Danfoss iC7 Series Operating Manual page 21

Encoder/Resolver Option OC7M0
Operating Guide
Default Value: 5
Unit: V
P 9.4.5 Supply Sense
Description: Activate power supply cable drop compensation.
Default Value: 0
Unit: –
4.9.2 Incremental Settings (Menu Index 9.5)
P 9.5.1 Resolution Channel 1
Description: Set the resolution of the incremental encoder connected to channel 1.
Default Value: 1024
Unit: –
P 9.5.2 Resolution Channel 2
Description: Set the resolution of the incremental encoder connected to channel 2.
Default Value: 1024
Unit: –
4.9.3 SSI/EnDat/BiSS/HIPERFACE Settings (Menu Index 9.6)
P 9.6.1 Resolution
Description: Number of bits used for one revolution.
Default Value: 13
Unit: –
P 9.6.2 Data Length
Description: Total number of bits used for position/angle + revolution count.
Default Value: 25
Unit: –
P 9.6.3 EnDat Clock Rate
Description: Set the Clock rate used for EnDat.
Default Value: 0 [8.33 MHz]
Unit: MHz
The following are the selections for the parameter:
Selection number
0
6
12
13
14
15
Danfoss A/S © 2022.02
Parameter Type: Range (3–24)
Data Type: UINT
Parameter Type: Range (0–1)
Data Type: BOOL
Parameter Type: Range (1–65535)
Data Type: UINT
Parameter Type: Range (1–65535)
Data Type: UINT
Parameter Type: Range (1–31)
Data Type: UINT
Parameter Type: Range (1–63)
Data Type: UINT
Parameter Type: Selection
Data Type: UINT
Encoder/Resolver Installation and
Parameter Number: 4002
Access Type: Read/Write
Parameter Number: 4035
Access Type: Read/Write
Parameter Number: 4008
Access Type: Read/Write
Parameter Number: 4009
Access Type: Read/Write
Parameter Number: 4010
Access Type: Read/Write
Parameter Number: 4011
Access Type: Read/Write
Parameter Number: 4036
Access Type: Read/Write
Selection name
8.33 MHz
4.16 MHz
2.08 MHz
1 MHz
0.2 MHz
0.1 MHz
AQ390830267692en-0001 / 136R0273 | 21
Configuration
