  • Page 1 Endurance Series User’s Manual minutemanups.com | 800.238.7272...
  • Page 2 Table of Contents Introduction Important Safety Warning 1-1. Transportation 1-2. Preparation 1-3. Installation 1-4. Operation 1-5. Maintenance, service and faults Installation and setup 2-1. Rear panel view 2-2. Operating principle 2-3. Install the UPS (Only for RT Models) 2-4. Setup the UPS 2-5.
  • Page 3 Veuillez lire ce manuel et vous conformer à tous les avertissements et instructions avant d'installer votre UPS Endurance Series car il fournit des informations importantes qui doivent être suivies lors de son installation et de sa maintenance, vous permettant de configurer correctement votre UPS pour une sécurité...
  • Page 4 Batteries can present a risk of electrical shock. Observe proper cautions and do not bridge the battery terminals at any time. Follow all precautions and instructions for battery replacement and disposal in the BATTERY REPLACEMENT section of this manual. 1. Important Safety Warning It is critical that the user strictly comply with all warnings and operating instructions in this manual.
  • Page 5 • The UPS features its own, internal current source (batteries). The UPS output receptacles may be electrically charged even if the UPS system is not connected to input power. • In order to fully disconnect the UPS system, first press the OFF/Enter button to disconnect input power then disconnect the internal batteries of the UPS.
  • Page 6 • When changing batteries, install the same number and same type of batteries or battery packs. Manufacturer Type Rated LIFE-247500 25.6 VDC, 7.5 Ah Voltronic Power LIFE-485000 48.0 VDC, 5.0 Ah LIFE-722500 76.8 VDC, 2.5 Ah • When necessary, replace the fuse only with the same type and amperage in order to avoid fire hazards.
  • Page 7 3000VA 1. Programmable outlets: connect to non-critical loads 2. Output receptacles: connect to mission-critical loads 3. AC input 4. Network/Fax/Modem surge protection 5. USB communication port 6. RS-232 communication port 7. SNMP intelligent slot 8. Emergency power off function connector (EPO) 9.
  • Page 8 2-3 Install the UPS (Only for RT Models) To prevent accidental discharge, the UPS is shipped with batteries disconnected from the UPS. Prior to installation of the UPS, follow the steps below to reconnect the battery wires. Step 1 Step 2 Step 3 Remove the front panel.
  • Page 9 2-4 Setup the UPS Read the instructions below to select the proper location to install the UPS. 1. The UPS should be placed on the flat and clean surface. Place it in an area away from vibration, dust, humidity, high temperature, flammable liquids, gases, corrosive and conductive contaminants.
  • Page 10 Step 2: UPS output connection There two types of output receptacles: Programmable receptacles and Always-On receptacles. Connect non-critical devices to the Programmable receptacles and critical devices to the Always- On receptacles. During a power failure event, the backup time to critical devices can be extended by programming the shutdown of non-critical devices.
  • Page 11 Step 5: Disable and enable EPO function This UPS is equipped with EPO function. The default setting for the UPS is with Pin 1 and pin 2 closed (a metal plate is connected to Pin 1 and Pin2) for UPS normal operation. To activate the EPO function, remove two screws on EPO port and metal plate can then be removed.
  • Page 12 NOTE 4 : During the replacement process, when the battery module is disconnected, the attached loads will not be protected from power outages. CAUTION!! Consider all warnings, cautions, and notes before replacing battery modules. Step 1 Step 2 Step 3 Remove front panel.
  • Page 13 3. Operations 3-1 Button operation Button Function  Turn on the UPS: Press and hold ON/MUTE button for at least 2 seconds to turn on the UPS.  Mute the alarm: While the UPS is operating in battery mode, press and hold the ON/MUTE button for at least 3 seconds to disable or enable the alarm ON/MUTE system.
  • Page 14 3-2 LCD Panel Display Function Backup time information Indicates the estimated backup time. H: hours, M: minute, S: second. Configuration and fault information Indicates the options available for configuration. (A full list of these options are listed in Section 3-5) Indicates the active warning and fault codes.
  • Page 15 Mode operation information Indicates the UPS is connected to nominal mains input power. Indicates the battery is actively providing output power. Indicates charging status Indicates the bypass circuit is active. Indicates the ECO mode is enabled. Indicates the AC to DC circuit is active. Indicates the PFC circuit is active.
  • Page 16 Battery Low Over Load Over input current Battery No Connect Over Charge Site wiring fault Temperature Charger Battery Fault Bypass Out Range Bypass frequency unstable Battery Replace EEPROM error 3-5 UPS Setting Parameter 1 Parameter 2 There are three parameter options for setting up the UPS.
  • Page 17 • B: ECO enable/disable Interface Setting Parameter 2: Enable or Disable the ECO function. ENA: ECO mode Enable DIS: ECO mode Disable (Default) • C: ECO voltage range setting Interface Setting Parameter 2: Adjusts the acceptable high voltage and low voltage points for ECO mode by pressing Down “...
  • Page 18 • E: Bypass voltage range setting Interface Setting Parameter 2: Sets the acceptable high and low voltage points for Bypass mode by pressing Down “ “ key or Up “ “ key. HLS: Allows for the adjustment of the Bypass high voltage point with a range of 120-140VAC.
  • Page 19 • I: Charger current setting Interface Setting Parameter 2: The current for the battery charger is set by the factory to 4Amps and is not configurable. The recharge time vs. charging current is listed in the table below (in hours): 1000VA 1500VA 2000VA...
  • Page 20 3-6 Operating Mode Description Operating Description LCD display mode Is active when input voltage is within an acceptable range. The UPS will provide pure and stable AC Online mode output power and will also actively charge the internal batteries. ECO mode is an energy saving mode: When the input voltage is within strict voltage regulation parameters, the UPS will bypass the ECO mode...
  • Page 21 3-7 Faults Reference Code Fault event Fault code Icon Fault event Fault code Icon Bus start fail Battery voltage too high Bus over Battery voltage too low Bus under Charger output short Inverter soft start fail Over temperature Inverter voltage high Overload Inverter voltage Low Charger failure...
  • Page 22 Battery voltage is too high or Contact your dealer display and the alarm is continuously the charger is faulty. Minuteman customer support. sounding. Fault code 28 is showing on the LCD Battery voltage is too low or the Contact your...
  • Page 23 If necessary, please contact your dealer or Minuteman customer support. Be sure to deliver any spent LiFePO4 (LiFe) batteries to a proper recycling facility or return it to your dealer, (or Minuteman), in the replacement battery packing material. minutemanups.com | 800.238.7272...
  • Page 24 Storage Before storing, the UPS charge the internal batteries for a minimum of 8 hours. Store the UPS covered and upright in a cool, dry location. During storage, recharge the battery in accordance with the following table: Storage Temperature Recharge Frequency Charging Duration 35°C ~ 45°C Every months...
  • Page 25 ≧96% ECO Mode@ full charged ≧87% ≧89% ≧89% ≧90% battery Battery Mode BATTERY Battery Type LIFE-247500 LIFE-485000 LIFE-722500 Numbers Recharge Time 2 hours recover to 100% capacity @ 4A charging current Charging Current 4A (Default) Charging Voltage 28 VDC ± 1% 52.5 VDC ±...
  • Page 26 7. Warranty Para Systems, Inc. (Para Systems) warrants this equipment, when properly applied and operated within specified conditions, against faulty materials or workmanship for a period of three years from the date of purchase. For equipment sites within the United States and Canada, this warranty covers depot repair or replacement of defective equipment at the discretion of Para Systems.
  • Page 27 Para Systems, Inc. 1455 LeMay Drive Carrollton, TX 75007 800.238.7272 www.minutemanups.com © 2024 PARA SYSTEMS, INC. Minuteman Power Technologies, Endeavor and SentryHD are owned by Para Systems, Inc. All other trademarks are property of their irrespective owners. minutemanups.com | 800.238.7272...
  • Page 28 3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-8, IEEE C62.41 Category A1, IEC62040-1-1, IEC/EN62040-2, UL1778 (5 Edition), CSA 22.2 no. 107.3-05, FCC Class A Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS) Manufacturer’s Address: 1455 LeMay Drive, Carrollton, Texas 75007 (USA) Type of Equipment: Uninterruptible Power Supplies (UPS)
  • Page 29 NOTES: minutemanups.com | 800.238.7272...
  • Page 30 minutemanups.com | 800.238.7272...
  • Page 31 34000571 RevA 202410 minutemanups.com | 800.238.7272...
