A
C
Figure 4-3. Air Filter Assembly
Service Spark Plug
To service spark plug:
1. See 4-5. Remove bolts (A) on con-
Figure
trol panel cover using a 10mm wrench.
A
Figure 4-4. Remove Screws
2. See Figure 4-5. Slide cover left and
remove to reveal the spark plug access
hole. (Do not disconnect any wires from
control panel cover.)
Figure 4-5. Spark Plug Access
3. Clean area around spark plug.
4. Remove and inspect spark plug.
5. See Figure 4-6. Inspect electrode gap with
wire feeler gauge and reset spark plug gap
to 0.04 in (1.01 mm).
Owner's Manual for Portable Generator
A
B
NOTE: Replace spark plug if electrodes are
pitted, burned or porcelain is cracked. Use
013788
ONLY recommended replacement plug. See
Specifications.
6. Install spark plug finger tight, and tighten
an additional 3/8 to 1/2 turn using spark
plug wrench.
Battery Replacement (if
applicable)
Accidental Start-up. Disconnect the negative battery
cable, then the positive battery cable when working
on unit. Failure to do so could result in death
or serious injury.
Environmental Hazard. Always recycle batteries at an
official recycling center in accordance with all local
laws and regulations. Failure to do so could result in
environmental damage, death, or serious injury.
014000
NOTE: The battery shipped with the generator
has been fully charged. A battery may lose
some charge when not in use for prolonged
periods of time.
See
Figure
1. Disconnect negative (-) battery terminal
FIRST (B).
2. Disconnect positive (+) battery terminal
SECOND (A).
B
014001
3. Install new battery. Install hold down
bracket and tighten.
4. Connect positive (+) battery terminal (A)
FIRST. Slide rubber boot over connection
hardware.
Figure 4-6. Spark Plug
WARNING
WARNING
4-7.
Figure 4-7. Battery Connection
000211
(000130)
(000228)
A
003482
