HDMI Extender over single
50m/164ft UTP Cables with IR Control
LM-EX50
User manual
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or adjusting this product. Please keep this manual for future
reference.
Advertisement
Table of Contents
Related Manuals for LINK-MI LM-EX50
Summary of Contents for LINK-MI LM-EX50
-
Page 1: User Manual
HDMI Extender over single 50m/164ft UTP Cables with IR Control LM-EX50 User manual Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future... - Page 2 INTRODUCTION The HDMI Extender over Single Cat5e/6 with IR extends high definition video and audio signals and IR, at a distance of up to 164ft/50m over a single Cat5e/6 cable. Features EDID management, which allows and encourages source and display “handshake” for seamless integration. With only one cost effective Cat5e/6 cable, high definition sources with HDMI outputs can be connected to high definition displays with HDMI inputs over long distances.
- Page 3 SPECIFICATIONS Video Bandwidth: Single-link 165Mhz [ 4.95Gbps] Video Support: 480i/480p/720p/1080i/1080p @60 Audio Support: Surround Sound (up to 7.1 ch) or stereo digital audio Transmission Range: HD [1080p 24-bit color] – up to 50m [164ft] Input TMDS Signal: 3.3 volts Input DDC Signal: 5.0 volts/P-P ESD Protection: Human Body model: +/- 8 kV (air-gap discharge) +/- 4 kV (contact discharge) HDMI connector: Type A 19 pin female...
- Page 4 PANEL DESCRIPTIONS Transmitting unit ① HDMI out: This slot is to connect the HDMI input of your display such as an HDTV. ② EDID: The switcher can switch copy EDID fuction,switch to left position,the extender will copy hdmi loop out display EDID information to source.
- Page 5 Receiver unit ① EQ switcher: HDMI Receiver equalizer switcher. ② HDMI out: This slot is to connect the HDMI input port of your display such as an HDTV. ③ IR in: Connect to the IR Receiver for IR signal reception. Ensure that remote being used is within the direct line-of-sight of the IR receiver.
-
Page 6: Connection Diagram
Recommended EQ setting Position Cable Length under 15m (49.5ft) 15-30m (49.5 ft - 99ft) 30-40m (99ft - 132ft) 40-50m(132ft – 164ft) CONNECTION DIAGRAM... - Page 7 CONNECT AND OPERATE . Connect a source such as a Blu-Ray Player, game console, A/V Receiver, Cable or Satellite Receiver, etc. to the HDMI input on the Transmitting unit. 2. Connect a display such as an HDTV or HD Projector to the HDMI output on the Receiving unit.
- Page 8 IR BLASTER (TX) To control the source : Plug IR Blaster into IR TX port of transmitter unit; place blaster in front of the IR eye of the source. To control the display : Plug IR Blaster into IR TX port of receiver unit; place blaster in front of the IR eye of the display.
