- Page 1 Installation and user manual SLWI...
-
Page 2: Editorial Pictograms
By following the suggestions contained in this manual, the product that you have purchased will operate without problems giving you optimum room temperatures with minimum energy costs. INNOVA S.r.l. Conformity This unit complies with the European directives: •... -
Page 3: General Warnings
GENERAL GENERAL 1.1 General warnings After unpacking, make sure that all the components are – close the water taps present. If not, contact your vendor who sold the device – if there is a danger of frost, make sure that you have added to you. -
Page 4: Product Line
GENERAL 1.3 Product line Filomuro incasso fancoils range are designed for wall in- • for connection with remote control at modulating speed stallation. The device are are made in three different perfor- • for connection with remote control at fixed speed mance levels and size, all for two-pipe configuration. - Page 5 GENERAL 1.6 Dimensions and weight for shopping Filomuro Filomuro Filomuro Models m.u. Dimensions and weight for shopping Total length 1020 1220 1320 Total height Total depth Weight...
-
Page 6: Unit Placement
INSTALLATION INSTALLATION 2.1 Unit placement Position of device must be established by the system design- Make sure that: er or other qualified professional and must take into account • the wall on which you intend to install the unit has an ap- both technical requirements and any local laws in force. -
Page 7: Device Preparation
INSTALLATION 2.4 Device preparation The unit is supplied without accessories. The formwork for in- The metal case for housing the unit must already be pre- stalling the unit is supplied separately for installation on site. pared on the wall before installing the appliance. Installation arrangement To install the unit, prepare the wall for housing the metal cas- Make sure that the wall is not crossed by pipelines,... - Page 8 INSTALLATION Metal casing Plaster holder mesh – fix to the wall During the installation of the formwork, keep the edge of the plaster-holder mesh levelled with the finished wall. Plaster holder mesh Skimming Aesthetic panel attachment holes Make sure that the metal casing does not deform during installation.
-
Page 9: Fancoil Unit Installation
INSTALLATION Fancoil unit installation – place the cage nuts supplied in the square holes provided – check right alignment in the formwork It is necessary, for right functioning of the device, that – insert the 2 brackets supplied with the appliance during the whole installation phase the working space remains clean. - Page 10 INSTALLATION Aesthetic front panel installation – bring the aesthetic panel closer to the formwork – hook the lower part of the panel using the hooks provided in the formwork Aesthetic panel attachment holes Aesthetic front panel – bring the top of the aesthetic panel closer to the form- –...
-
Page 11: Hydraulic Connections
INSTALLATION 2.6 Hydraulic connections The engineer is responsible for choosing the right water lines Keep in mind that undersized pipelines lead to poor sys- and their size, in accordance with good installation practices tem operation and/or a loss of thermal and cooling per- and the applicable law. - Page 12 INSTALLATION Connection to the system To make the connections: The hydraulic lines and fittings must be thermally insulat- – hydraulic lines positioning Avoid partial insulation of the pipes. – use the "wrench against wrench" method Avoid over-tightening the pipes to avoid damage to the –...
- Page 13 INSTALLATION Connection with 2-way valve and thermoelectric actuator (V20687) In case of choice for the 2-way valve and thermoelectric ac- • connect the pipe with the water sending at the top tuator: unit body thermoelectric actuator fitting for water inlet pipe water outlet pipe fitting electrical cable entry hole Connection with 3-way diverting valve unit with thermoelectric actuator (V30688)
-
Page 14: Condensate Drain
INSTALLATION 2.7 Condensate drain drain connection, external Ø 14 mm The unit is complete of a drain pan that collects the con- densate fluid that is produced during cooling operation and must be conveyed to a suitable place for unloading. Connection to the condensate drain Drain connection Unit... -
Page 15: Filling The System
INSTALLATION 2.8 Filling the system To fill the system: Regularly check the system's pressure. – open the vent valves Coil vent – open all the system's shut-off devices – slowly open the water tap When water begins to leak out of the breather valves: –... - Page 16 INSTALLATION terminal block for wiring – bring the power cord to the terminal block – making the connections – refer to the information in the wiring diagram of the unit you are installing You can use a cable embedded in the wall in the position traced with the installation template to make the electrical connection (recommended connection for devices installed in the upper part of the wall).
- Page 17 INSTALLATION 2.10 Diagrams and configurations electrical controls Remote control EDA649 - EDB649 / EWG649 - EWW649 (code suffix-0P00) Printed circuit broad with continuous modulation for wall control connection The PCB is included in the supply. -AB+ Serial connection for wall-mounted remote control (respect the AB polarization) Hot water temperature probe 10 kΩ...
-
Page 18: Error Signals
INSTALLATION Wall mounted remote control EDA649 - EDB647 / EWG649 - EWW649 The control panel is to be ordered separately. – if the wire is rigid, you can insert it easily whereas Terminal blocks – if it is flexible, it is advisable to use long nose pliers –... - Page 19 INSTALLATION Remote control with fixed speed (code suffix-0T00) Printed circuit board for connection to standard 4-speed thermostats The PCB is included in the supply. N-L 230 V/50 Hz electrical power supply Solenoid valve permission input Maximum fan speed 1.400 rpm Medium fan speed 1.100 rpm Minimum fan speed 680 rpm Super-silent speed 400 rpm...
- Page 20 INSTALLATION Connection with 3 speed thermostats The CV input is the ON/OFF of the board: • V4 - supersilent speed (equal to 400 rpm) Connect the 3 speeds of the thermostat to three of the four • in case of opened input the PCB is placed in stand-by available inputs based on the characteristics and use of the location.
- Page 21 INSTALLATION Remote control with modulating speed (code suffix-0V00) Printed circuit board for 0-10 V interface The PCB is included in the supply. L-N 230 V/50 Hz electrical power supply 10V Device pilot input 0÷10 V. Input impedance 25 kΩ Water solenoid valve (230 V/50 Hz 1 A power output) Fan motor DC Inverter N276659C...
- Page 22 INSTALLATION Connection with 0-10 V thermostats The 10 V input activates solenoid valve Y1 and adjusts the The solenoid valve Y1: number of rotations of the fan. The speed range provides a • is enabled by voltage values > 1 V DC linear adjustment from the minimum value (400 rmp) to the maximum value (1400 rmp) for voltage values ≥...
- Page 23 INSTALLATION WALL MOUNTED REMOTE CONTROL EDA649 - EDB647 / EWG649 - EWW649 3.1 Installation Description The wall-mounted control panel is a thermostat with possi- The control can control up to a maximum of 30 units. bility of control on several device equipped with electronic The temperature probe can be remoted in one of the fan- control for remotization.
-
Page 24: Connection Diagram
INSTALLATION For the remote control wall mounting: Base of the control Holes for the wall mounting – drill holes in the wall Screws – pull the electric wires through the hole provided Hole for the passage of the electrical connections –... - Page 25 INSTALLATION Terminal block position Terminal block The spring terminals allow the connection of rigid or flexible cables with sections from 0.2 to 1 mm². For cables provided with lugs with plastic collar the maximum section is reduced to 0,75 mm². Connection to the PCB For the connection: –...
-
Page 26: Keys Functions
INSTALLATION 3.3 Interface Description The wall-mounted control panel EDA649-EDB649 / EWG649- The control can control up to a maximum of 30 units. EWW649 is a thermostat with possibility of control on several The room temperature probe ensures an antifreeze safety device equipped with electronic control for remotization. -
Page 27: Main Functions
INSTALLATION General start-up Before the activation: In case of a master switch on the power supply line, switch on the system by inserting the switch. Make sure that the remote control is connected to the mains. To activate the device press the –... - Page 28 INSTALLATION • in heating function decreases by 1 °C after one hour and • in cooling function decreases by 1 °C after one hour and by another degree after 2 hours by another degree after 2 hours Maximum ventilation speed To select the operation at the maximum ventilation speed press the key for about 2 seconds...
-
Page 29: Menu Items
INSTALLATION To access the menu with the display off, hold down for 10 seconds – The device turns on and the temperature appears keep pressed until the indication "Ad" appears – To navigate in the menu use the icons – The menu items change To select a menu item and to confirm the changes made press the icon... -
Page 30: Factory Reset
INSTALLATION To select digital input select the menu item "di" by pressing – The default value appears select "CP" for clean contact – select "CO" to cooling open – select "CC" to cooling close – By default digital input is set to CP. For return to the default settings, set the digital input to "CP". - Page 31 INSTALLATION WALL-MOUNTED CONTROL B3V151 - B3V152 4.1 Electric connections Connection diagram B3V151 Wall control DATA I/O N276660C B3V152 Built-in wall control DATA I/O N276660C...
-
Page 32: Routine Maintenance
MAINTENANCE MAINTENANCE 5.1 Routine maintenance Routine maintenance is essential to keep the device always Warnings: efficient, safe and reliable over time. • Do not lean on the fancoil to avoid damaging the appli- It can be done: ance. •... -
Page 33: Inserting The Filter
MAINTENANCE Air intake filter cleaning Cleaning the filter must be carried out: • when you plan to restart the system after prolungate dis- use. • after prolonged operation, considered the concentration of impurities in the air, Filter extraction To extract the filter: –... - Page 34 MAINTENANCE 5.2 Suggestions for energy saving For a correct operation of the device and a great energy sav- ing: • keep the filters clean • keep the doors and windows of the locations fitted with air conditioning systems closed as much as possible •...
-
Page 35: Troubleshooting Table
TROUBLESHOOTING TROUBLESHOOTING 6.1 Preliminary warnings Should you encounter any of the anomalies below: – disconnect the device from power supply immediately • the ventilation does not start even if the water circuit is – close the water taps filled with hot or cold water –... - Page 36 INNOVA S.r.l. Via I Maggio 8 - 38089 Storo ( TN) - ITALY tel. +39.0465.670104 – fax +39.0465.674965 info@innovaenergie.com N420310A - Rev. 01...
