BREAS: NIPPY4+
QUICK START GUIDE
CONNECT AND SET UP DEVICE
1
How do I connect the
ventilator?​ (Image A)
• Attach oxygen from wall or

cylinder via flowmeter to
Turn on and run device
before starting Oxygen flow
and turn off when not in
use.

• Connect power cable to
• Connect patient breathing

system to
• If exhalation valve
breathing circuit is used,
connect pressure tube to

Navigation system for setting controls (Image C)
3
Please see default settings labelled on the device.
In VCV the following parameters
can be controlled:
• Breath rate setting (BPM)
• Tidal volume
• EPAP setting (PEEP)
• Oxygen flow (via flowmeters)
(FiO2)
• Select parameter using
11
• Adjust and confirm using
13
This quick start guide has been developed by the NHS and Cabinet Office for the Ventilator Challenge programme and should be used in conjunction with the manufacturer's Instructions for Use
A
4
3
1
 
Oxygen inlet port
Exhalation valve control

pressure tube
Mains / DC electrical inlet

Air outlet
SET THE CONTROLS ON THE DEVICE
The following parameters can
be monitored:
On screen 14 :
Respiratory Rate; Vti/Vte; Circuit
leak; MVi/Mve; Peak pressure;
Peak flow
CATEGORY C/D: EMERGENCY & TRANSPORT / CPAP
How do I set up the
2
breathing system and the
HME filter? (Image B)
• Connect bacterial filter

outlet and attach tube
• For invasive VCV, connect

exhalation valve
valve control pressure tube
• For non-invasive CPAP use leak
circuit
• Connect HMEF / bacterial filter
2

to patient
 
Air outlet HMEF / bacterial filter
 
Bacterial filter Exhalation valve
 
Ventilation tube Leak
C
11
10
B
For invasive VCV - single
limb exhalation valve circuit

3
to air

4
to exhalation
5

For non-invasive CPAP -
4
5
13
14
12
8
6 7
single limb leak circuit
9
6 7
 Mode
10
 Treatment settings
11
 Menu
12
 Navigation buttons (+ / - / Set)
13
 Monitoring screen
14
