OPERATION
MANUAL
ERS-44-12G
SDI Routing Switcher
st
1
Edition- Rev.1
DM-1892-W2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ELETEX ERS-44-12G and is the answer not in the manual?

Questions and answers

Related Manuals for FOR-A ELETEX ERS-44-12G

Summary of Contents for FOR-A ELETEX ERS-44-12G

  • Page 1 DM-1892-W2 OPERATION MANUAL ERS-44-12G SDI Routing Switcher Edition- Rev.1...
  • Page 2 Edition Revision History Edit. Rev. Date Description Section/Page 2019/12/18 1st Edition SWF command value 3GA Switching Area correction 2020/2/21 5-2-1 1250~2140 → 625~1070...

  • Page 3: Important Safety Warnings

    Precautions Important Safety Warnings [Power] Operate unit only at the specified supply voltage. Caution Disconnect the power cord via the power plug only. Do not pull on the cable portion. Do not place or drop heavy or sharp-edged objects on the power cord. A damaged cord can cause fire or electrical shock hazards.
  • Page 4 [Circuitry Access] Do not remove covers, panels, casing, or access the circuitry with power applied to the unit. Turn the power off and disconnect the power cord prior to removal. Internal servicing / adjustment of unit should only be performed by qualified personnel. Do not touch any parts / circuitry with a high heat factor.

  • Page 5: Upon Receipt

    Upon Receipt ERS-44-12G units and their accessories are fully inspected and adjusted prior to shipment. Check your received items against the packing lists below. Check to ensure no damage has occurred during shipment. If damage has occurred, or items are missing, inform your supplier immediately. ...
  • Page 6 Installing the AC Cord Retention Clip Secure the AC cord with the supplied ladder strap/retention clip assembly to prevent accidental removal from the unit.  Installing the clip Wrap the retention clip around the AC cord (with the anchor of the ladder strap toward the unit.) Insert the anchor into the hole next to the AC IN socket.

  • Page 7: Table Of Contents

    Table of Contents 1. Prior to Starting ............................. 9 1-1. Overview ............................. 9 1-2. Features ............................9 1-3. About This Manual ........................9 2. Panel Descriptions ..........................10 2-1. Front Panel ..........................10 2-2. Rear Panel ..........................11 3. Connection ............................12 3-1. Basic Connection ........................12 4.
  • Page 8 8. Specifications and Dimensions ......................41 8-1. Unit Specifications ........................41 8-2. External Dimensions .........................42...

  • Page 9: Prior To Starting

    1. Prior to Starting 1-1. Overview The ERS-44-12G is a compact, high cost-performance 4:4 routing switcher that supports 12G/6G/3G/HD/SD-SDI and DVB-ASI streams in multiple bitrates. 1-2. Features  Multi-bitrate and multi-format support -Supports 12G/6G/3G/HD/SD-SDI. -SDI input signal auto-detection  DVB-ASI support ...

  • Page 10: Panel Descriptions

    2. Panel Descriptions 2-1. Front Panel POWER I / O CONF (PUSH) 2-6 : IN KEYLOCK POWER 1 POWER 2 (10) (11) POWER 1 Turns unit power ON / OFF. Normally turn both switches to ON to activate redundancy. POWER 2 Displays the POWER 1 and 2 states.

  • Page 11: Rear Panel

    2-2. Rear Panel OUT6 OUT5 OUT4 OUT3 OUT2 OUT1 REF IN THROUGH RS-232C GPIO (10) IN 1,2 Serial Digital video signal inputs. Serial Digital video signal inputs/outputs. The number of inputs and outputs varies depending on the setting. IN 3-6 / OUT 6-3 (See Sec.

  • Page 12: Connection

    3. Connection 3-1. Basic Connection Refer to the connection example below to connect ERS-44-12G and video and control devices. ◆ 4-input / 4-output Configuration Monitor Monitor Monitor Monitor Video signals (SDI) OUT6 OUT5 OUT4 OUT3 OUT2 OUT1 REF IN THROUGH RS-232C GPIO Reference (BB)

  • Page 13: Front Panel Operation

    4. Front Panel Operation This chapter explains how to switch crosspoints and configure inputs and outputs using front panel operation. 4-1. Operation Procedures 4-1-1. Enabling/Disabling Crosspoint Switching Hold down the KEYLOCK key for more than 2 seconds to toggle the lock On/Off. The key will light up in lock mode and crosspoint switches on the front panel are disabled.

  • Page 14: Crosspoint Switching

    4-1-3. Crosspoint Switching As factory default, the 4-input / 4-output configuration is applied and IN1 is assigned to all outputs, OUT 1-4.  Operations in 4-input / 4-output Configuration (1) Press an OUT key. (If the key is not lit, repress the key to turn on the key light.) (2) The IN key that routes to the OUT will light up.

  • Page 15: Features

    When all keys on the front panel blink, release these keys. The keys will flash six times and turn off to indicate that the GPIO assignments are reset. If the GPIO reset needs to be compatible with FOR-A DRS Series routers, use Mode-B. ...

  • Page 16: Blanking Switch

    5-2. Blanking Switch To switch signals within a vertical blanking period, all input signals must be synchronized with the system. Input an external reference signal. As factory default, crosspoints are switched within blanking periods in accordance with the reference signal timing (even if input signals have different clock rates).
  • Page 17 525/59.94i (BB) 625/50i (BB) 1080/60i 1080/ 59.94i 1080/ 50i 1080/30p 1080/29.97p 1080/25p 1080/ 24p 1080/ 23.98p 720/ 60p 720/ 59.94p 720/ 50p 720/ 30p 720/ 29.97p 720/ 25p 720/ 24p 720/ 23.98p 1080/24PsF 1080/23.98PsF As factory default, the switching point is set to the same format as that of the input signal (as indicated by REF in table cell fields).

  • Page 18: Remote Control

    6. Remote Control The ERS-44-12G can be controlled externally using an RS-232C or LAN interface. Serial commands can be sent via RS-232C or LAN (TCP/IP) and TELNET commands can be sent via LAN by establishing a terminal connection for each. In addition, the ERS-44-12G provides an SNMP agent and you will find the product-specific MIB file in the supplied CD-ROM.

  • Page 19: Rs-232C Connection Example

    6-1-2. RS-232C Connection Example ERS-44-12G Pin No. Signal Pin No. Signal Chassis Chassis Cable: 9-pin D-sub (female) to 9-pin D-sub (female) (Straight) IMPORTANT Use a straight-through cable. (The pin assignments and wiring methods may vary depending on the computer type.) DSR and DTR are connected inside the ERS-44-12G. 6-1-3.

  • Page 20: Lan Interface

    6-2. LAN Interface 6-2-1. LAN Communication Specifications  LAN interface Item Description Connector RJ-45 LAN interface Standard 100BASE-TX LAN Protocol TCP/IP LAN cable Category 5 or higher  Network settings Item Default setting Setting range IP address 192.168.0.100 1-223.0-255.0-255.0-255 Subnet mask 255.255.255.0 0-255.0-255.0-255.0-252 0-223.0-255.0-255.0-255...

  • Page 21: Serial Commands

    6-3. Serial Commands Commands can be typed and sent on a terminal emulator.  Command format [ASCII command string]<CR><LF> Both upper and lower case letters are supported. CR: ASCII code 13, LF: ASCII code 10 A space character is required between CMD and SUB_CMD, and SUB_CMD and PARAMETER.

  • Page 22: Command Examples

    Sets the SNMP output alarm trap On/Off. SUB_CMD: Specifies the output number. OUTA ON/OFF PARAMETER: ON: Trap On OFF: Trap Off (default for all) Turns KEYLOCK On/Off. SUB_CMD: ON/OFF ON: KEYLOCK On OFF: KEYLOCK Off (default) Requests the reference signal format status. Sets the SNMP reference alarm trap On/Off.
  • Page 23 "OUTA 1 ON" <CR><LF> (Command) Turn on the SNMP OUT 1 trap. OUTA "OUTA 1" <CR><LF> (Command) Send the SNMP OUT 1 trap status. "ON" <CR><LF> (Response) ON "LOC ON" <CR><LF> (Command) Turn on the KEYLOCK. "LOC OFF" <CR><LF> (Command) Turn off the KEYLOCK. "LOC"...

  • Page 24: Notes On Lan Interface Connection

    6-3-3. Notes on LAN Interface Connection  Set the network settings, IP Address, Subnet Mask, Default Gateway and TCP/UDP port number, according to your network environment.  Normally, if adding devices to an existing LAN, you need to consult a network administrator and set your devices in accordance with the LAN.

  • Page 25: Telnet

    6-4. TELNET The ERS-44-12G can receive setting commands through Telnet from a terminal emulator on a computer. 6-4-1. Communication Specifications  Communication Specifications Protocol Telnet (Teletype network) TCP port number Login User Name: "user" (fixed) Password: "user" (default) Command syntax [CMD]<SP>[SUB_CMD] <SP>...

  • Page 26: Commands Examples

    Requests the SNMP TRAP community name. Sets the SNMP TRAP community name using SNMP_TC SUB_CMD. Default value: trap Requests the SNMP trap status. SNMP_TR ON/OFF Turns On/Off the SNMP trap. Default value: OFF Requests an SNMP trap destination address. Four parameters Sets an SNMP trap destination address.
  • Page 27 (Command) Set the RS-232C baud rate to ”9600” bps. "BAU 9600" <CR><LF> "BAU" <CR><LF> (Command) Send the RS-232C baud rate. "9600" <CR><LF> (Response) 9600 bps "SNMP_PU abcd" <CR><LF> (Command) Set the SNMP GET community name to ”abcd.” SNMP_PU "SNMP_PU" <CR><LF> (Command) Send the SNMP GET community name.

  • Page 28: Snmp

    6-5. SNMP A user-supplied computer and SNMP manager are required for SNMP monitoring and control. Once the MIB file for ERS-44-12G is loaded to your SNMP manager, ERS-44-12G operational settings and error traps, as well as status monitoring are all available. SNMP traps can be sent to up to 4 destination IP address.

  • Page 29: Snmp Mib Parameter List

    6-5-3. SNMP MIB Parameter List 1.3.6.1.4.1.25386.1.1.2.2.2.1 Setting Parameter Description Setting Default 1.3.6.1.4.1.25386. fetERS4412G-Outp Selects an input for OUT 1. 1.1.2.2.2.1.1.0 ut1Select 1.3.6.1.4.1.25386. fetERS4412G-Outp Selects an input for OUT 2. 1.1.2.2.2.1.2.0 ut2Select 1.3.6.1.4.1.25386. fetERS4412G-Outp Selects an input for OUT 3. 1.1.2.2.2.1.3.0 ut3Select 1.3.6.1.4.1.25386.
  • Page 30 1.3.6.1.4.1.25386. fetERS4412G-Outp Turns On/Off OUT 5 signal ON/OFF 1.1.2.2.2.1.28.0 ut5CAlarm change alarm. 1.3.6.1.4.1.25386. fetERS4412G-Outp Turns On/Off OUT 6 signal ON/OFF 1.1.2.2.2.1.29.0 ut6CAlarm change alarm. 1.3.6.1.4.1.25386. Turns On/Off the Blanking fetERS4412G-Blank 1.1.2.2.2.1.30.0 switch format change ON/OFF ingFormatAlarm alarm. 1.3.6.1.4.1.25386. fetERS4412G-Salvo Sets the input of OUT 1. 0～6 1.1.2.2.2.1.31.0 1Setting...
  • Page 31 1.3.6.1.4.1.25386.1.1.2.2.2.2 Status Parameter Description Value 1.3.6.1.4.1.25386.1.1.2. OK/NG fetERS4412G-Power1S Power 1 status （NG=not good） 2.2.2.1.0 tatus 1.3.6.1.4.1.25386.1.1.2. OK/NG fetERS4412G-Power2S Power 2 status （NG= not good） 2.2.2.2.0 tatus 1.3.6.1.4.1.25386.1.1.2. OK/NG fetERS4412G-Input1St IN 1 status （NG= not good） 2.2.2.3.0 atus 1.3.6.1.4.1.25386.1.1.2. OK/NG fetERS4412G-Input2St IN 2 status （NG= not good）...
  • Page 32 1.3.6.1.4.1.25386.1.1.2.2.2.0 Trap Parameter Description Object to be tracked 1.3.6.1.4.1.25386.1.1.2. fetERS4412G-Power1C Power 1 status has fetERS4412G-Power1S 2.2.0.1.0 hanged changed. tatus 1.3.6.1.4.1.25386.1.1.2. fetERS4412G-Power2C Power 2 status has fetERS4412G-Power2S 2.2.0.2.0 hanged changed. tatus 1.3.6.1.4.1.25386.1.1.2. fetERS4412G-Input1Ch IN 1 status has fetERS4412G-Input1St 2.2.0.3.0 anged changed. atus 1.3.6.1.4.1.25386.1.1.2.

  • Page 33: Gpio Interface

    See Sec. 6-6-2. "Crosspoint List" for GPI input and Sec. 6-6-3. "Tally List" for GPI output. The Mode-B preset is a specific GPIO set compatible with FOR-A DRS Series routing switchers. This preset also uses 4:4 router mode. * If using an existing cable for GPIO connection, use the optional connector conversion harness.

  • Page 34: Crosspoint List

    Mode-A and Mode-B are different presets for GPIO pin assignments. Normally, it is recommended to use Mode-A. Mode-B is specific for FOR-A routers connection (compatible with GPIO of FOR-A DRS Series routers). A connector conversion harness (25-pin D-sub, 50 cm) is provided as an option. See Sec. 0.

  • Page 35: Tally List

    OUT4_IN2 Selects IN2 for OUT4. OUT4_IN3 Selects IN3 for OUT4. OUT4_IN4 Selects IN4 for OUT4. OUT5_IN1 Selects IN1 for OUT5. OUT5_IN2 Selects IN2 for OUT5. OUT5_IN3 Selects IN3 for OUT5. OUT6_IN1 Selects IN1 for OUT6. OUT6_IN2 Selects IN2 for OUT6. NONE Sets nothing.
  • Page 36 For the followings, tally is High while a condition is met. (To reverse the contact closure, add "N" after setting.) TOUT1_IN1 OUT1 outputs IN1. TOUT1_IN2 OUT1 outputs IN2. TOUT1_IN3 OUT1 outputs IN3. TOUT1_IN4 OUT1 outputs IN4. TOUT1_IN5 OUT1 outputs IN5. TOUT1_IN6 OUT1 outputs IN6.

  • Page 37: Gpio Pin Assignment (Other Router Mode)

    6-6-4. GPIO Pin Assignment (Other Router Mode) The following table shows GPI input and tally assignments examples of various router (input/output) modes. To assign functions to pins, see Sec. 6-4. “TELNET.”  D-shaped connector, 20-pin receptacle Router (Input : output) mode Pin name GPIO IN1 SW_OUT1...

  • Page 38: Gpio Circuit

    6-6-5. GPIO Circuit  GPIO Input circuit Photo-coupler input (Pulse control, Source current: approx. 7 mA, Duration: 50 ms or more) Contact closure example Open Collector example ERS-44-12G side ERS-44-12G side ※VCC = +5V ※VCC = +5V  GPIO Output circuit Open collector output (Max.

  • Page 39: Connector Conversion Harness Pin Assignment (Option)

    The maximum rating current for +5V DC is 300 mA. Although the circuit is protected from overcurrent, do not use it with excess current. NOTE Note that the harness is NOT equipped with a DC power input for GPI input. Refer to FOR-A DRS Series Routing Switcher Manual for more details.

  • Page 40: Troubleshooting

    7. Troubleshooting If any of the following problems occur while operating your ERS-44-12G, proceed as indicated below to see if the problem can be corrected before assuming a unit malfunction has occurred. Problem Check Action Unlock the KEYLOCK. Cannot operate the (See Sec.

  • Page 41: Specifications And Dimensions

    8. Specifications and Dimensions 8-1. Unit Specifications Input : Output 4:4 (shipped), 2:6, 3:5, 5:3, 6:2 (configurable) Signal input 800 mVp-p 75Ω BNC Signal output (Signals are compliant to one of following standards.) 12G-SDI: 11.88 Gbps, 11.88/1.001 Gbps (SMPTE ST 2082-1) 6G-SDI: 5.94 Gbps, 5.94/1.001 Gbps (SMPTE ST 2081-1) 3G-SDI: 2.97 Gbps, 2.97/1.001 Gbps (SMPTE ST 424) HD-SDI: 1.485 Gbps, 1.485/1.001Gbps (SMPTE ST 292-1)

  • Page 42: External Dimensions

    8-2. External Dimensions (All dimensions in mm)
  • Page 43  Dual-unit mount POWER POWER I / O CONF I / O CONF (PUSH) (PUSH) 2-6 : IN 2-6 : IN KEYLOCK KEYLOCK POWER 1 POWER 2 POWER 1 POWER 2  Single-unit mount POWER I / O CONF (PUSH) 2-6 : IN KEYLOCK POWER 1...
