reserved.
Page 24: Cyclic Servo Installation
Once the servos are in place, you will need to adjust the length of the linkage rods according to the provided schematics. The distance between the uniball centers should be adjusted to precisely 96mm to ensure optimal performance. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 26: Adjust Swashplate Linkages
To ensure proper functionality, it is important to adjust the linkages from the L-Levers to the swash plate at the correct length. The distance between the uniball centers should be set to 35mm all three levers. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 27: Motor And Belt Installations
Then tighten all four screws of the violet motor holder. Then tighten the 4 screws that hold the top motor shaft bearing block. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 28 Use both tensioning screws to adjust the belt drive tension. The belt should not be too tight to avoid unnecessary wear. After installing the motor, reassemble the side frames. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 29: Installation Of Electric Components And Wiring
The swash plate is a regular 120deg CCPM type. Take the time to adjust all servo travels, center positions, and the entire 3 axis gyro-servo-radio setup before installing it into the fuselage. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 30: Attention When Commissioning / Testing The Equipment
1m altitude, until you are confident that there are no defects or errors, and that everything is working correctly. Use your ears to listen for any unusual sounds or vibrations and investigate any issues immediately. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 31: Installation Into The Scale Fuselage
To properly install the mechanics, start by removing the tail entirely. Next, insert the fuselage according to the diagram provided. Use the screws (M3x16 socket) and washers (M3) as shown to secure the mechanics in place. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 32: Mounting The Tail Fuselage
Then connect the linkages on the tail gearbox so that the servo controls the tail rotor pitch again. Close the tail hatch with the screws. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 33: Routing The Electrical Wires
Assemble the front fuselage and secure it with the screws. These screws always have to be installed before you start to fly. The front section will fall off in flight if these screws aren’t installed, and the helicopter will sustain damage. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 34 Ensure that the mounting holes on the parts align with the pre-drilled holes on the aircraft.  Press each part firmly onto the surface to secure it in place.  Wait until the glue has fully cured before proceeding with any further installation steps. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 35 After all scale parts are installed, proceed to applying the water slide decals in the correct positions. We will not go into detail on how to apply water decals in this manual, please check YouTube, there are many great how to instructions for static models available. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 36: Adjustment Of Center Or Gravity
If the battery is particularly heavy or of an unusual size, it may be necessary to add trim weights to achieve the correct forward center of gravity. These weights can be added to the nose section below the cockpit panel. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 37: Operation/Use
Do not take any unnecessary risks and prioritize safety above all else. Remember to always follow local regulations and guidelines for emergency situations, and seek professional assistance if needed. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 38: Maintenance And Cleaning
Periodically check the receiver and transmitter antennas for damage. Replace them if necessary. By following these maintenance and cleaning guidelines, you can ensure that your scale radio controlled helicopter stays in top condition and performs at its best. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 39: Troubleshooting And Repair
Check the blades, rotor head, and other components for any loose or damaged parts. Clean the helicopter with a soft cloth and mild detergent. Avoid using water or any other liquid as it may damage the electronics. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 40: Repairs
If you are unsure about any repairs, seek the advice of a qualified technician. Remember that the safety of yourself and others is the top priority when operating a scale helicopter. Always follow the manufacturer's instructions and guidelines and take appropriate safety measures. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 41: Disposal
By following these guidelines, you can help protect the environment and ensure the safe disposal of your scale radio controlled helicopter. Copyright © 2023 Roban Model Limited: all rights reserved.
Page 50: Appendix B Mechanic Replacement Parts
Upper base plate plate Bearing 6901RS 24*12*6 轴承 RCH-70-005 Bearing L-1910ZZ 19*10*5 轴承 M2.5*12 杯头 M2.5x12 socket 螺丝 M2.5 防松螺母 M2.5 nyloc nut Lower base RCH-70-006 1-JJ-70-00071 Lower base plate 机架下支撑板 plate Copyright © 2023 Roban Model Limited: all rights reserved.
Page 51 78T 斜齿轮 gear 78T Helical pinion Helical pinion gear 1-70-JJ-3002 20T 斜齿轮 gear 20T RCH-70-U003 M4*4 机米 M4x4 set hex RCH-70-011-CCW all models, except Belt pulley set 1-JJ-70-00075 Washer 10x12x0.5 垫片 RCH-70-011-CW Copyright © 2023 Roban Model Limited: all rights reserved.
Page 52 Gear 1M 32T 1-JJ-70-00082-1 Gear 1M 32T 动齿轮 40T 过渡尾传 RCH-70-013-40 Gear 1M 40T 1-JJ-70-00082-2 Gear 1M 40T 动齿轮过渡尾传动 Gear holder RCH-70-014-30 1-JJ-70-00083 Gear holder 30T32T 齿轮铝件 2 30T & 32T 30T32T Copyright © 2023 Roban Model Limited: all rights reserved.
Page 53 M4x4 set hex M3*6 半圆头 Swash drive M3x6 round hex 螺丝 M2.5*12 半圆 M2.5x12 round hex 头螺丝 RCH-70-016 1-JJ-70-00037 Ball link 5mm 升降球头扣升降摇臂 1 1-JJ-70-00038 U-Lever 法兰轴承 Flanged bearing 1-JJ-70-00039 F683ZZ 3x7x3 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 54 黑鹰，休斯，阿帕奇，贝尔 RCH-70-019-V2 Main Shaft 1-JJ-70-00033 Main Shaft 12mm all other models 12mm 贝尔 429， 407, 松鼠,130/135 RCH-70-020 Shaft 10x76.1 1-JJ-70-00057 2ND stage shaft 过渡减速轴 Swash Plate RCH-70-021-2B-V2 2 桨十字盘 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 55 M4 nyloc nut 13*8*7 橡胶圈 1-JJ-70-00168-7 Rubber grommet Rotorhead V2 版 3 桨中联 1-1T-XY-0004 center hub 3B M4*25 杯头半 M4x25 socket half RCH-70-022 -3B-V2 thread 牙螺丝 M3*12 杯头螺 M3x12 socket 丝 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 56 14*3 插销 3MM 不锈钢钻 3MM tungsten carbide drill 头 Rotorhead 1-1T-XY-0004 V2 版 5 桨中联 center hub 5B M4*25 杯头半 M4x25 socket half RCH-70-022 -5B-V2 thread 牙螺丝 M3*12 杯头螺 M3x12 socket 丝 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 57 L Lever set Washer 5x7x0.1 5*7*0.1 垫片 3.2*5*0.5 垫片 Washer 3.2x5x0.5 RCH-70-025-LLL 滚珠轴承 BE429, UH60, AS350, Bearing 3x7x3 MD500, AH-6, OH-6 one set only 3*4.5*1.1 垫片 1-JJ-70-00022 Washer 3x4.5x1.1 1-JJ-70-00023 L-Lever 大桨夹摇臂 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 58 拉杆 RCH-70-025-KNL 1-JJ-70-00025 Ball link frames 球头扣 Ball link set 球头扣 RCH-70-026 1-JJ-70-00025 Ball Link frame set 11*4*1.5 铜垫 Washer set Washer 11x4x1.5 片 RCH-70-027V2 11.5*8*1.3 铜 Washer 11.5x8x1.3 垫片 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 59 Aft Tail boom holder holder 夹座 M3*6 半圆头 M3x6 round hex 螺丝 RCH-70-034 M3*8 杯头螺 M3x8 socket 丝 M3*10 杯头螺 M3x10 socket 丝 Servo holder RCH-70-035 1-JJ-70-00064 Servo holder fwd 舵机固定件 1 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 60 承座 5*10*4 滚珠轴 RCH-70-037 Bearing MR105ZZ 承 M3*8 杯头螺 M3x8 socket 丝 Tail shaft 过渡尾传动轴 RCH-70-038-222/407 1-80-22-00001 Tail Shaft Set 5x73.5 Tail shaft 过渡尾传动轴 RCH-70-038-AH64 1-70-AP-00021 Tail Shaft Set 5x122 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 61 过渡尾传动轴 Tail shaft 5x52 1-80-GZ-00001 Tail Shaft Set MD/429/105 Fwd tail bevel 1-JJ-70-00094 Tail boom holder aft 1-JJ-ZZ-00002 Tail boom holder fwd RCH-70-039V2 1-JJ-ZZ-00001 Tail bearing holder 1-JJ-ZZ-00005 Tail bearing distancer Copyright © 2023 Roban Model Limited: all rights reserved.
Page 62 Tail gear 4 尾伞齿轮 4 尾伞齿轮 3 1-60-WJ-00003 Tail gear 3 Aft tail bevel 1-60-WJ-00004 Tail frame gear 尾伞齿轮 4 M4*4 机米螺 RCH-70-039G M4x4 set hex 丝 1-60-WJ-00003 Tail frame gear 尾伞齿轮 3 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 63 尾传动轴轴承套 12-02-02006 Bearing holder RCH-70-041 轴承 8x14x4 1-55-70-00015 Bearing MR148ZZ 600C 尾转折 11-600jRCH-70- X Connector 传动轴铝件 Tail servo 1-JJ-70-00097 Tail servo frame 尾舵机固定板 holder RCH-70-042 尾舵机固定环 1-JJ-70-00098 Tail servo clamp Copyright © 2023 Roban Model Limited: all rights reserved.
Page 64 Tail support 尾支撑铝接头 1-JJ-70-00104 Tail support holder 尾支撑插销 RCH-70-045 1-JJ-70-00105 Bolt 1.5x7.8 尾支撑碳纤维 Tail support 1-JJ-70-00106 Tail support rod 棒 Tail support Tail boom RCH-70-046 11-600UH1-007 Tail support clamp clamp clamp Copyright © 2023 Roban Model Limited: all rights reserved.
Page 65 Pitch slider 1-JJ-70-00113 Pitch sleeve 尾推组件 2 垫片 RCH-70-050 1-JJ-70-00122 Washer 7x8.5x4 M2*10 杯头内 M2x10 socket half 1-JJ-70-00131 thread 六角半牙螺丝 7*11*3 滚珠轴 1-JJ-70-00100 Bearing MR117ZZ 承 1-JJ-70-00048 Ball link 5mm 球头 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 66 Tail lever set 1-JJ-70-00114 Washer 3x4x0.5 1-JJ-70-00115 和 L-Lever 1 号尾 L 摇臂 1-JJ-70-00115-1 3*6*2.5 滚珠 Bearing MR63ZZ 轴承 RCH-70-053-1 1-JJ-70-00068 Uniball 5mm 球头 3*4*6 铜套 Sleeve 3x4x6 M2 nyloc nut M2 螺母 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 67 Frame Spacer 尾侧板固定柱尾测板 1 Tail frame 1 1-JJ-70-00117 Tail Frame 1 尾 L 摇臂支撑 1-JJ-70-00123 Pitch lever support 件 RCH-70-055 M2*5 杯头内 M2x5 socket 六角螺丝 5*10*4 滚珠轴 Bearing MR105ZZ 承 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 68 M3x6 round hex 内六角螺丝 3MGT 皮带 RCH-70-060 Main Belt 1-JJ-70-00146 Main Belt 杯头内六角螺 M3x17 socket half RCH-70-061 Screw M3x17 1-JJ-70-00002 thread 丝杯头内六角螺 Screw M4x26- M4x26 socket half RCH-70-066 1-JJ-70-00010 thread 丝 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 69 板牙杯头内六角螺 M2x14 socket half 丝 RCH-70-067 Screw M2x14 1-JJ-70-00140 thread 板牙推力轴承 Tail grip Thrust Bearing F6- RCH-70-068 1-JJ-70-00013 bearing 6x14x5 滚珠轴承 Tail boom RCH-70-069 1-JJ-70-00015 Bearing MR148ZZ bearing 8*14*4 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 70 1-JJ-70-00055 Bearing 6901-2RS 12x24x6 滚珠轴承 RCH-70-074 Bearing set 3 1-JJ-70-00056 Bearing 6800-ZZ 10x19x5 滚珠轴承 RCH-70-080 Bearing set 4 1-JJ-70-00100 Bearing MR117ZZ 7x11x3 滚珠轴承 RCH-70-081 Bearing set 5 1-JJ-70-00101 Bearing MR63ZZ 3x6x2.5 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 71 Uniball 5mm Pitch lever set 4 桨尾推 1-JJ-70-00143 Pitch lever 4 blade 尾推组件 1 1-JJ-70-00112 Pitch slider 尾推组件 2 RCH-70-094 1-JJ-70-00113 Pitch sleeve 1-JJ-70-00122 Washer 7x8.5x4 垫片球头 1-JJ-70-00048 Ball link 5mm Copyright © 2023 Roban Model Limited: all rights reserved.
Page 72 1-JJ-70-00100 Bearing MR117ZZ 承 Tail shaft set 1-JJ-70-00145 Tail shaft 3/4 blade 3-4 桨尾轴 3-4B 垫片 RCH-70-096 1-60-WJ-00010 Washer 5x7x5.7 1-60-WJ-00011 Washer 5x7x2.1 垫片 Washer RCH-70-097 1-60-WJ-00015 Washer 12x18x0.1 垫片 12x18x0.1 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 73 1-JJ-70-00091 Bearing MR6701-2RS 12x18x4 12x18x4 Tail rotor gear 尾伞齿轮 4 1-60-WJ-00004 Tail frame gear M4*4 机米螺 M4x4 set hex 丝 RCH-70-105 尾旋翼伞齿轮 1-60-WJ-00002 Tail frame gear 12*15*0.1 垫 Washer 12x15x0.1 片 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 74 M3*3 机米螺 M3x3 set hex 丝 RCH-70-110-V2 M2*14 杯头半 M2x14 socket half thread 牙螺丝 M2 nyloc nut M2 防松螺母 2B tethering 2 桨头横轴 Tethering shaft shaft RCH-70-120 4*11*1.5 铜垫 Washer 4x11x1.5 片 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 75 RCH-70-TRH-2V2 Tail rotor 2B 3 桨尾旋翼 RCH-70-TRH-3V2 Tail rotor 3B RCH-70-TRH-4V2 Tail rotor 4B 4 桨尾旋翼 MD500/407/AW/412/ 2nd stage RCH-70-LRPM36T UH1D/BO105/AH1/22 gear 30/36 2/225/AS350 2nd stage 429/UH60/AH64/EC- RCH-70-LRPM40T gear 40/32 145T1 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 76 RCH-70-RH12-4V2 blades(12mm) （金属桨夹） , V2 version 12mm 4 桨旋翼头 Rotor head 4 RCH-70-RH10-4V2 blades(10mm) （金属桨夹） , V2 version 12mm 5 桨旋翼头 Rotor head 4 RCH-70-RH12-5V2 blades(12mm) （金属桨夹） , V2 version 12mm Copyright © 2023 Roban Model Limited: all rights reserved.
Page 77 Bearing 6001-ZZ 28*12*8 轴承 Motor shaft 马达固定件 RCH70-SS support 套 9pc ec-135 涵道桨 RBN-70-058-EC135 Tail Blade Tail pushrod 拉杆/碳纤棒/ RBN-70-e5-SET-1 incl. guide, 固定件组 carbon fiber Fenestron Scale Clamp RBN-70-e5-SET-4 PU 件凹 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 78 1-70-e5-00033 Bevel gear 1-70-E5-00033 gear M4*4 机米螺 M4x4 set hex 丝 RBN-70-e5-SET-5 尾旋翼伞齿轮 1-60-WJ-00002 Bevel gear 12*15*01 垫片 Washer 12x15x0.1 Fenestron 1-70-e5-00013 pitch unit 1-70-e5-00014 1-70-e5-00019 RBN-70-e5-SET-6 1-70-e5-00007 1-70-e5-00015 1-70-e5-00010 1-70-e5-00017 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 79 M2x5 CS screw 丝 7*11*3 滚珠轴 Bearing 7x11x3 Bearing MR117ZZ 承 RBN-70-e5-00006V2 1-70-e5-00006V2 涵道中联涵道桨夹组 1-70e5-00024 Tail blade grip 6*10*2.5 滚珠 Bearing 轴承 RBN-70-e5-SET-7 6*10*3 滚珠轴 Bearing 承 C-Clip 6mm 6MM 弹簧介子 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 80 BELT 255T Belt 255T 6MM 宽度各 Door handle RBN-DH4S Door handle 门把手组 set 4pcs M2 反爪牙螺 Tail boom nut M2 wooden nut 母 RBN-EM6S M2*8 半圆头 M2x8 round hex 内六角螺丝 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 81 摇臂 2 1-JX-70-18005 Lever 2 RBN-HWU-800 1-JX-70-18006 Lever 3 摇臂 3 摇臂 4 1-JX-70-18007 Lever 4 1-JX-70-18008 Washer 5x7x1.2 垫片 5*7*1,2 不锈钢轴 1-JX-70-18009 Pitch shaft 2.3 拉杆 1-JX-70-18010 Push rod 78mm 78MM Copyright © 2023 Roban Model Limited: all rights reserved.
Page 82 4 桨长轴桨夹 Blade grip 1-JJ-70-00009-2-1 Lever lever 3/4/5B 摇臂 RBN-KHSM-BHA M2.5*5 杯头螺 M2.5x5 socket 丝 2 桨长轴桨夹 Blade grip Lever incl ball link lever 2B 摇臂 M2.5*5 杯头螺 M2.5x5 socket 丝 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 83 150 degree 700AH64 全金 metal tail RCH-70-WBX-AH64 gearbox for 属尾波箱 AH-64 Metal tail 700AH64 尾波 RCH-70-WBX01- gearbox gear AH64 箱扇齿 set for AH-64 600 轴传通用 600 tail 600WBX gearbox nylon 尾波箱 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 84 500WBX gearbox nylon 尾波箱 500 轴传通用 500 tail 短尾管+轴+拉 500WBX01 gearbox short boom set 杆 500 tail 500 轴传通用 500WBX02 geabox gear 扇齿 500 tail 500 轴传通用 500WBX03 geabox gear 扇齿 Copyright © 2023 Roban Model Limited: all rights reserved.
Page 85: Appendix C Scale Replacement Parts
Appendix C scale replacement parts 800 BO-105 landing RCH-70-003-BO105 800BO105 脚架组 gear set RCH-70-004-BO105 800BO105 脚踏 800 BO-105 foot rest 800 BO-105 base RCH-70-006-BO105 800BO105 主支撑板 plate 800 BO-105 motor RCH-70-007-BO105 600BO105 皮带调机器 shaft mount RCH-70-007-1- 800 BO-105 motor 600BO105 马达固定座...
Page 86 800 BO-105 decal set RCH-70-130-BO105 800BO105 前头含门 800 BO-105 canopy 600 BO-105 tail RCH-70-131-BO105 800BO105 尾巴 distancer set 800 BO-105 short tail tube RCH-70-132-BO105 800BO105 短尾管 21.5x196mm 800 BO-105 short torque RCH-70-133-BO105 800BO105 短尾传动轴 tube 201mm 800 BO-105 short pushrod RCH-70-134-BO105 800BO105 短拉杆...
