Installation Manual
(Translation of original
EN
language)
N420900A - Rev. 08 - 10/2024
Filomuro Slim Fit
SW 400 - SW 600 - SW 800

Advertisement

loading
Need help?

Need help?

Do you have a question about the Filomuro Slim Fit and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Innova Filomuro Slim Fit

Summary of Contents for Innova Filomuro Slim Fit

  • Page 1 Installation Manual (Translation of original language) N420900A - Rev. 08 - 10/2024 Filomuro Slim Fit SW 400 - SW 600 - SW 800...
  • Page 2 By following the suggestions contained in this manual, the product you have purchased will provide trouble free operation, giving you optimum room temperatures with minimum energy costs. INNOVA S.r.l. Conformity This unit complies with the European directives: • EMC 2014/30/EU •...

  • Page 3: Table Of Contents

    TAbLE Of CONTENTS TABLE OF CONTENTS 1. Coding                                5 6.3 Single connection diagram          32 1.1 Product related coding             5 6.4 Multiple connection diagram        33...
  • Page 4 TAbLE Of CONTENTS 11.2 Connection diagram              70 11.3 Connections                   71 11.4 Error signals                   71 12.

  • Page 5: Coding

    This instruction manual refers to the following product Check the correspondence with the technical rat- codes. ing  plate  on  the  product.  See  chapter  "identifica- tion" p. 10. Filomuro Slim Fit For connection with M7 series Bluetooth remote FAWM04DC1II0B00 SW 400 Right-handed fittings...
  • Page 6 1. Coding Filomuro Slim Fit For connection with M7 series remote controls FAWM08DC1II0R00 SW 800 Right-handed fittings (modulating speed) FAWM08DC1II0T00 SW 800 Right-handed fittings For connection with remote control (fixed speed) FAWM08DC1II0V00 SW 800 Right-handed fittings For 0-10 V connection (modulating speed)

  • Page 7: General Information

    2. general information 2. GENERAL INFORMATION 2.1 About the manual  I nthefigures This manual was written to provide all the explanations for the correct management of the appliance. 1 The numbers indicate the individual components. This instruction manual forms an integral part of the A The capital letters indicate component assemblies.

  • Page 8: General Warnings

    2. general information Coding Control panels It addresses all recipients. It is addressed only and exclusively to the Installer and the It contains the list of products and/or accessories referred Authorised Service Centre. to in the manual. these are sections dedicated to the different types of con- trols and electronic boards combined with the range with General information specific information for that combination.

  • Page 9: Disposal

    2. general information It is forbidden to touch the device with wet or damp It is forbidden to introduce objects and substances body parts. through the air inlet and outlet grilles. It is forbidden to carry out any operation before discon- It is forbidden to open the access doors of the device's necting the appliance from the power supply by setting internal parts without first having set main switch of the ...

  • Page 10: Product Presentation

    • SW 600 • SW 800 All sizes are suitable for installation on two-pipe systems. Filomuro Slim Fit fancoils range are available into six con- figurations based on control mode: • 0Q00 - with touchpad and remote control • 0R00 - for connection with M7 series remote controls (modulating speed) •...

  • Page 11: Components

    3. ProduCt PreSentation 3.4 Components Aesthetic front panel air filter On-unit control panel predisposition (only available for some ø 14 mm condensate drain versions) Condensation drain tray air outlet deflector Electrical panel Aesthetic side panels Heat exchanger Anti-intrusion grid 3.5 Compatible accessories The accessories table refers to all products in the filo- muro Slim fit range.
  • Page 12 Network controls Butler BUTLER: codes, accessories and price list in relevant section Valves Valves Filomuro Slim Fit XL I20205II (2) 2 way valve group with manual closure Filomuro Slim Fit I20686II (2) 2 way valve group (water inlet valve, shut off valve and electro thermal motor)
  • Page 13 3. ProduCt PreSentation Accessory description Combinable products Code Fittings Couple of EUROKONUS adapters for 1/2” female connection (male fittings) AI0200II Couple of EUROKONUS adapters for 3/4” female connection (male fittings AI0201II 90° bended EUROKONUS connector AI0203II Distancer kit ( 1 piece) AI0501II Adaptors for flat ring AI0612II 1.

  • Page 14: Installation

    4. inStallation 4. INSTALLATION 4.1 Preliminary warnings This section is dedicated to the Installer. The fea- during  the  installation,  it  is  necessary  to  observe  the  tures of the installer are described in the "Recipi- precautions mentioned in this manual, and on the la- ents"...

  • Page 15: Handling With Packaging

    4. inStallation Models m.u. Dimensions and weight for shipping Width 1120 1320 Height Total depth Weight 15,0 17,0 20,0 4.4 Handling with packaging 4.4.1 Preliminary warnings In manual operation it is compulsory to always respect the maximum weight per person provided for by the national laws and standards.

  • Page 16: Handling Without Packaging

    • rooms subject to high frequencies force. Avoid placing the unit within 1 metre of radio and video The Filomuro Slim Fit fancoil has to be installed only equipment. in high position on the wall, with a maximum height do not install over heat sources.

  • Page 17: Installation Mode

    The unit requires two or more people to position the The filomuro Slim fit fancoil has to be installed only in high unit. position on the wall, with a maximum height of 2,2 m (ex- Make sure that: cept for use in cooling only).

  • Page 18: Device Preparation

    4. inStallation 4.11.2 Device preparation Aesthetic front panel The images refer to a version of the appliance with the connection on the right. If the appliance has the con- nection on the left side, the operation must be adapted to the position of the attacks. before proceeding with the installation, it is necessary to remove some elements from the appliance.

  • Page 19: Installation Arrangement

    4. inStallation 4.11.3 Installation arrangement dowels bracket To install the appliance, use a recessed box to contain the connections. If the appliance is installed later, leave the connecting pipes plentiful so as not to make joints. The images refer to a version of the appliance with the connection on the right.

  • Page 20: Hydraulic Connections

    4.12.2 Position and dimensions Filomuro Slim Fit Models m.u. Pipeline diameter 4.12.4  S hut-offvalves for dimensional information, refer to chapter "Techni- cal information"...

  • Page 21: Condensation Drain Preparation

    4. inStallation 4.13 Condensation drain preparation This appliance is complete with a tray for collecting the Condensate drain connection Connecting stub condensation produced during operation, which must be channelled to a suitable place for drainage. The size and positioning of the drainage tube are shown below.

  • Page 22: Filling The System

    4. inStallation If draining into the sewage system: If the condensation is not collected, it will be deposited on the support surface. The water could freeze if the Make a siphon to prevent bad smells returning up the outdoor temperatures are below zero, thus creating pipe towards the room.

  • Page 23: Electric Connections

    4.15.2 Power line dimensioning for the size of the power supply cable and safety devices, use the following table. Filomuro Slim Fit Models m.u. Power conductor (phase+neutral) mm² Protective conductor section on ground mm²...
  • Page 24 4. inStallation 4.15.3 Access to the terminal block To connect the power supply: Terminal block for wiring Cover of the electrical box fixing screws before carrying out any works, please ensure the power ► making the connections supply is disconnected. Refer to the information in the wiring diagram of the Access to the electrical panel is only permitted to qual- unit you are installing.

  • Page 25: Touchpad And Remote Control Code Eca789

    5. touChPad and remote Control Code eCa789 5. TOUCHPAD AND REMOTE CONTROL CODE ECA789 5.1 Interface The touchpad control is supplied on board the machine, • show any alarms does not require connections, and allows: • select the various functions • show the operating status display area Keys area 5.1.1 Description M7 on-board control, with continuous modulation thermo-...

  • Page 26: Printed Circuit Board Eca789

    5. touChPad and remote Control Code eCa789 5.2 Printed circuit board ECA789 The PCb is included in the supply. M1  dC fan motor with 1 minute delay when the fancoil is in heating mode and is Earth connection on call (potential-free contact max. 1 A). 230V~50Hz Power supply connection 230 V / 50 Hz Presence contact (normally open) Water electrovalve (voltage output 230 V / 50 Hz / 1 A) Step Motor...

  • Page 27: Connections

    5. touChPad and remote Control Code eCa789 5.3 Connections 5.3.1 Presence contact CP ► when closing the CP contact, connected to a po- tential-free contact, the device switches to stand- Through this device it is possible to connect an external by mode control signal that inhibits the operation of the control sig- ►...

  • Page 28: Advanced Menu

    5. touChPad and remote Control Code eCa789 5.4.2 Advanced Menu To access the setup menu, it is necessary to access  S ettheanti-stratificationfunctionto the Basic menu. See section "Basic menu" p. 27. cooling The special functions menu can be accessed via the control panel. To set the anti-stratification function in cooling mode To access the advanced menu ►...
  • Page 29 5. touChPad and remote Control Code eCa789 With the led on and no indication on the display, it is  indicated that there are no errors. 5.4.4 Visualisation of alarms on display In the event of a malfunction, the display shows an alarm code. In the event of an alarm, the device still maintains active functions. ► E1 Room temperature probe AIR/T1 discon- nected or faulty None of the modes can be activated.

  • Page 30: M7 Series Control Code Eeb749

    6. m7 SerieS Control Code eeB749 6. M7 SERIES CONTROL CODE EEB749 6.1 Interface display area Keys area 6.2 Installation 6.2.1 Description the  wall-mounted  remote  control  is  an  electronic  led  thermostat with a touch interface, with the possibility of controlling multiple appliances equipped with the same electronic board.
  • Page 31 6. m7 SerieS Control Code eeB749 • away from heat sources (heaters, convectors, stoves, Electric box 503 back plate direct sunlight) Wall-mounted control panel The wall control is provided inside the package already assembled. back plate Wall-mounted control panel ► Close the control panel Pay attention not to crush the conductors when you close the control.

  • Page 32: Single Connection Diagram

    6. m7 SerieS Control Code eeB749 6.3 Single connection diagram M1  dC fan motor with 1 minute delay when the fancoil is in heating mode and is Step Motor on call (potential-free contact max. 1 A). Earth connection +BA- Serial connection for wall-mounted remote control (respect 230V~50Hz Power supply connection 230 V / 50 Hz / 1 A Ab polarization) Water electrovalve (voltage output 230 V / 50 Hz / 1 A)

  • Page 33: Multiple Connection Diagram

    6. m7 SerieS Control Code eeB749 6.4 Multiple connection diagram M7 series wall control panel Terminal block for device connection board for pairing control and device 12 V 230V 50Hz With multiple command linkage, it is mandatory to per- form command-to-device matching. See section "Pair- ing of control and unit"...

  • Page 34: Connections

    6. m7 SerieS Control Code eeB749 6.5 Connections 6.5.1 Preliminary warnings Terminal block position: Terminal block ( back view panel) The terminals for connecting the control panel and the presence contact CP are placed in a plastic bag and po- sitioned inside the cover of the electrical box. Terminal blocks Terminal blocks The terminals accept:...

  • Page 35: Functions

    6. m7 SerieS Control Code eeB749 the CP presence contact can be configured for heating and  Use a bipolar shielded cable suitable for the RS485 se- cooling operation via the "To select digital input" p.  28 rial connection with a minimum section of 0,35 mm². settings menu item (digital input). Keep the bipolar cable separate from power supply ca- ble by a minimum of 50 mm. 6.5.4 RS485 Serial Connection Chase out the wall in order to minimise the length of the leads.

  • Page 36: Adjusting The Volume

    6. m7 SerieS Control Code eeB749 Setting the humidity hysteresis Adjusting the volume To set the humidity hysteresis To change the volume ► select ► select ► press to change settings ► press to change settings ► increase or decrease the value with the icons ►...

  • Page 37: Reset Pairing

    6. m7 SerieS Control Code eeB749 Set radiant options in heating with R20 ► press to move within the menu ► select to enable the function To change the rH function, it is necessary to have the ► press  to confirm changes accessory MZS - Single zone module for radiant system, By default, the anti-stratification function in cooling code eg1028ii.
  • Page 38 6. m7 SerieS Control Code eeB749 ► select the fancoil to be reset the led on the cover of the electrical box performs the  same functions as the led on the machine board. ► press  to confirm appears, with an acoustic signal. the flashing led indicates errors. The device is removed. With the led on, it is indicated that there aren't errors. To exit the setting LED signals ► press for 5 seconds ► led flashing Exit the setting. Errors to be shown on the display.

  • Page 39: M7 Series Control Part No. Efb749

    The control can manage a maximum of 16 units. The app is available to control the following command. To download the app: Android user: "Innova" iOS user: "Innovabutler" 7.2.2 Mounting The control panel for wall control is to be installed in- side a 503 electrical box.
  • Page 40 7. m7 SerieS Control Part no. efB749 Should the control be located in an area utilised by per- Electric box 503 back plate sons with reduced physical capabilities, please refer to Wall-mounted control panel local regulations. • away from doors or windows • away from heat sources (heaters, convectors, stoves, direct sunlight) The wall control is provided inside the package already assembled.

  • Page 41: Single Connection Diagram

    Activated in parallel with the output of the solenoid valve (Y1) Electronic board for step motor connection M7 series wall control command 12 V 230V 50Hz CHBO The app is available to control the following command. To download the app: Android user: "Innova" iOS user: "Innovabutler"...

  • Page 42: Multiple Connection Diagram

    7. m7 SerieS Control Part no. efB749 7.4 Multiple connection diagram M7 series wall control panel Terminal block for device connection board for pairing control and device 12 V 230V 50Hz With multiple command linkage, it is mandatory to per- form command-to-device matching. See section "Pair- ing of control and unit"...

  • Page 43: Connections

    7. m7 SerieS Control Part no. efB749 7.5 Connections 7.5.1 Preliminary warnings Terminal block position: Terminal block ( back view panel) The terminals for connecting the control panel and the presence contact CP are placed in a plastic bag and po- sitioned inside the cover of the electrical box. Terminal blocks Terminal blocks The terminals accept:...

  • Page 44: Functions

    7. m7 SerieS Control Part no. efB749 the CP presence contact can be configured for heating and  Use a bipolar shielded cable suitable for the RS485 se- cooling operation via the "To select digital input" p.  46 rial connection with a minimum section of 0,35 mm². settings menu item (digital input). Keep the bipolar cable separate from power supply ca- ble by a minimum of 50 mm. 7.5.4 RS485 Serial Connection Chase out the wall in order to minimise the length of the leads.
  • Page 45 7. m7 SerieS Control Part no. efB749  S etprobeoffsetRH Adjusting the volume Modify only after real deviations from an actual meas- To change the volume urement has been established with professional equip- ► select ment. ► press to change settings ► increase or decrease the value with the icons To set the RH probe offset ►...
  • Page 46 7. m7 SerieS Control Part no. efB749 Menu items Set radiant options to cooling with R20 To change the rC function, it is necessary to have the Ad: Not used accessory MZS - Single zone module for radiant system, code eg1028ii. Pr: Not used To change the settings, please refer to the Instruction of: Options for digital output Sheet of the accessory MZS - Single zone module for radiant system, code eg1028ii.
  • Page 47 7. m7 SerieS Control Part no. efB749 red led ► press until appears green led Appears black button Electrical back box ► press  to confirm ► use the icons to move inside the menu ► select No to maintain all fancoils ► select Yes to reset the fancoils ► press  to confirm LED interface operation on the electrical If the device is being paired...
  • Page 48 7. m7 SerieS Control Part no. efB749 ► led on Wall control on and no alarm present. ► led 2 flashes / pause Internal fan motor alarm faulty or disconnected. ► led 3 flashes / pause Alarm for water temperature probe H2/T2 discon- nected or faulty. ► led 6 flashes / pause Communication error alarm with wall control panel. 7.6.5 Alarm display on wall control panel In the event of an alarm, the device still maintains active functions.

  • Page 49: M7 Series Control Code Egb749

    8. m7 SerieS Control Code egB749 8. M7 SERIES CONTROL CODE EGB749 8.1 Interface display area Keys area 8.2 Installation 8.2.1 Description • the functionality of load-bearing elements is not com- promised the  wall-mounted  remote  control  is  an  electronic  led  thermostat with a touch interface, with the possibility of controlling multiple appliances equipped with the same electronic board.
  • Page 50 8. m7 SerieS Control Code egB749 • at a height of about 1,5 m from the floor Electric box 503 back plate Should the control be located in an area utilised by per- Wall-mounted control panel sons with reduced physical capabilities, please refer to local regulations. • away from doors or windows • away from heat sources (heaters, convectors, stoves, direct sunlight) The wall control is provided inside the package already assembled.

  • Page 51: Single Connection Diagram

    8. m7 SerieS Control Code egB749 8.3 Single connection diagram M1  dC fan motor with 1 minute delay when the fancoil is in heating mode and is Step Motor on call (potential-free contact max. 1 A). Earth connection Potential-free input 1(not active) 230V~50Hz H2/T2 Power supply connection 230 V / 50 Hz / 1 A 2-pipe water temperature probe Water electrovalve (voltage output 230 V / 50 Hz / 1 A) Presence contact (normally open)

  • Page 52: Multiple Connection Diagram

    8. m7 SerieS Control Code egB749 8.4 Multiple connection diagram M7 series wall control panel Terminal block for device connection board for pairing control and device 12 V 230V 50Hz It is possible to power the control unit either via a sepa- The matching procedure between command and de- rate 12 V-dC power supply (not supplied) or by connec- vice is mandatory.
  • Page 53 8. m7 SerieS Control Code egB749 Terminal block position: Terminal blocks Terminal block ( back view panel) The terminals accept: • rigid or flexible wires with a 0.2 to 1 mm² cross-sec- tion Terminal blocks • rigid  or  flexible  wires  with  0,5  mm²  cross-section  if  two wires are connected to the same terminal block • rigid or flexible wires with 0,75 mm² cross-section if  the wires have wire end ferrules with a plastic collar 8 mm 0.2 - 1 mm...

  • Page 54: Functions

    8. m7 SerieS Control Code egB749 8.5.4 Bluetooth connection The devices must be equipped with an electronic board suitable for remote control. The wall-mounted remote control can be connected via bluetooth to one or more devices, for a maximum of 16. 8.6 Functions 8.6.1 Basic menu  S etprobeoffsetRH To access the basic menu Modify only after real deviations from an actual meas-...
  • Page 55 8. m7 SerieS Control Code egB749 8.6.2 Advanced Menu To access the setup menu, it is necessary to access by selecting one of the other inputs (CO,CC) the season- the Basic menu. See section "Basic menu" p. 27. ality is locked. It is not possible to modify it through the The special functions menu can be accessed via the control of the control.
  • Page 56 8. m7 SerieS Control Code egB749 8.6.3 Pairing of control and unit The matching procedure between command and de- ► press to access the menu vice is mandatory. ► use the icons to move inside the menu The assignment numbers assigned to the fancoils To pair the control with the unit appears.
  • Page 57 8. m7 SerieS Control Code egB749 ► E6 fancoil block for unsuitable water None of the modes can be activated. ► E7 Module Communication Alarm Bluetooth communication not functioning. ► E8 Communication error Communication error between the wall control pan- el and the fancoil or in case of combining multiple appliances.

  • Page 58: Remote Control Eea649 - Eeb649

    9. remote Control eea649 - eeB649 / efa649 - efB649 9. REMOTE CONTROL EEA649 - EEB649 / EFA649 - EFB649 9.1 Interface display area Keys area 9.2 Installation 9.2.1 Description 9.2.2 Mounting The wall-mounted control panel is a thermostat with possi- bility of control on several device equipped with electronic control for remotization.
  • Page 59 9. remote Control eea649 - eeB649 / efa649 - efB649 Should the control be located in an area utilised by per- Pay attention not to crush the conductors when you sons with reduced physical capabilities, please refer to close the control. local regulations. • away from doors or windows •...

  • Page 60: Single Connection Diagram

    9. remote Control eea649 - eeB649 / efa649 - efB649 9.3 Single connection diagram The PCb is included in the supply. M1  BO/C2 dC fan motor Heating request contact (for example boiler or heat pump). Step Motor Activated in parallel with the output of the solenoid valve (Y1) -BA+ Serial connection for wall-mounted remote control with 1 minute delay when the fancoil is in heating mode and is Earth connection on call (potential-free contact max.

  • Page 61: Multiple Connection Diagram

    9. remote Control eea649 - eeB649 / efa649 - efB649 9.4 Multiple connection diagram Wall-mounted control panel The terminal block for CP presence contact connection Terminal block for device connection 230V 50Hz 9.5 Connections 9.5.1 Preliminary warnings The terminals for connecting the control panel and the presence contact CP are placed in a plastic bag and po- sitioned inside the cover of the electrical box.
  • Page 62 9. remote Control eea649 - eeB649 / efa649 - efB649 To connect the wall control panel to the board: Terminal blocks ► connect the power supply cables to the + - terminals ► connect the Modbus serial connection cables to ter- minals A and b 9.5.3 Presence contact CP Through this device it is possible to connect an external control signal that inhibits the operation of the control sig- nal, for example:...

  • Page 63: Functions

    9. remote Control eea649 - eeB649 / efa649 - efB649 • in Off position, ventilation takes place cyclically, 4 dip-switch B dip-switch C min ON - 10 min Off Dip-switch C • changes the logic of night-time operation in heating mode • in the ON position, ventilation is inhibited, allowing the appliance to heat rooms by radiation and natural convection as in traditional radiators •...
  • Page 64 9. remote Control eea649 - eeB649 / efa649 - efB649 the volume changes after confirming the modification. LED signals ► led off Device switched off or without power supply. Adjust the brightness of the display ► led on Normal operating of the device To adjust the brightness of the display ► led 1 flash / pause ► select Water request detected by temperature probe H2/ ►...

  • Page 65: Fixed Speed Remote Controls Code B3V151

    10. fixed SPeed remote ControlS Code B3V151 10. FIXED SPEED REMOTE CONTROLS CODE B3V151 10.1 Interface 10.2 Description Wall mounted control with thermostat, summer/winter and speed selectors.

  • Page 66: Connection Diagram

    10. fixed SPeed remote ControlS Code B3V151 10.3 Connection diagram Board B3V151 Wall control SW GRL DATA I/O N276660C MOTOR F1AT N EV1 N EV2 230V 50Hz...

  • Page 67: Connection Diagram With Seasonal Switching

    10. fixed SPeed remote ControlS Code B3V151 10.4 Connection diagram with seasonal switching 230 V / 50 Hz power supply Mobile aspiration panel control (230 V / 50 Hz / 1 A voltage Consent input output) Maximum fan speed (1400 rpm) RS version wiring HRS  Medium fan speed (1100 rpm)  rS water probe (10 kΩ) M1 ...

  • Page 68: Generic Thermostat Connection Diagram

    10. fixed SPeed remote ControlS Code B3V151 10.5 Generic thermostat connection diagram The PCb is included in the supply. 230V~50Hz M1  Power supply 230 V-50 Hz dC fan motor SM  Solenoid valve permission input Step motor (diffuser) Maximum fan speed 1.400 rpm 3 speed room thermostat (to buy, install and connect by the Medium fan speed 1.100 rpm installer) Minimum fan speed 680 rpm...

  • Page 69: Connections

    10. fixed SPeed remote ControlS Code B3V151 10.6 Connections 10.6.1 Connection with 3 speed 10.6.2 Water probe management thermostats through the water temperature probe (10 kΩ) positioned  in the compartment on the unit's coil, the functions can be regulated: CV input • minimum temperature in heating mode (30 °C) • maximum temperature in cooling mode (20 °C) The CV input is the ON/OFF of the board.

  • Page 70: 10 V Connection

    11. 0-10 V ConneCtion 11. 0-10 V CONNECTION 11.1 Installation 11.1.1 Description Motor regulation can be made through a 0-10 V analogue input with an input impedance of 25 kΩ. On-board electronic printed circuit board for control from systems with 0-10 V analogue output. Consider the impedance value, especially when con- Mounted on the unit, it allows the motor to be managed trolling several units in parallel.

  • Page 71: Connections

    11. 0-10 V ConneCtion 11.3 Connections The 10 V input • activates solenoid valve Y1 • regulates the fan speed Linear speed regulation is possible, from a minimum value MAX rpm (400 rpm) to a maximum value (1500 rpm) for voltage val- ues ≥ 1.1 V to 10 V dC. the motor is switched off for values below 1 V.

  • Page 72: Maintenance

    12. maintenanCe 12. MAINTENANCE routine  maintenance  is  essential  to  keep  the  device  effi- cient, safe, and reliable over time. 12.1 Preliminary warnings This section is dedicated to the Authorised Service Warnings: Centre. The features of the Authorised Service Cen- • do not lean or sit on the fancoil to avoid damaging  tre are described in chapter "Recipients"...

  • Page 73: Suggestions For Energy Saving

    12. maintenanCe 12.2.2  A irintakefiltercleaning Cleaning the filter must be carried out: ► rotate until the complete exit from the housing • after prolonged operation, consider the concentra- ► remove the filter tion of impurities in the air To clean the filters: •...

  • Page 74: Troubleshooting

    13. trouBleShooting  13. TROUBLESHOOTING 13.1 Preliminary warnings For detailed information on accessories please re- Follow the instructions below: fer to the "Configuration accessories" p.  75 sec- ► disconnect the device from power supply immediate- tion. ► isolate the water supply Should you encounter any of the anomalies below: ►...

  • Page 75: Configuration Accessories

    14. Configuration aCCeSSorieS 14. CONFIGURATION ACCESSORIES 14.1  S hut-offvalves as standard, the unit is supplied without shut-off valves The motorized valve can be omitted, inside the unit, if there is a motorized valve in the distribution manifold The 2-way and 3-way motorized valves are mandatory of the system and connected to the regulation card of for the correct operation of the unit.
  • Page 76 14. Configuration aCCeSSorieS Unit Water outlet pipe fitting Thermoelectric actuator Electrical cable entry hole fitting for water inlet pipe 14.1.3 Connection with 3-way diverting valve unit with thermoelectric actuator (V30688) V30688II - 3-way deviator valve unit with thermo-electric • electrical connection are required head • connect to the flow at the bottom In case of choice for the 3-way diverter valve unit with ther- moelectric motor: Unit...

  • Page 77: Technical Information

    15. teChniCal information 15. TECHNICAL INFORMATION 15.1 Technical data Filomuro Slim Fit Models m.u. Cooling performances (W 7/12 °C; A 27 °C) (1) Total cooling capacity 1,24 1,61 1,94 Sensible cooling capacity 0,98 1,27 1,52 Water flow 212,00 276,00 332,00 Pressure drop...

  • Page 78: Limits Of Product Operation

    Cooling Minimum room relative humidity Maximum room relative humidity Minimum room air temperature °C Maximum room air temperature °C 15.4 Dimensions Lateral view front view Filomuro Slim Fit Models m.u. Width 1015 1215 Height Total depth Net weight 14,0 16,0...
  • Page 79 NOTES...
  • Page 80 INNOVA S.r.l. Via I Maggio 8 - 38089 Storo (TN) - ITALY tel. +39.0465.670104 – fax +39.0465.674965 info@innovaenergie.com...

This manual is also suitable for:

Sw 400Sw 600Sw 800Fawm04dc111ob00Fawm04dc111op00Fawm04dc111oq00 ... Show all
