Summary of Contents for HPE Instant On AP17
- Page 1 HPE Networking Instant On Access Point AP17 Installation Guide...
- Page 2 Hewlett Packard Enterprise Company. To obtain such source code, please check if the code is available in the HPE Software Center at https://myenterpriselicense.hpe.com/cwp-ui/software but, if not, send a written request for specific software version and product for which you want the open source code.
-
Page 3: Table Of Contents
Verifying Post-Installation Connectivity Safety and Regulatory Compliance Regulatory Model Name Brazil Canada European Union and United Kingdom Hong Kong India Japan Medical Mexico Morocco Oman Philippines Singapore Taiwan Ukraine United States HPE Networking Instant On Access Point AP17 | Installation Guide... -
Page 4: About This Guide
This document describes the hardware features of the HPE Networking Instant On Access Point AP17. It provides a detailed overview of the physical and performance characteristics of the HPE Networking Instant On Access Point AP17 and explains how to install the HPE Networking Instant On Access Point AP17. -
Page 5: Hardware Overview
Hardware Overview Hardware Overview HPE Networking Instant On Access Point AP17 supports IEEE 802.11ac standards for high- performance WLAN, and is equipped with two radios, which provide network access and monitor the network simultaneously. Multiple-in, Multiple-out (MIMO) technology allows the access point to deliver high-performance 802.11n 2.4 GHz and 802.11ac 5 GHz functionality, while also supporting 802.11a/b/g... -
Page 6: Hardware Overview
2. Alternating: one second each color, 2 second cycle. Reset Button The reset button can be used to reset the access point to factory default settings. There are two ways to reset the access point to factory default settings: HPE Networking Instant On Access Point AP17 |... -
Page 7: Ethernet Port
3. Release the reset button on the access point after 15 seconds. Ethernet Port The HPE Networking Instant On Access Point AP17 is equipped with one 10/100/1000Base-T auto- sensing, MDI/MDX Ethernet port (E0) for wired network connectivity. This port supports IEEE 802.3af... -
Page 8: Installation
(47 CFR 1.80). Identifying Specific Installation Locations The HPE Networking Instant On Access Point AP17 is designed in compliance with governmental requirements, so that only authorized network administrators can change configuration settings. For more information about AP configuration, refer to the Instant On User Guide. -
Page 9: Software
Access Point Installation Mounting the AP to a Solid Surface The HPE Networking Instant On Access Point AP17 ships with a mount bracket to mount the AP to a solid surface, such as a wall. To install the HPE Networking Instant On Access Point AP17 to a wall, follow these steps: 1. - Page 10 4. Slide the holder of the AP into the opening of the mount bracket, and use the two M6 x 20 screws included in the package to secure the AP to the mount bracket. Figure 3 Attaching AP to Mount Bracket HPE Networking Instant On Access Point AP17 | Installation Guide...
-
Page 11: Grounding The Ap
To connect the Ethernet cable to the access point, perform the following steps using the M20 cable gland. 1. Remove the dust cap from the Ethernet port. 2. Slide the sealing nut, clip, seals, gland body, and O-ring over the cable. HPE Networking Instant On Access Point AP17 |... -
Page 12: Verifying Post-Installation Connectivity
4-6 mm diameter, and the other is applicable for cables with 6-10 mm diameter. Verifying Post-Installation Connectivity The integrated LED on the access point can be used to verify that the access point is receiving power and initializing successfully . HPE Networking Instant On Access Point AP17 | Installation Guide... -
Page 13: Safety And Regulatory Compliance
Chapter 4 Safety and Regulatory Compliance Safety and Regulatory Compliance This chapter provides an overview of the HPE Networking Instant On Access Point AP17 safety and regulatory compliance information. Regulatory Model Name For the purpose of regulatory compliance certifications and identification, this product has been assigned a unique regulatory model number (RMN). -
Page 14: Eac
EU & UK Declaration of Conformity Compliance is only assured if the Hewlett Packard Enterprise approved accessories as listed in the HPE Networking Instant On Access Point AP17 data sheet are used. -
Page 15: Hong Kong
30 dBm 5725-5850 MHz 14 dBm Hong Kong India This product conforms to the relevant Essential Requirements of TEC, Department of Telecommunications, Ministry of Communications, Govt of India, New Delhi-110001 Japan HPE Networking Instant On Access Point AP17 | Installation Guide... -
Page 16: Medical
30 cm (12 inches) to any part of the access point. Otherwise, degradation of the performance of this equipment could result. This device has no IEC/EN60601-1-2 essential performance. Compliance is based on the use of Hewlett Packard Enterprise approved accessories. Refer to the HPE Networking Instant On Access Point AP17 data sheet. Mexico La operación de este equipo está... -
Page 17: Oman
CABINET OF MINISTERS OF UKRAINE dated May 24, 2017, No. 355. The full text of the UA declaration of conformity is available at the following internet address: https://certificates.ext.hpe.com/. Х’ЮЛЕТТ ПАКАРД ЕНТЕРПРАЗ, 6280 АМЕРИКА ЦЕНТР Д-Р, САН-ХОСЕ, КАЛІФОРНІЯ 95002, США HPE Networking Instant On Access Point AP17 | Installation Guide... -
Page 18: United States
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la conformité est susceptible d'annuler son droit d'utilisation. HPE Networking Instant On Access Point AP17 |...
