- Page 1 HPE Networking Instant On Access Point AP11 Installation Guide...
- Page 2 Hewlett Packard Enterprise Company. To obtain such source code, please check if the code is available in the HPE Software Center at https://myenterpriselicense.hpe.com/cwp-ui/software but, if not, send a written request for specific software version and product for which you want the open source code.
-
Page 3: Table Of Contents
Access Point Installation Verifying Post-Installation Connectivity Safety and Regulatory Compliance Regulatory Model Name Brazil Canada European Union and United Kingdom India Japan Medical Mexico Morocco Oman Philippines Singapore Taiwan Ukraine United States HPE Networking Instant On Access Point AP11 | Installation Guide... -
Page 4: About This Guide
This document describes the hardware features of the HPE Networking Instant On Access Point AP11. It provides a detailed overview of the physical and performance characteristics of the HPE Networking Instant On Access Point AP11 and explains how to install the HPE Networking Instant On Access Point AP11. -
Page 5: Hardware Overview
Hardware Overview Hardware Overview HPE Networking Instant On Access Point AP11 supports IEEE 802.11ac Wave 2, delivering high performance with 2x2 MU-MIMO (Multi-User Multiple-Input, Multiple-Output) technology, while also supporting 802.11a/b/g /n wireless services. The AP11 access point is designed for ceiling and wall mount. -
Page 6: Hardware Overview
The AP has detected a problem. Red- solid The AP has an issue - immediate action required. 1. Blinking: one second on, one second off, 2-seconds cycle. 2. Alternating: one second for each color, 2-second cycle. HPE Networking Instant On Access Point AP11 |... -
Page 7: Radio Status Led
Figure 2 Rear View Ethernet Port The HPE Networking Instant On Access Point AP11 is equipped with one 10/100/1000Base-T auto- sensing, MDI/MDX Ethernet port (E0) for wired network connectivity. This port supports IEEE 802.3af Power over Ethernet (PoE), accepting 48Vdc (nominal) as a standard defined Powered Device (PD) from a Power Sourcing Equipment (PSE) such as a PoE midspan injector, or network infrastructure that supports PoE. -
Page 8: Dc Power
The cable clips on the rear of the access point is used to organize Ethernet cable, as shown in the figure below. The use of the cable clips is optional and does not support all types of cables and plugs. HPE Networking Instant On Access Point AP11 |... - Page 9 Figure 4 Cable Clips HPE Networking Instant On Access Point AP11 | Installation Guide...
-
Page 10: Installation
(47 CFR 1.80). Identifying Specific Installation Locations The HPE Networking Instant On Access Point AP11 is designed in compliance with governmental requirements, so that only authorized network administrators can change configuration settings. For more information about AP configuration, refer to the Instant On User Guide. -
Page 11: Access Point Installation
Cordless headset such as those used in call centers or lunch rooms Access Point Installation The HPE Networking Instant On Access Point AP11 ships with the following two mount brackets. You can choose one of them to install the AP: A ceiling mount bracket (see Figure 5) to attach the AP to a 9/16”... - Page 12 30-degree angle to the ceiling rail. Make sure that any cable slack is above the ceiling tile. 5. Pushing toward the ceiling rail, rotate the access point clockwise until the it clicks into place on the ceiling rail. HPE Networking Instant On Access Point AP11 | Installation Guide...
- Page 13 Figure 7 Installing Access Point to 15/16" Ceiling Rail Figure 8 Installing Access Point to 9/16" Ceiling Rail HPE Networking Instant On Access Point AP11 |...
-
Page 14: Bracket-To-Solid Surface Option
4. Align the AP with the mount bracket, placing the AP so that it’s mounting tabs are at an angle of approximately 30 degrees to the mount bracket. 5. Pushing towards the solid surface, rotate the AP clockwise until it clicks into place. HPE Networking Instant On Access Point AP11 | Installation Guide... -
Page 15: Ap-To-Bracket Option
3. Install two screws (and wall anchors if necessary), one above the other. Do not fully insert the screws into the wall. Leave enough space between the screw head and the wall for the bracket. HPE Networking Instant On Access Point AP11 |... -
Page 16: Verifying Post-Installation Connectivity
Figure 13 Attaching AP to Wall Verifying Post-Installation Connectivity The integrated LED on the access point can be used to verify that the access point is receiving power and initializing successfully . HPE Networking Instant On Access Point AP11 | Installation Guide... -
Page 17: Safety And Regulatory Compliance
Chapter 4 Safety and Regulatory Compliance Safety and Regulatory Compliance This chapter provides an overview of the HPE Networking Instant On Access Point AP11 safety and regulatory compliance information. Regulatory Model Name For the purpose of regulatory compliance certifications and identification, this product has been assigned a unique regulatory model number (RMN). -
Page 18: Eac
EU & UK Declaration of Conformity Compliance is only assured if the Hewlett Packard Enterprise approved accessories as listed in the HPE Networking Instant On Access Point AP11 data sheet are used. -
Page 19: India
3. Wipe with a dry cloth, no additional maintenance required. 4. No serviceable parts, the unit must be sent back to the manufacturer for repair. 5. No modifications are allowed without approval from Hewlett Packard Enterprise. HPE Networking Instant On Access Point AP11 | Installation Guide... -
Page 20: Mexico
30 cm (12 inches) to any part of the access point. Otherwise, degradation of the performance of this equipment could result. This device has no IEC/EN60601-1-2 essential performance. Compliance is based on the use of Hewlett Packard Enterprise approved accessories. Refer to the HPE Networking Instant On Access Point AP11 data sheet. Mexico La operación de este equipo está... -
Page 21: Philippines
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or HPE Networking Instant On Access Point AP11 | Installation Guide... - Page 22 Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. Toute modification effectuée sur cet équipement sans l'autorisation expresse de la partie responsable de la conformité est susceptible d'annuler son droit d'utilisation. HPE Networking Instant On Access Point AP11 |...
