Ruijie RG-RAP73Pro Installation Manual page 11

Installation Guide
Table 1-3 Ports, Buttons, and Label on the Rear Panel
No. Item
1 DC power connector
2 Reset button
3 SFP+ port
4 LAN/2.5G/PoE port
5 Label
1.4 Technical Specifications
Table 1-4 Specifications
Radio Design
Wi-Fi Standards
Operating
Frequency Bands
Antenna Type
Spatial Streams
Max. Wi-Fi Speed
Modulation
Description
Supplies power to the AP, with a power supply specification of DC 54 V
Press and hold for less than 2 seconds: Restart the device.
Press and hold for more than 5 seconds: Restore the device to factory
settings.
1G/10G BASE-X SFP+ optical port (SFP+ optical transceiver module is
optional)
100/1000/2500 BASE-T port with auto-negotiation, supporting PoE input
The label is at the bottom of the device.
2.4 GHz: dual-stream
5 GHz and 6 GHz: tri-stream
IEEE 802.11be, IEEE 802.11ax, IEEE 802.11ac Wave 1 and Wave 2, and IEEE
802.11a/b/g/n
IEEE 802.11b/g/n/ax/be: 2.4 GHz to 2.4835 GHz
IEEE 802.11a/n/ac/ax/be: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725
GHz to 5.850 GHz
IEEE 802.11ax/be: 5.925 GHz to 7.125 GHz
Planar inverted-F antenna (PIFA) (2.4 GHz: 3.6 dBi; 5 GHz: 5.9 dBi; 6 GHz: 5.2 dBi)
2.4 GHz: two spatial streams, 2x2 MIMO
5 GHz: three spatial streams, 3x3 MIMO
6 GHz: three spatial streams, 3x3 MIMO
2.4 GHz: 688 Mbps
5 GHz: 4323 Mbps
6 GHz: 8646 Mbps
Combined: 13657 Mbps
OFDM: BPSK@6/9 Mbps, QPSK@12/18 Mbps, 16QAM@24 Mbps,
64QAM@48/54Mbps
DSSS: DBPSK@1 Mbps, DQPSK@2 Mbps, CCK@5.5/11 Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM, 4096QAM,
OFDMA
