Remove Contents from Carton
1. Open carton completely by cutting the
shipping bands and lifting the carton off
the pallet.
2. Remove and verify carton contents prior to
assembly. Carton contents should contain
the following:
Accessories
Item
Main Unit
Owner's Manual
Liter Oil SAE 30
Handle (A)
Never-flat Wheel (B)
Axle (C)
Service Warranty
Emissions Warranty
10
Figure 2-10. Instruction Action Label
Figure 2-11. Instruction Badge
Qty.
1
1
2
2
2
1
1
1
Keys (set of 2)
Foot Bracket (D)
Foot Support Bracket (E)
Hardware Bag
Cotter Pin (F)
Large Washer (G)
Hex Head Bolt (M8-1.25 x 16) (H)
Flat Washer (J)
Hex Head Bolt (M8-1.25 x 30) (K)
Hex Head Bolt (M8-1.25 x 45) (L)
Flange Hex Nut (M8-1.25) (M)
Rubber Vibe Mount (N)
Snap-in Button (P)
Nylok Nut (M8-1.25) (Q)
Owner's Manual for Portable Generator
006681
011360
1
2
2
Qty.
2
4
2
2
2
10
8
2
2
2
