Fault Code Example
Fault code 6-1 is displayed by: 6 long blinks = 6, one second pause, 1 short blink = 1.
Fault Code
1-1 CO Monitor
1-2 Battery Voltage
1-3 Battery Voltage
5-2 Engine Speed
6-1 Engine Oil
Pressure
Other Multiple
Contact an IASD for full list of fault codes.
®
COsense
Carbon Monoxide (CO) Detection
and Shut-off System (if equipped)
The COsense module monitors for the accu-
mulation of poisonous CO gas found in engine
exhaust when the generator is running. If
COsense detects increasing levels of CO gas,
it automatically shuts off the engine. COsense
only monitors when the engine is running.
Generators are intended to be used outdoors,
far from occupied buildings and the exhaust
pointed away from personnel and buildings.
However, if mis-used and operated in a loca-
tion that results in the accumulation of CO, like
indoors or in a partially enclosed area,
COsense shuts off the engine, notifies the
user of what has happened and directs the
user to read the instruction action label for
steps to take. See Figure
a substitute for an indoor carbon monoxide
alarm.
See Figure 2-11. After a shut-off, a blinking
RED light in the COsense badge on the side
of the generator provides notification that the
generator was shut off due to an accumulating
CO hazard. The RED light will blink for at least
five minutes after a CO shut-off. Move the
generator to an open, outdoor area and point
the exhaust away from people and occupied
buildings. Once relocated to a safe area, the
generator can be restarted and the proper
electrical connections made to supply electri-
cal power. The RED light will stop blinking
automatically upon engine re-start. Introduce
fresh air and ventilate the location where the
generator had shut down.
Owner's Manual for Portable Generator
Cause
1. Carbon Monoxide above
limit.
2. Input voltage to module
below normal range.
1. Battery voltage above nor-
mal operating range.
1. Battery voltage below nor-
mal operating range.
1. No or low fuel.
2. Engine speed below nor-
mal operating range.
1. Low oil pressure.
2. Switch voltage not
detected.
1. Multiple
2-10. COsense is not
Condition
See
Figure
has occurred and no longer provides protec-
tion, the portable generator is shut off auto-
matically and the YELLOW light will blink for at
least five minutes in the COsense badge to
notify the user of the fault. The COsense mod-
ule can only be diagnosed and repaired by a
trained technician at the dealer. The generator
can be re-started, but may continue to shut-
off.
COsense will detect the accumulation of Car-
bon Monoxide from other fuel burning sources
such as engine powered tools or propane
heaters used in the area of operation. For
example, if another generator is used and the
exhaust is pointed at a COsense equipped
generator, COsense may initiate a shut-off
due to rising CO levels. This is not an error.
Hazardous Carbon Monoxide has been
detected. The user must take action to move
and re-direct these devices to better dissipate
Carbon Monoxide far away from personnel
and occupied buildings.
Correction
1. Move generator outside.
2. Contact IASD.
1. Contact IASD.
1. Charge battery to correct
level.
1. Fill fuel tank.
2. Contact IASD.
1. Fill crankcase to correct
level.
2. Contact IASD.
1. Contact IASD.
2-11. If a COsense system fault
