EGR ROLLTRAC RT040036E Installation Instructions Manual page 6

Ø29mm (11/8")
ATTENTION
Ensure that the diameter of the hole does not exceed
Larger hole size will lead to water ingress
ATTENTION
Repeat for RHS
3
Mark the position of the rear drain tubes holes in the bed rear side panel, center punch and drill with
hole saw. LHS shown, repeat on the RHS.
(not supplied).
1
4
Feed the rear drain tube into the drilled hole. Guide the plastic tube inside the tail light cavity towards the ground.
Push the rubber tube in until seated firmly in the hole, see detail view. Repeat for RHS.
RT0090
ANTI RUST
Ø29mm (11/8")
into the bed
Clean all burrs and coat the exposed metal with a suitable rust preventative
2
INSIDE
INSIDE
Page 6 of 35
LHS
118mm (4.64")
483mm (19")
16
Ø29mm (11/8")
LHS
Issue 3: 04/09/24
