Installation Manual
(Translation of original
EN
instructions)
N420927A - Rev.00 - 04/23
AirLeaf
EEB749 - EGB749 - EEA649 - EEB649
EFA649 - EFB649 - E4T643 - E2T543
ECA644 - ECA647 - EWF644 - EWF647
B3V137 - B4V642 - B3V151 - B10642

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AirLeaf SL and is the answer not in the manual?

Questions and answers

Related Manuals for Innova AirLeaf SL

Summary of Contents for Innova AirLeaf SL

  • Page 1 Installation Manual (Translation of original instructions) N420927A - Rev.00 - 04/23 AirLeaf EEB749 - EGB749 - EEA649 - EEB649 EFA649 - EFB649 - E4T643 - E2T543 ECA644 - ECA647 - EWF644 - EWF647 B3V137 - B4V642 - B3V151 - B10642...
  • Page 2 By following the suggestions contained in this manual, the product you have purchased will operate without problems giving you optimum room temperatures with minimum energy costs. INNOVA S.r.l. Conformity Refer to the Installer Manual of the paired unit.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Coding                                                                     p. 7 1.1 Coding accessories .
  • Page 4 M7 series control Code EGB749                                              p. 26 5.1 Interface .
  • Page 5 7.4.2 Long period shut-down ........p. 48 7.4.3 LED signals .
  • Page 6 12 Connection 0-10 V Code B10642                                             p. 66 12.1 Installation .

  • Page 7: Coding                                                                     P

    CODInG CODING The present manual refers to the products: • AirLeaf SLI • AirLeaf SL • AirLeaf SLSI • AirLeaf SLS • AirLeaf RSI • AirLeaf RS 11 Coding accessories This instruction manual refers to the following accessory codes. Accessory description...
  • Page 8 CODInG Accessory description Combinable products Code Electronic board on board unit with continuous modulation. For ESE745II connection to M7 wall control units SL FULL FLAT SLSI RS FULL FLAT 2 PIPES Electronic board on board unit with continuous modulation. For ESE746II connection to M7 wall control with Bluetooth SL FULL FLAT...
  • Page 9 CODInG Accessory description Combinable products Code SL FULL FLAT 2 PIPES On-board electronic printed circuit board for control from B10642II (1) systems with 0-10 V analogue output. RS FULL FLAT SLSI 2 PIPES and 4 PIPES On-board electronic printed circuit board for connection to B4V642II (1) 3-speed wall-mounted electromechanical thermostats.

  • Page 10: General Information                                                       P

    GEnERAL InFORMATIOn GENERAL INFORMATION 21 About the manual  I nthefigures This manual was written to provide all the explanations for the correct management of the appliance. 1 The numbers indicate the individual components. This instruction manual forms an integral part of the A The capital letters indicate component assemblies.

  • Page 11: General Warnings

    GEnERAL InFORMATIOn It is addressed exclusively to the installer. It is addressed only and exclusively to the Installer and the It contains specific warnings and all the information nec- Technical Assistance Centre. essary for positioning, mounting and connecting the ap- These are sections dedicated to the different types of con- pliance.

  • Page 12: Disposal

    GEnERAL InFORMATIOn 24 Disposal The symbol on the product or its packaging indicates that the product must not be treated as normal household waste, but must be taken to the appropriate collection point for the recycling of electrical and electronic equip- ment.

  • Page 13: Installation                                                               P

    InSTALLATIOn INSTALLATION 31 Installation 311 Preliminary warnings Before doing any work, make sure that the supply pow- er is disconnect. All operations of an electrical nature must be carried out by qualified personnel having the necessary legal requirements, trained and informed about the risks re- lated to such operations.

  • Page 14: Installation Of Electrical Connection Box

    InSTALLATIOn 313 Installation of electrical connection box To install the electrical connection box The minimum force that must be exerted to tighten the – separate the base of the electrical box from the cover screws must be approximately 2n. – place the base of the electrical box on the side of the –...

  • Page 15: Completed Assembly

    InSTALLATIOn – connect the water probe to the T2 connector on the the quick connector (MOTOR) on the electrical board device on the left-hand side. To make the connections: Valid for the EEB749, EGB749, EEA649, EEB649, EFA649, – connect the cable to the fan motor EFB649, ECA644, ECA647, EWF644, EWF647, E4T643, –...

  • Page 16: Mounting

    M7 SERIES COnTROl COdE EEB749  M 7SERIESCONTROLCODEEEB749 41 Interface Display area Keys area 42 Installation 421 Description the wall-mounted remote control is an electronic LED ther- mostat with a touch interface, with the possibility of control over multiple appliances equipped with the same electron- ic board.
  • Page 17 M7 SERIES COnTROl COdE EEB749 – Close the control panel Base of control Wall-mounted control panel Pay attention not to crush the conductors when you close the control. Before wall installation: – separate the control base from the control panel Fixing screws Base of control Holes for fixing to electrical box Electric box 503 For wall mounting of the control panel:...

  • Page 18: Single Connection Diagram

    M7 SERIES COnTROl COdE EEB749 43 Single connection diagram Fan motor DC Inverter with 1 minute delay when the fancoil is in heating mode and is Earth connection on call (potential-free contact max. 1 A). Power supply connection 230 V / 50 Hz / 1 A Presence contact (normally open) -BA+ Water electrovalve...

  • Page 19: Multiple Connection Diagram

    M7 SERIES COnTROl COdE EEB749 44 Multiple connection diagram M7 series wall control panel Terminal block for device connection Board for pairing control and device...

  • Page 20: Preliminary Warnings

    M7 SERIES COnTROl COdE EEB749 45 Connections 451 Preliminary warnings Terminal block position: Terminal block ( Back view panel) The terminals for connecting the control panel and the presence contact CP are placed in a plastic bag and po- sitioned inside the cover of the electrical box. Terminal blocks Terminal blocks The terminals accept:...
  • Page 21 M7 SERIES COnTROl COdE EEB749 454 RS485 Serial Connection Use a bipolar shielded cable suitable for the RS485 se- rial connection with a minimum section of 0,35 mm². The wall-mounted remote control can be connected through a RS485 serial line to one or more device, for a Keeping the bipolar cable separate from power supply maximum of 16.
  • Page 22 M7 SERIES COnTROl COdE EEB749 To select digital input After 30 seconds from the last action the control goes out and the settings is memorized. To change the digital input Menu items select – press to change settings – ot: AIR probe offset (air probe setting) select CP for contact presence (default) –...
  • Page 23 M7 SERIES COnTROl COdE EEB749  S etthehotanti-stratificationfunction Toenablethehotanti-stratificationfunction select – press to change settings – select no to disable the hot anti-stratification – function select Yes to enable the hot anti-stratification – function press to confirm – By default, digital input is set to Yes. In heating mode, periodically the fan turns on at mini- mum speed to limit the air stratification effect.
  • Page 24 M7 SERIES COnTROl COdE EEB749 463 Pairing of control and unit To pair the control with the unit The device is removed. with control switched on, at the same time press – To exit the setting for about 10 seconds press for 5 seconds –...

  • Page 25: Functions

    M7 SERIES COnTROl COdE EEB749 The LED on the cover of the electrical box performs the Incorrect water temperature with au- – same functions as the LED on the machine board. tomatic season function setting The fancoil is performing heating and cooling func- The flashing lEd indicates errors. tions incorrectly.
  • Page 26 M7 SERIES COnTROl COdE EGB749  M 7SERIESCONTROLCODEEGB749 51 Interface Display area Keys area 52 Installation 521 Description the wall-mounted remote control is an electronic LED ther- mostat with a touch interface, with the possibility of control over multiple appliances equipped with the same electron- ic board.
  • Page 27 M7 SERIES COnTROl COdE EGB749 The wall control is provided inside the package already Electric box 503 Base of control assembled. Wall-mounted control panel Base of control Wall-mounted control panel – Close the control panel Pay attention not to crush the conductors when you Before wall installation: close the control.
  • Page 28 M7 SERIES COnTROl COdE EGB749 53 Single connection diagram Fan motor DC Inverter BO/C2 Heating request contact (for example boiler or heat pump). Earth connection Activated in parallel with the output of the solenoid valve (Y1) Power supply connection 230 V / 50 Hz / 1 A with 1 minute delay when the fancoil is in heating mode and is Water electrovalve on call (potential-free contact max.
  • Page 29 M7 SERIES COnTROl COdE EGB749 54 Multiple connection diagram M7 series wall control panel Terminal block for device connection Board for pairing control and device 12 V-dc It is possible to power the control unit either via a sepa- rate 12 V-DC power supply (not supplied) or by connec- tion to the - + contacts on the PU board.
  • Page 30 M7 SERIES COnTROl COdE EGB749 55 Connections 551 Preliminary warnings Terminal block position: Terminal block ( Back view panel) The terminals for connecting the control panel and the presence contact CP are placed in a plastic bag and po- sitioned inside the cover of the electrical box. Terminal blocks Terminal blocks The terminals accept:...
  • Page 31 M7 SERIES COnTROl COdE EGB749 554 Bluetooth connection – connect respecting the indication A and B The wall-mounted remote control can be connected via Chase out the wall in order to minimize the length of Bluetooth to one or more devices, for a maximum of 16. the leads.
  • Page 32 M7 SERIES COnTROl COdE EGB749 Enabling radiant zones rA: Radiant zone options Ac: Cold Antistratification To enable the radiant zone select – Ah: Hot anti-stratification press to change settings –  S etAIRprobeoffset change the value with the icons – press to confirm – To set the air probe regulation The setting range is from 01 to a maximum of 03.
  • Page 33 M7 SERIES COnTROl COdE EGB749 563 Pairing of control and unit To pair the control with the unit The device is removed. with control switched on, at the same time press – To exit the setting for about 10 seconds press for 5 seconds –...
  • Page 34 M7 SERIES COnTROl COdE EGB749 The LED on the cover of the electrical box performs the Incorrect water temperature with au- – same functions as the LED on the machine board. tomatic season function setting The fancoil is performing heating and cooling func- The flashing lEd indicates errors. tions incorrectly.
  • Page 35 REMOTE COnTROl EEA649 - EEB649 / EFA649 - EFB649  R EMOTECONTROLEEA649-EEB649/EFA649-EFB649 61 Interface Display area Keys area 62 Installation 621 Description 622 Mounting The wall-mounted control panel is a thermostat with possi- bility of control on several device equipped with electronic control for remotization. The control can control up to a maximum of 30 units. The temperature probe can be remoted in one of the connected device.
  • Page 36 REMOTE COnTROl EEA649 - EEB649 / EFA649 - EFB649 • away from doors or windows • away from heat sources (heaters, convectors, stoves, direct sunlight) The wall-mounted remote control is provided inside the package already assembled. notches Before wall installation: – Unhook the protruding notches on the back side of the control.
  • Page 37 REMOTE COnTROl EEA649 - EEB649 / EFA649 - EFB649 63 Single connection diagram Fan motor DC Inverter with 1 minute delay when the fancoil is in cooling mode and is -BA+ Serial connection for wall-mounted remote control on call (potential-free contact max. 1 A). Earth connection BO/C2 Heating request contact (for example boiler or heat pump). Power supply connection 230 V / 50 Hz / 1 A Activated in parallel with the output of the solenoid valve (Y1) Water electrovalve...
  • Page 38 REMOTE COnTROl EEA649 - EEB649 / EFA649 - EFB649 64 Multiple connection diagram M7 series wall control panel Terminal block for device connection...
  • Page 39 REMOTE COnTROl EEA649 - EEB649 / EFA649 - EFB649 65 Connections 651 Preliminary warnings Terminal block position: Terminal blocks The terminals for connecting the control panel and the presence contact CP are placed in a plastic bag and po- sitioned inside the cover of the electrical box. Terminal blocks To connect the wall control panel to the board: –...
  • Page 40 REMOTE COnTROl EEA649 - EEB649 / EFA649 - EFB649 It is forbidden make star connections. 66 Functions 661 Setup menu Set the modbus address Through the control it is possible to access the settings To set the modbus address menu. select – increase or decrease the value with the icons –...
  • Page 41 REMOTE COnTROl EEA649 - EEB649 / EFA649 - EFB649 UV lamp options Access to the Radiant menu items is only possible if the set value for rH or rC is > 0. To enable UV lamp option To access the Radiant menu select – from the settings menu press the button for –...
  • Page 42 REMOTE COnTROl EEA649 - EEB649 / EFA649 - EFB649 lEd 3 flashes / pause – H2/T2 water temperature probe disconnected or faulty. lEd 5 flashes / pause – Alarm Probe AIR/T1 disconnected or faulty. 1. * In case of a operation without water probe H2/T2, the fan stop thresholds will be ignored. 664 Error signals The symbol is displayed to indicate alarms on the wall control panel.
  • Page 43 On-BOARd COnTROl COdE ECA644 - ECA647 - EWF644 - EWF647  O N-BOARDCONTROLCODEECA644-ECA647-EWF644-EWF647 71 Interface Display area Keys area AUTO 72 Installation 721 Description The printed circuit board provides for operation without a water probe. In this case, the fan stop thresholds are ignored. Electronic control on-board the unit The control can control up to a maximum of 30 units.
  • Page 44 On-BOARd COnTROl COdE ECA644 - ECA647 - EWF644 - EWF647 722 Installation of on-board control Dip-switch B Dip-switch C To install the on-board control – place the on-board control at the top of the unit – fix with the screws provided On board display Screws 724 CP presence contact input connection The presence contact (CP) input connection is to be made with: •...
  • Page 45 On-BOARd COnTROl COdE ECA644 - ECA647 - EWF644 - EWF647 725 Installation of air temperature • operation of the cooling symbol (on with setpoint low- er than room temperature, off with higher setpoint) probe This selection is saved even if the power is switched off. – position the temperature probe – pass the probe through the hole in the shoulder of the appliance – pass the probe through the lower hole –...
  • Page 46 On-BOARd COnTROl COdE ECA644 - ECA647 - EWF644 - EWF647 73 Connection diagram Fan motor DC Inverter with 1 minute delay when the fancoil is in heating mode and is HRS Water temperature probe 10 kΩ for RS models (only for ECA644 on call (potential-free contact max. 1 A). - EWF644) CH/C1 Cooling request contact (for exemple chiller or reversible heat Wiring for RS models (only for ECA644 - EWF644) pump).
  • Page 47 On-BOARd COnTROl COdE ECA644 - ECA647 - EWF644 - EWF647 74 Functions 741 Setup menu  A djustingbuzzervolume Through the control it is possible to access the settings To change the volume menu. select – increase or decrease the value with the icons – To access the settings menu with the display off, hold down for 10 seconds –...
  • Page 48 On-BOARd COnTROl COdE ECA644 - ECA647 - EWF644 - EWF647 Factory reset To change the settings, please refer to the Instruction Sheet of the accessory MZS - Single zone module for To reset the control to factory settings radiant system, code. EG1028II. select – Radiant module option (MZS) in Cooling select "YS"...
  • Page 49 On-BOARd COnTROl COdE ECA644 - ECA647 - EWF644 - EWF647 Incorrect setpoint – The symbol of the function activated flashes and ventilation is stopped until the set setpoint is reached.
  • Page 50 On-BOARd COnTROl COdE E4T643  O N-BOARDCONTROLCODEE4T643 81 Interface Display area Keys area AUTO 82 Installation 821 Description The Smart Touch E4T643on-board electronic control 4-speed fixed speed and thermostat consists of a panel with eight capacitive keys and an amber display. The control is fitted with: • AUTO function (step ventilation adjustment) •...
  • Page 51 On-BOARd COnTROl COdE E4T643 822 Installation of on-board control Air temperature probe Prepared hole in the shoulder of the appliance To install the on-board control Lower hole – place the on-board control at the top of the unit Hook for temperature probe – fix with the screws provided On board display Screws 823 Installation of air temperature...
  • Page 52 On-BOARd COnTROl COdE E4T643 83 Connection diagram Fan motor DC Inverter Power supply connection 230 V / 50 Hz / 1 A HRS Water temperature sensor 10 kΩ for RS models AIT/T1 Water temperature probe Wiring for RS models H2/T2 2-pipe water temperature probe COMM UV lamp connection Connection for on-board control display Water electrovalve Earth connection AUTO...
  • Page 53 On-BOARd COnTROl COdE E4T643 84 Functions 841 Setup menu  A djustingbuzzervolume Through the control it is possible to access the settings To change the volume menu. select – increase or decrease the value with the icons – To access the settings menu with the display off, hold down for 10 seconds –...
  • Page 54 On-BOARd COnTROl COdE E4T643 Reset Modbus LED signals lEd off – select – Device switched off or without power supply. select "no" to keep the current settings – LED on – select "YS" to reset the settings – Normal operating of the device lEd 1 flash / pause Factory reset –...
  • Page 55 On-BOARd COnTROl COdE E2T543  O N-BOARDCONTROLCODEE2T543 91 Interface Display area Led area Keys area mode 92 Installation 921 Description On-board control with: • speed selector • On/OFF key • room thermostat adjustable from 5 °C to 40 °C • summer/winter selector • winter minimum temperature function 30 °C and summer maximum temperature function 20 °C The on-board control with thermostat is suitable for in- stallation on board the unit and has a 230 V output for...
  • Page 56 On-BOARd COnTROl COdE E2T543 922 Installation of on-board control 923 Installation of air temperature probe To install the on-board control – place the on-board control at the top of the unit – position the temperature probe – fix with the screws provided – pass the probe through the hole in the shoulder of the appliance On board display –...
  • Page 57 On-BOARd COnTROl COdE E2T543 93 Connection diagram Hot water temperature probe 10 kΩ Wiring for RS model Fan motor DC Inverter Air temperature probe Water solenoid valve ( 230 V/50 Hz 1 A power output) Output for mobile suction panel servomotors (power output at 230 V/50 Hz electrical power supply connection 230 V/50 Hz 1 A) HRS Water temperature probe 10 kΩ for RS models INTERFACCIA...
  • Page 58 On-BOARd COnTROl COdE E2T543 94 Water probe management Through the water temperature probe (10 kΩ) positioned in the compartment on the unit's coil, the functions can be regulated: • minimum temperature in heating mode (30 °C) • maximum temperature in cooling mode (20 °C) If the printed circuit board detects the water temperature probe correctly, start-up takes place under normal condi- tions.
  • Page 59 SpEEd SElECTOR COdE B3V137  S PEEDSELECTORCODEB3V137 101 Interface Led area Keys area mode 102 Installation 1021 Description On board display Screws On-board speed selector B3V137 for connection to stand- ard single-contact wall-mounted thermostats. On-board control with: • speed selector • On/OFF key •...
  • Page 60 SpEEd SElECTOR COdE B3V137 103 Connection diagram 230 V connection consent from room thermostat Wiring for RS model HRS Water temperature probe 10 kΩ for RS models Fan motor DC Inverter Water solenoid valve ( 230 V/50 Hz 1 A power output) Output for mobile suction panel servomotors (power output at 230 V/50 Hz electrical power supply connection 230 V/50 Hz 1 A) N276663A...
  • Page 61 SpEEd SElECTOR COdE B3V137  O N-BOARDELECTRONICBOARDB4V642+WALLCONTROLB3V151 On-board electronic board Code B4V642 1111 Description Installed on the unit, it allows the motor to function at fixed speeds. On-board electronic printed circuit board for connection to It has a 230 V output for controlling a solenoid valve. 3-speed wall-mounted electromechanical thermostats. 1112 Connection diagram 230 V/50 Hz electrical power supply connection HRS Water temperature probe 10 kΩ for RS models Solenoid valve permission input Wiring for RS model...
  • Page 62 SpEEd SElECTOR COdE B3V137 112 On-board electronic board Code B4V642 + wall control Code B3V151 1121 Interface Wall mounted control with thermostat, summer/winter and speed selectors 1122 Description Wall mounted control with thermostat, summer/winter and speed selectors, in connection with B4V642II. For 2 pipe units For models with hydraulic connections on the right hand side, please refer to "Models with right-hand hy- draulic connections"...
  • Page 63 SpEEd SElECTOR COdE B3V137 1123 Connection diagram 230 V/50 Hz electrical power supply connection Full-flat connection (voltage output at 230 V/50 Hz 1 A) Solenoid valve permission input Water solenoid valve ( 230 V/50 Hz 1 A power output) HRS Water temperature probe 10 kΩ for RS models Maximum fan speed Medium fan speed Wiring for RS model Velocità minima ventilatore Fan motor DC Inverter Supersilent speed H4 H2...
  • Page 64 SpEEd SElECTOR COdE B3V137 1124 Connection diagram with seasonal switching 230 V/50 Hz electrical power supply connection Full-flat connection (voltage output at 230 V/50 Hz 1 A) Solenoid valve permission input Water solenoid valve ( 230 V/50 Hz 1 A power output) HRS Water temperature probe 10 kΩ for RS models Maximum fan speed Medium fan speed Wiring for RS model Velocità...
  • Page 65 SpEEd SElECTOR COdE B3V137 113 Connections 1131 Connection with 3 speed • minimum temperature in heating mode (30 °C) • maximum temperature in cooling mode (20 °C) thermostats Water probe connection to the control CV input In case of combination with electromechanical ther- TheCVinputistheON/OFFoftheboard.
  • Page 66 COnnECTIOn 0-10 V COdE B10642  C ONNECTION0-10VCODEB10642 121 Installation 1211 Description Motor regulation can be made through a 0-10 V analogue input with an input impedance of 25 kΩ. On-board electronic printed circuit board for control from systems with 0-10 V analogue output. Consider the impedance value, especially when con- Mounted on the unit, it allows the motor to be managed trolling several units in parallel.
  • Page 67 COnnECTIOn 0-10 V COdE B10642 For models with hydraulic connections on the right For full flat or radiant panel (RS) versions, please refer hand side, please refer to "Models with right-hand hy- to the "Version configurations" p.  15 section to make draulic connections" p. 15 to make the connections. the connections. 123 Connections with 0-10 V thermostats With the GRID input closed, the 10 V input •...
  • Page 68 InnOVA S.r.l. Via I Maggio 8 - 38089 Storo (Tn) - ITALY tel. +39.0465.670104 – fax +39.0465.674965 info@innovaenergie.com...
