- Page 1 Enterprise Plus LCD RTXL UPS Series User's Manual Para Systems, Inc. 1455 Lemay Dr. Carrollton, TX 75007 Phone: 1-972-446-7363 Fax: 1-972-446-9011 Internet: minutemanups.com UPS Sizing: sizemyups.com PN - 34000431 R4...
- Page 2 Introduction Controls and Indicators Installation Operation Troubleshooting Replacing the Battery Obtaining Service Specifications Configurable Parameters & Settings Limited Product Warranty A1. Declaration of Conformity © Copyright 2013...
- Page 3 This symbol indicates "Equipment Grounding Conductor" CAUTION! Connect the UPS to a two pole, three wire, grounded AC wall outlet. The outlet must be connected to the appropriate branch protection (circuit breaker or fuse). Connection to any other Thank you for purchasing this power protection product. It has been designed type of outlet may result in a shock hazard and violate local electrical and manufactured to provide many years of trouble free service.
- Page 4 Receiving Inspection CAUTION! This UPS series is ONLY intended to be installed in an Once you receive the product it should be visually inspected for damage that indoor temperature controlled environment that is free of conductive may have occurred in shipping. Immediately notify the carrier and place of contaminants.
- Page 5 The Load Level Bar Graph operates as follows: LED #1: When the attached load is >20% the LED will illuminate. LED #2: When the attached load is >40% the LED will illuminate. LED #3: When the attached load is >60% the LED will illuminate. LED #4: When the attached load is >80% the LED will illuminate.
- Page 6 REAR PANEL INSTALLATION PLACEMENT This UPS series is ONLY intended to be installed in an indoor temperature controlled environment that is free of conductive contaminants. DO NOT oper- ate the UPS in: extremely dusty and/or unclean areas, locations near heating devices, water or excessive humidity, or where the UPS is exposed to direct 1.
- Page 7 NOTE: If you are using an External Battery Pack with this UPS series, CONNECTING THE BATTERIES (QUALIFIED SERVICE PERSONNEL ONLY) the UPS must be configured so that the UPS will report the correct Please read all of the WARNINGS and CAUTIONS before attempting to con- estimated runtime on the LCD screen and in the Power Monitoring soft- nect the batteries.
- Page 8 WALLMOUNT CONFIGURATION TOWER CONFIGURATION The wallmount configuration allows the user to mount the UPS on the wall. There is The tower configuration allows the user to install the UPS in the up-right position a wallmount bracket kit available for the UPS. The kit includes two wall mounting next to a tower computer.
- Page 9 CONNECTING YOUR EQUIPMENT COMMUNICATIONS PORT CONNECTION (OPTIONAL) Plug the equipment into the output receptacles on the rear panel of the UPS. The Power Monitoring Software and interface cables can be used with the Do not use extension cords, adapter plugs or surge strips on the output of the UPS.
- Page 10 The UPS will charge the batteries with the UPS in the on or off position as long DIPSWITCH SETTINGS as the UPS is plugged into the wall outlet and there is an acceptable AC voltage The dipswitch setting may be changed by the user to set the desired Inverter present (80 - 164VAC/150 - 271VAC).
- Page 11 OPTION SLOT The option slot on the rear panel of the UPS is for option cards. Contact your local dealer for the available option cards. RJ11 REPO (Remote Emergency Power Off) PORT Connect one end of the RJ11 cable to the REPO port and the other end of the RJ11 cable to the EPO switch.
- Page 12 Replace batteries with the same number and type as originally CAUTION: installed in the UPS. These batteries have pressure operated vents. These UPSs contain sealed non-spillable maintenance-free lead acid batteries. Model # E750RTXL2U E1500RTXL2U E2000RTXL2U E3000RTXL2U E1000RTXL2U E1500RTXLT2U E3000RTXLT2U REPLACING THE BATTERY Internal (QUALIFIED SERVICE PERSONNEL ONLY) Battery...
- Page 13 5. Mark the RMA # on the outside of all packages. The factory cannot accept any package without the RMA # marked on the outside. 6. Return the unit by insured, prepaid carrier to: Para Systems Inc. MINUTEMAN UPS 1809 W. Frankford Road, Suite 150 Carrollton, TX 75007 ATTN: RMA # _______...
- Page 14 BATTERY SYSTEM Battery Type Sealed, Non-Spillable, Maintenance Free, Value Regulated Lead Acid Typical Recharge Time 8-hours to 90% after full load discharge Typical Battery Life 3-5 years, depending on discharge cycles and ambient temp System Voltage 36VDC 72VDC Battery Module BM0029 BM0032 BM0029...
- Page 15 Para Systems, Inc. (Para Systems) warrants this equipment, when properly applied and (These items may require optional software or hardware) operated within specified conditions, against faulty materials or workmanship for a period of three years from the date of purchase. For equipment sites within the United States and User Choices Description Function...
- Page 16 Standard(s) to which Conformity is declared: EN61000-3-2, EN61000-3-3,EN62040-2, IEC61000-2-2 IEC61000-4-2, IEC61000-4-3, IEC61000-4-4, IEC61000-4-5, IEC61000-4-6, IEC61000-4-8, IEEE C62.41 Category A1 Manufacturer’s Name: Para Systems, Inc. (MINUTEMAN UPS) Manufacturer’s Address: 1455 LeMay Drive Carrollton, Texas 75007 USA Type of Equipment: Uninterruptible Power Supplies (UPS)
