IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE HOMEOWNER
SAVE THESE INSTRUCTIONS
SAFETY NOTICE
If this stove is not properly installed, a house re
may result. For your safety, follow the installation
instructions. Contact local building or re ofcials
about restrictions and installation inspection
requirements in your area.
Meets the U.S. Environmental Protection
Agency's May 2020 Particulate Emission
Standards.
Visit www.pacificenergy.net for the most recent version of this manual
030323-32
SERIAL #
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODELS:
ALDERLEA T5 LE INSERT
ALT5.INSERT LE
100003038

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALDERLEA T5 LE INSERT and is the answer not in the manual?

Questions and answers

Related Manuals for Pacific energy ALDERLEA T5 LE INSERT

Summary of Contents for Pacific energy ALDERLEA T5 LE INSERT

  • Page 1 Contact local building or re ofcials about restrictions and installation inspection requirements in your area. Meets the U.S. Environmental Protection Agency's May 2020 Particulate Emission Standards. MODELS: ALDERLEA T5 LE INSERT Visit www.pacificenergy.net for the most recent version of this manual 030323-32 ALT5.INSERT LE 100003038...

  • Page 2: Table Of Contents

    California to cause cancer, and to carbon monoxide, which is known to the state of California to cause birth defects or other reproductive harm. For more information go to www.p65warnings.ca.gov. This warning is applicable to all PACIFIC ENERGY FIREPLACE PRODUCTS ALT5 LE Insert 030323-32 100003038...

  • Page 3: Rating Label

    COMBUSTIBLE SOUS L’APPAREIL, S’ÉTENDANT À UNE DISTANCE DE 16po / 406mm DEVANT LE FACE D’OUVERTURE DU FOYER. CLEARANCE TO COMBUSTIBLES • INSTALL AND USE ONLY IN ACCORDANCE WITH PACIFIC ENERGY’S INSTALLATION AND OPERATING INSTRUCTIONS. • INSTALLEZ ET UTILISEZ SELON LES INSTRUCTIONS D’INSTALLATION ET D’UTILISATION DE •...

  • Page 4: Safety

    Safety CAUTION: Never use gasoline type lantern fuel, kerosene, charcoal lighter fluid or similar liquids to start or "freshen up" a fire in this heater. Keep all such liquids well away from the heater while it is in use. Instruct all members of your family on the safe operation of the heater. Ensure they have enough knowledge of the entire system if they are expected to operate it.

  • Page 5: To Avoid A Chimney Fire

    To Avoid a Chimney Fire 1. Burn wood cleanly. Do not burn wet wood or turn down the unit too quickly after loading. 2. Do not let creosote build up to a point where a chimney re is possible. 3. Do not have res in the heater that may ignite chimney res. These are excessively hot res, such as when burning household trash, cardboard, Christmas tree limbs, or even ordinary fuel wood;...

  • Page 6: Operation

    Operation CAUTION: Hot while in operation. Keep children, clothing and furniture away. Contact may cause skin burns. WARNING: Always keep loading door closed when burning. This heater is not designed for open door burning. WARNING: No alteration or modification of the combustion air control assembly is permitted. Any tampering will void warranty and could be very hazardous.

  • Page 7: Lighting A Fire

    Lighting a fire WARNING: Never use chemicals or any other volatile liquid to start a fire. Do not burn garbage, or flammable fluids such as gasoline, naptha, or engine oil. 1. Adjust air control to “High” position(all the way to the left) and open door. 2.

  • Page 8: Convection Blower Operation

    Convection Blower Operation The Insert comes equipped with twin variable speed circulating air blowers. The blower system is thermostatically controlled for automatic operation, as well as manually with a convenient bypass switch. Automatic Blower Operation: Allows the blowers to turn on automatically once the Insert has come up to operating temperature.

  • Page 9: Maintenance

    Maintenance WARNING: ONLY USE MATERIALS SUPPLIED BY MANUFACTURER WHEN DOING MAINTENANCE OR REPLACEMENTS. 1. If glass becomes darkened through slow burning or poor wood, it can readily be cleaned with replace glass cleaner when stove is cold. Never scrape with an object that might scratch the glass. The type and amount of deposit on the glass is a good indication of the ue pipe and chimney buildup.

  • Page 10: Maintenance Checks

    Maintenance Checks Check the following parts for damage such as cracks, excessive corrosion, burned out sections and excessive warping: (See website for descriptions and more detail) Weekly: • Firebrick - Visual, for cracking. • Door Gasket - sagging, placement, damage. Monthly •...

  • Page 11: Dimensions

    Dimensions 1/2 " 545mm 7/8 " 530mm " 430mm 1/2 " ” 1080mm 265mm ” 645mm ” Surround Heights 560mm Dimension Standard Oversized 1/4 " 7/8 " 3/8 " 1/8 " 210mm 455mm 770mm 865mm 3/4 " 1/8 " 3/8 " 5/8 "...

  • Page 12: Minimum Fireplace And Hearth Dimensions

    Minimum Fireplace and Hearth Dimensions ” 660mm ” 570mm ” 535mm ” 465mm ” Fireplace Hearth ” 406mm 200mm Figure 3: Fireplace opening dim. - ALT5 Insert LE. Hearth Requirements: The replace's non-combustible masonry hearth must extend 16” in front and 8” beyond each side of the existing replace opening.

  • Page 13: Ember Protection

    Ember Protection: Combustible ooring in front of the replace insert must be protected from hot embers by non-combustible material extending; • Canada - 18” to the ring side (From the Glass) and 8” to each side of the unit. • U.S.A.

  • Page 14: Clearances

    Clearances The minimum required clearances to surrounding combustible materials when installed into a masonry or factory built replace are listed below and in Figure 5. Mantel or Top Facing 12" 305mm 6” 155mm 10” 254mm e n t j a c Fireplace hearth Figure 5: Clearances - ALT 5 Insert LE.

  • Page 15: Installation

    Installation Your Insert is designed to be installed into a masonry wood burning replace. The masonry replace must be built according to the requirements of the Standard of Chimneys, Fireplaces, Vents and Solid Fuel Burning appliances, N.F.P.A. 211 (Latest Edition) or applicable National, Provincial, State or local codes. The installa- tion shall conform to CAN/CSA-B365, Installation Code for Solid-Fuel-Burning Appliances and Equipment.

  • Page 16: Full Flue Liner - (Required In Canada)

    Full Flue Liner - (Required in Canada) In Canada, this Fireplace Insert must be installed with a continuous chimney liner extending from the Fireplace Insert’s Flue Collar to the top of the chimney. The chimney liner must conform to the class 3 requirements of CAN/ULC-B365, Standard for Lining Systems for Existing Masonry or Factory-Built Chimneys and Vents, or CAN/ULC-S640, Standard for Lining Systems for New Masonry Chimneys.

  • Page 17: Direct Flue Connection (Permitted Only In The Usa)

    Direct Flue Connection (permitted only in the USA) Pacic Energy highly recommends the use of a full liner as the safest installation and providing optimum per- formance. When connected to a full liner, the Insert is able to draft correctly and will prevent problems such as difcult start-ups and smoking out the door.

  • Page 18: Into A Factory Built Fireplace

    Into a Factory Built Fireplace Your Insert may be installed into a factory built replace (size permitting) with the following requirements: 1. Inspect your replace for damage or other physical defects. The replace must be in good working condition. If in doubt about its condition, seek professional advice. Check for creosote build up or other obstructions inside the chimney, especially if it has not been in use for some time.

  • Page 19: Electrical Supply

    Electrical Supply Circulating air blower electrical rating; 115V, 60 Hz, 1.2 A. For your protection against shock hazard, use only a properly grounded outlet that will accept a three-pronged plug. Do not cut or remove the grounding prong. Do not route power cord under unit. Power cord must be routed to avoid contact with any hot or sharp surfaces.

  • Page 20: Surround Assembly And Installation

    Surround Assembly and Installation 1. Remove crate and plastic covering from the unit. Place the insert in a location that you can access the back of it to adjust the panels.l 2. Remove the Top (A) by lifting up. Caution: Support the Fan Shields (B) (Figure 11), they may fall.

  • Page 21: Air Inlet

    Air inlet Surround side Figure 15: Install surround to rebox. Figure 16: Installing fan shield. 6. Attach surround to rebox by angling the suround sides behind the ash shelf and in front of the mounting stud brackets. align the slots in the surround brackets with studs (L) then fasten with washers and nuts (M) on each side (Figure 15).

  • Page 22: Fan Speed Controller Relocation

    Fan Speed Controller Relocation The fan speed controller is factory installed under the ash lip on the right hand side. If required, it can be relocated to the left side by following the instructions below. To make this as easy as possible, it is suggested that this be done prior to tting the surround and installation into the replace: 1.

  • Page 23: Remove Screws

    Loosen ash lip bolts Remove screws and clips Figure 23: Ash lip bolts. Figure 24: Remove speed control screws and clips. 4. Loosen the two bolts that secure the ash lip to the rebox (Figure 23), carefully lift up the ash lip and remove from the rebox.
  • Page 24 Thermal snap switch Figure 29: Reconnecting fan wires. Figure 30: Re-attaching thermal snap switch. 9. Reconnect the wires to the fans (Figure 29) and re-attach thermal snap switch (Figure 30). Ret ash lip, sides and top. Ensure that the power cable is correctly routed through the surround and it is not touching the rebox side (Figure 31).

  • Page 25: Fan Removal/Installation

    Fan Removal/Installation 1. Remove Decorative Top and both Fan shields as specied in”Fan Speed Controller Relocation” on page 2. Disconnect fan wires as shown in Figure 32 from appropriate fan that is being replaced. Remove Thermal switch if needed (Figure 33). 3.

  • Page 26: Troubleshooting

    Troubleshooting Problem Cause Cure Excessive Creosote 1) Wood is too wet - Use dry wood Buildup Turning down air control - Do not turn down until: too soon a) there is a good bed of coals b) the wood is charred Draft too low - Improper chimney height and/or diameter - Chimney plugged or restricted, check ue...

  • Page 27: Firebrick Installation

    Firebrick Installation ITEM SIZE 18pcs. 9” x 4 1/2” x 1 1/4” (230 mm x 115 mm x 32 mm) 2pcs. 4 1/2” x 1 1/2” x 1 1/4” (115 mm x 38 mm x 32 mm) Figure 34: Bottom shield.(Part #80002585) 1.
  • Page 28 3. Place four bricks along the left hand wall. Insert the bricks and slide them forward, so that they are kept in place behind the rail tabs (Figure 38). Figure 36: Cover in place. Figure 35: Empty rebox. Figure 37: Floor bricks in place. Figure 38: Left wall bricks in place.
  • Page 29 This page is intentionally left blank. 100003038 ALT5 LE Insert 030323-32...

  • Page 30: Parts Diagram

    Parts Diagram (WHEN ORDERING, INCLUDE PART NUMBER WITH DESCRIPTION) ITEM DESCRIPTION PART NO. 1..Casting, ALT 5 Insert, Top, Painted ..................8 0000713 ..Casting, ALT 5 Insert, Top, Majolica Brown Enamel ..............8 0000060 ..Casting, ALT 5 Insert, Top, Antique White Enamel ..............8 0000058 2..
  • Page 31 Parts may be ordered from your nearest Pacic Energy dealer. Contact Pacic Energy for the location of the dealer nearest you. 100003038 ALT5 LE Insert 030323-32...
  • Page 32 © 2023 Copyright Pacic Energy Fireplace Products LTD. Reproduction, adaptation, or translation without prior written permission is prohibited except as allowed under the copyright laws. For technical support, please contact your retailer Web site: www.pacificenergy.net 2975 Allenby Rd., Duncan, BC V9l 6V8 Printed in Canada...
