Danfoss iC7 Series Operating Manual page 22

Encoder/Resolver Option OC7M0
Operating Guide
P 9.6.5 SSI Data Format
Description: Select the SSI data coding according to the specifications of the connected SSI encoder.
Default Value: 1 [Gray] (1)
Unit: –
1 In this release, the value Gray is preselected and cannot be changed.
4.9.4 Resolver (Menu Index 9.7)
P 9.7.1 Excitation Voltage
Description: Set the Excitation voltage according to the specifications of the connected resolver (RMS).
Default Value: 5
Unit: V
P 9.7.2 Excitation Frequency
Description: Set the Resolver excitation frequency according to the specifications of the connected resolver.
Default Value: 5000
Unit: Hz
P 9.7.3 Number of Poles
Description: Set the number of poles of the connected resolver.
Default Value: 2
Unit: –
22 | Danfoss A/S © 2022.02
Parameter Type: Selection
Data Type: BOOL
Parameter Type: Range (2–8)
Data Type: UINT
Parameter Type: Range (2000–20000)
Data Type: UINT
Parameter Type: Range (2–254)
Data Type: USINT
Encoder/Resolver Installation and
Parameter Number: 4034
Access Type: Read/Write
Parameter Number: 4005
Access Type: Read/Write
Parameter Number: 4004
Access Type: Read/Write
Parameter Number: 4003
Access Type: Read/Write
AQ390830267692en-0001 / 136R0273
Configuration
