PV 101+/PV 102+ Service Manual
TABLE OF CONTENTS
1
INTRODUCTION............................................................................. 1-1
1.1
About the PV 101+ and PV 102+ ............................................................1-1
1.1.1
Intended use of the PV 101+ ................................................................ 1-1
1.1.2
Intended use of the PV 102+ ................................................................ 1-1
1.1.3
Design and function .............................................................................. 1-1
1.1.4
Service personnel's training requirements ............................................ 1-1
1.2
About this manual ...................................................................................1-2
1.2.1
Scope .................................................................................................... 1-2
1.2.2
Intended audience................................................................................. 1-2
1.2.3
Icons...................................................................................................... 1-2
2
MAINTENANCE SERVICE INSTRUCTIONS ................................. 2-1
2.1
Purpose of the maintenance ...................................................................2-1
2.2
Introduction .............................................................................................2-2
2.2.1
Service check schedule ........................................................................ 2-2
2.2.2
Safety precautions ................................................................................ 2-2
2.2.3
Service record ....................................................................................... 2-2
2.2.4
Inspection equipment and tools ............................................................ 2-3
2.2.5
Replacement parts ................................................................................ 2-3
2.3
Preparing inspection................................................................................2-4
2.3.1
Verifying the components and the installed software............................ 2-4
2.3.2
Initial recording...................................................................................... 2-4
2.3.3
Markings................................................................................................ 2-4
2.3.4
Information from the patient/user .......................................................... 2-4
2.3.5
Validity of the documentation ................................................................ 2-4
2.4
External inspection ..................................................................................2-5
2.4.1
Visual inspection for external damage and wear .................................. 2-5
2.4.2
Checking the power supply connection................................................. 2-5
2.4.3
Short function check.............................................................................. 2-5
2.5
Internal inspection ...................................................................................2-6
2.5.1
Opening the casing ............................................................................... 2-6
2.5.2
Cleaning the inside of the machine ....................................................... 2-6
2.5.3
Inspecting the internal wiring................................................................. 2-6
2.5.4
Securing the components ..................................................................... 2-6
2.5.5
Checking the power supply ................................................................... 2-6
2.5.6
Checking the electrical safety values .................................................... 2-6
2.5.7
Calibrating the pressure sensor ............................................................ 2-6
2.5.8
Calibrating the flow sensor.................................................................... 2-6
2.5.9
Calibrating the high pressure limit......................................................... 2-6
2.5.10 Reassembling the casing ...................................................................... 2-6
Doc. No. 003259 En
Issue: X-1
BREAS MEDICAL
TABLE OF CONTENTS
TOC - 1
Advertisement
Table of Contents
Related Manuals for Breas PV 102+
Summary of Contents for Breas PV 102+
-
Page 1: Table Of Contents
Checking the electrical safety values ............ 2–6 2.5.7 Calibrating the pressure sensor ............2–6 2.5.8 Calibrating the flow sensor..............2–6 2.5.9 Calibrating the high pressure limit............2–6 2.5.10 Reassembling the casing ..............2–6 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL TOC – 1... - Page 2 Part-number list – Blower unit and patient outlet ........5–10 5.3.4 Part-number list – Miscellaneous ............5–11 FUNCTIONAL DIAGRAMS ............6–1 Pneumatic diagram ................. 6–1 Functional block diagram ................ 6–2 TOC – 2 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
- Page 3 Fault-tracing table..................8–1 APPENDICES ................. 9–1 Engineering change history – PV 101+...........9–1 Engineering change history – PV 102+...........9–1 Service Record for BREAS PV 101+/PV 102+ Returning products to BREAS..............9–5 Service Report for BREAS PV 101+/PV 102+ Doc. No. 003259 En Issue: X-1 BREAS MEDICAL TOC –...
- Page 4 TABLE OF CONTENTS PV 101+/PV 102+ Service Manual 10 PV 101+ OPERATING MANUAL 11 PV 102+ OPERATING MANUAL TOC – 4 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
-
Page 5: Introduction
1.1.2 Intended use of the PV 102+ The BREAS PV 102+ device is intended for treatment of obstructive and central sleep apnoea, hypopnea and other forms of sleep-related breathing problems. The back-up rate is adjustable, as well as the rise time, which makes it possible to customise the time for the pressure to change from EPAP to IPAP. -
Page 6: About This Manual
BREAS Medical reserves the right to make changes to the products and/or the contents of this manual without any prior notice. 1.2.2... -
Page 7: Maintenance Service Instructions
• subjected to regular service, maintenance and control and any applicable upgrades, in accordance with BREAS service instructions; • repaired and/or modified in accordance with BREAS service manuals, technical bul- letins and any special service instructions, by service technicians that have been authorised after BREAS PV 101+/PV 102+ service training, or have an equivalent technical knowledge on medical respiratory devices. -
Page 8: Introduction
The PV 101+/PV 102+ Operating Manual contains an extended list of safety pre- cautions. 2.2.3 Service record See section 9, “APPENDICES” for the BREAS service record. • Copy the service record and use it for noting the service checks while performing the yearly service. -
Page 9: Inspection Equipment And Tools
• Test lung • Multimeter • Measuring equipment for pressure 0–70 mbar (Thommen HM 28 digital manometer is recommended, BREAS part no. 001934) • Flow meter • Screwdrivers TX10, TX25, Phillips 1 • Box socket wrenches M3, M4 •... -
Page 10: Preparing Inspection
Check that the documentation used by the patient is valid and up to date. Check if any modification or revision of the PV 101+/PV 102+ needs to be done at the same time as the service. 2–4 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 11: External Inspection
2 seconds before the device starts functioning normally. (PV 102+ only) Switch on the PV 102+ and wait for 15 seconds for the leakage alarm to be activated. Switch off the device. Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 2–5... -
Page 12: Internal Inspection
Calibrating the high pressure limit • For instructions, see section 4.6, “Calibrating the high pressure limit”. 2.5.10 Reassembling the casing • For instructions, see section 3.2, “Removing and reassembling the upper casing”. 2–6 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 13: Final Inspection Before Delivery
Adjust the pressure settings to: IPAP 10 mbar EPAP 10 mbar Measure the pressure and check that it is correct (tolerance: ±4% of the maximum value and ±8% of the current pressure value). Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 2–7... -
Page 14: Replacing The Filters
Checking the accessories Inspect the patient circuit. Replace it if necessary. Inspect any other accessories. 2.6.7 Adjusting the settings for the patient • Adjust all the patient settings to the prescribed values. 2–8 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 15: Removing/Replacing The Main Components
Before disassembling the PV 101+/PV 102+, make sure you have the following tools at hand: • Screwdriver TX10 • Screwdriver TX25 • Screwdriver Phillips 1 • Box socket wrench M4 • Box socket wrench M3 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 3–1... -
Page 16: Removing And Reassembling The Upper Casing
× TX25 Lift up the upper casing. Disconnect the CPU board’s ribbon cable from the MDA board. Put the upper casing aside. To reassemble the casing: • Reassemble in reverse order. 3–2 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 17: Removing And Replacing The Cpu Board
× TX10 To reassemble the CPU board: • Reassemble in reverse order. Fit the components to the holes for the display panel controls and screw the CPU board back in place. Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 3–3... -
Page 18: Removing And Reassembling The Main Assembly
Turn the PV 101+/PV 102+ upside down. Remove the M4 nut that fastens the blower unit rubber mount. Remove the five screws on the lower casing that hold the base plate. 1 × M4 Compound 5 × TX10 3–4 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... - Page 19 Press the rear panel side of the lower casing outwards to release the connectors and lift out the main assembly. To reassemble the main assembly: • Reassemble in reverse order. Make sure the connectors on the rear panel are properly fitted in their holes. Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 3–5...
-
Page 20: Removing And Replacing The Blower Unit
Remove the remaining two nuts that hold the blower unit’s rubber mounts from underneath the base plate. Lift away the complete blower unit. 2 × M4 Compound nut To reassemble the blower unit: • Reassemble in reverse order. 3–6 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 21: Removing And Replacing The Power Board
Pinch the two securing pins on the front part of the power board, e.g. by using a screwdriver, and lift up the power board from the base plate. 2 × Phillips 1 To reassemble the power board: • Reassemble in reverse order. Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 3–7... -
Page 22: Removing And Replacing The Mda Board
Lift up the MDA board from the base plate. 4 × T10 4 × M3 Compound 3 × T10 3 × M3 Compound nut To reassemble the MDA board: • Reassemble in reverse order. 3–8 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 23: Calibration Instructions
∅ • Screwdriver for the calibration screws ( 1 mm) Pressure calibration • Flow restrictor nipple 6 mm, BREAS part number 000997 • Flow restrictor nipple 5 mm, BREAS part number 003311 • Voltmeter • Syringe with a y-piece tube •... -
Page 24: Calibrating The Pressure Sensor
Repeat step 4 to 8 until no further adjustment is necessary. Remove the equipment. Continue with the pressure verification procedure (see section 4.4). P203 P204 Pressure sensor MDA board P204 Gain P203 Offset 4–2 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 25: Verifying The Pressure Calibration
If necessary, repeat the pressure calibration procedure (see section 4.3). Remove the equipment and reassemble the casing (see section 3.2). Pressure gauge mbar 5 mm leakage Plug Patient circuit Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 4–3... -
Page 26: Calibrating The Flow Sensor
Remove the air flow blockage. Repeat step 6 to 9 until no further adjustment is necessary. Remove the equipment and reassemble the casing. P201 P202 MDA board P202 Offset P201 Gain 4–4 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 27: Calibrating The High Pressure Limit
Adjust the screw on the P205 potentiometer on the MDA board until the pressure measured on the pressure gauge is 40 mbar (±1 mbar). Remove the equipment and reassemble the casing. P205 X202 MDA board P205 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 4–5... - Page 28 CALIBRATION INSTRUCTIONS PV 101+/PV 102+ Service Manual 4–6 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
-
Page 29: Parts Drawings And Part-Number Lists
This chapter contains enlarged drawings and part-number lists of the PV 101+/PV 102+. The main components of the device are displayed at the beginning of the chapter. Some of the listed parts can be ordered as replacement parts from BREAS. Please contact your BREAS supplier for more information. -
Page 30: Overview - Main Components
PARTS DRAWINGS AND PART-NUMBER LISTS PV 101+/PV 102+ Service Manual Overview – Main components 5–2 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... - Page 31 Blower unit, incl. motor Mounted on base plate Power board Mounted to bottom of base plate MDA board Mounted to rear of base plate Base plate In the lower casing Lower casing Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 5–3...
-
Page 32: Parts Drawings
PARTS DRAWINGS AND PART-NUMBER LISTS PV 101+/PV 102+ Service Manual Parts drawings 5–4 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 33: Parts Drawing - Upper And Lower Casing
PV 101+/PV 102+ Service Manual PARTS DRAWINGS AND PART-NUMBER LISTS 5.2.1 Parts drawing – Upper and lower casing For definitions of the part numbers, refer to the list in section 5.3.1. Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 5–5... -
Page 34: Parts Drawing - Main Assembly
PARTS DRAWINGS AND PART-NUMBER LISTS PV 101+/PV 102+ Service Manual 5.2.2 Parts drawing – Main assembly For definitions of the part numbers, refer to the list in section 5.3.2. 5–6 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 35: Parts Drawing - Blower Unit And Patient Air Outlet
PV 101+/PV 102+ Service Manual PARTS DRAWINGS AND PART-NUMBER LISTS 5.2.3 Parts drawing – Blower unit and patient air outlet For definitions of the part numbers, refer to the list in section 5.3.3. Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 5–7... -
Page 36: Part-Number Lists
Overlay, PV 102+ setting panel, German 003201 Overlay, PV 102+ setting panel, Finnish 003202 Overlay, PV 102+ setting panel, Spanish 003203 Overlay, PV 102+ setting panel, Italian 003204 Overlay, PV 102+ setting panel, Dutch 5–8 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 37: Part-Number List - Main Assembly
(Eribel part no) Spacer with securing pin, 10 mm 1310114 (Eribel part no) DSS M3050x10 Spacer 1360074 (Eribel part no) Base plate PV 101+/PV 102+ 1410006 Mains power fuse, 110–220V, 1A T 5x29 mm Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 5–9... -
Page 38: Part-Number List - Blower Unit And Patient Outlet
Blower casing outlet 22 mm 001117 Flow sensor AWM2100V 001122 Seal for upper blower casing 001245 Screw, RX-PT 4-20*6 fzb 001665 Shoulder screw M4 4,3 002966 Compound nut M4, PV 101+/PV 102+ 5–10 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 39: Part-Number List - Miscellaneous
PV 101+ Operating manual, English 002977 PV 101+ Operating manual, Norwegian 002978 PV 101+ Operating manual, Spanish 002979 PV 101+ Operating manual, Italian 002980 PV 101+ Operating manual, Dutch 002981 PV 101+ Operating manual, Danish Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 5–11... - Page 40 PV 101+ Operating manual, Japanese 003244 PV 102+ Operating manual, Japanese 003259 PV 101+/PV 102+ Service manual, English 003302 Fan control unit 003311 Flow restrictor nipple 5 mm 003312 Flow restrictor nipple 4 mm 5–12 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
-
Page 41: Functional Diagrams
Sensor 2 Sensor 1 Blue Green Black Description Patient air inlet (through air filter) Blower Motor Silencer Flow sensor (2) Pressure sensor (1) Honeycomb material Reference pressure tube Patient air tube Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 6–1... -
Page 42: Functional Block Diagram
FUNCTIONAL DIAGRAMS PV 101+/PV 102+ Service Manual Functional block diagram The block diagram below shows how the electronics are designed and how they are connected to the other components. 6–2 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 43: Electronics
ELECTRONICS This chapter describes in detail the electronics of the . It also contains PV 101+ PV 102+ circuit diagrams and component location drawings for the circuit boards of the machine. Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–1... -
Page 44: Electronics - Main Components
Electronics – Main components The electronics in the PV 101+ and the PV 102+ comprises a blower unit and three printed circuit boards: the CPU board, the power board and the MDA board. 7–2 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... - Page 45 Mounted to rear of base plate Hour counter Mounted to MDA board Analogue/digital Mounted to MDA board connection Battery connection Mounted to rear of MDA board Power connection Mounted to rear of base plate Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–3...
-
Page 46: Functional Block Diagram
PV 101+/PV 102+ Service Manual Functional block diagram The block diagram below shows on an overall level how the electronics are designed and how they are connected to the other components. 7–4 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 47: Internal Wiring Diagram
PV 101+/PV 102+ Service Manual ELECTRONICS Internal wiring diagram The wiring diagram displays the internal cabling and connections of the electronics. Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–5... -
Page 48: Circuit Board Descriptions
Refer also to the circuit diagrams (See section 7.6.6 and 7.6.7) and component location drawings (See section 7.7.2 and 7.7.3). The power supply has mains power as soon as the power cord is con- nected. 7–6 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 49: Mda Board
The signal is used for initiating the trigger and the mask-off function. Refer also to the circuit diagrams (See section 7.6.8, 7.6.9 and 7.6.10) and component location drawings (See section 7.7.4). Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–7... -
Page 50: Electrical Safety Measurements
Leakage currents with mains power supply at the patient connected part • Perform this test using an automatic electrical safety tester with this function. See the safety instructions for the tester. Limit value: < 5mA 7–8 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 51: Circuit Diagrams - Circuit Boards
PV 101+/PV 102+ Service Manual ELECTRONICS Circuit diagrams – Circuit boards Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–9... -
Page 52: Circuit Diagram - Cpu Board 1, Rev 2
ELECTRONICS PV 101+/PV 102+ Service Manual 7.6.1 Circuit diagram – CPU board 1, rev 2 7–10 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 53: Circuit Diagram - Cpu Board 2, Rev 2
PV 101+/PV 102+ Service Manual ELECTRONICS 7.6.2 Circuit diagram – CPU board 2, rev 2 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–11... -
Page 54: Circuit Diagram - Cpu Board 3, Rev 2
ELECTRONICS PV 101+/PV 102+ Service Manual 7.6.3 Circuit diagram – CPU board 3, rev 2 R150 R149 R148 R147 R146 R145 R144 7–12 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 55: Circuit Diagram - Cpu Board 4, Rev 2
PV 101+/PV 102+ Service Manual ELECTRONICS 7.6.4 Circuit diagram – CPU board 4, rev 2 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–13... -
Page 56: Circuit Diagram - Cpu Board 5, Rev 2
ELECTRONICS PV 101+/PV 102+ Service Manual 7.6.5 Circuit diagram – CPU board 5, rev 2 R182 R181 R180 R179 R178 R177 R176 7–14 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 57: Circuit Diagram - Power Board 1, Rev 3
PV 101+/PV 102+ Service Manual ELECTRONICS 7.6.6 Circuit diagram – Power board 1, rev 3 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–15... -
Page 58: Circuit Diagram - Power Board 2, Rev 3
OPTO_A 1000u/50V 100n 47u/6V 100n 470k 100k 680p 10u/20V BAS21 100k 100n BAS21 0R1/1W 0R1/1W 4n7/50V 47R/1W 4n7/50V 47R/1W BZX84C5V1 220p/400V 100n 220p/400V 220p/400V 220p/400V 100n 100R 100R 100u/50V DC_OUT 100n 7–16 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 59: Circuit Diagram - Mda Board 1, Rev 3
PV 101+/PV 102+ Service Manual ELECTRONICS 7.6.8 Circuit diagram – MDA board 1, rev 3 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–17... -
Page 60: Circuit Diagram - Mda Board 2, Rev 3
Circuit diagram – MDA board 2, rev 3 C282 100n C284 100n C283 100n R281 3,3k R310 R309 R227 C266 Monteras ej!!! C267 Monteras ej!!! C263 100nF C264 C214 C215 C262 100nF 100nF C265 100nF 7–18 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 61: Circuit Diagram - Mda Board 3, Rev 3
PV 101+/PV 102+ Service Manual ELECTRONICS 7.6.10 Circuit diagram – MDA board 3, rev 3 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–19... -
Page 62: Component Location Drawings - Circuit Boards
ELECTRONICS PV 101+/PV 102+ Service Manual Component location drawings – Circuit boards 7–20 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 63: Component Location Drawing - Cpu Board
LED102 LED103 LED100 LED101 R134 R111 R129 R110 Q100 R119 R131 R130 R112 C130 LD100 R109 R108 LD101 RN104 RN107 RN100 RN101 RN102 RN103 RN105 RN106 U109 2960 U111 C111 OK100 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–21... -
Page 64: Component Location Drawing - Power Board, Upper Side
ELECTRONICS PV 101+/PV 102+ Service Manual 7.7.2 Component location drawing – Power board, upper side For component lists, refer to section 7.8.2. 7–22 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 65: Component Location Drawing - Power Board, Under Side
PV 101+/PV 102+ Service Manual ELECTRONICS 7.7.3 Component location drawing – Power board, under side For component lists, refer to section 7.8.2. R101 R104 R102 R105 R100 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–23... -
Page 66: Component Location Drawing - Mda Board
ELECTRONICS PV 101+/PV 102+ Service Manual 7.7.4 Component location drawing – MDA board For component lists, refer to section 7.8.3. 7–24 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... -
Page 67: Component Lists - Circuit Boards
RESISTOR 20k 1% R144-150, 160-166 RESISTOR 10K 1% RN100-107 RN RESNET MNR34-J5AJ-471 U100 IC 24LC01 WSOITR U101 IC DS14C232CWM SO16W (232CB) U102 IC HD63C03YRF (U104) IC PLCC32 SMD U105 IC GAL16V8H-25SC/4 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–25... -
Page 68: Component List - Power Board
C24, 27, 32, 33 CAPACITOR 1000uF 50V C31, 50, 63, 64 CAPACITOR 220pF 500V C40, 42 CAPACITOR 680p NPO CAPACITOR 10u/20V C45, 46, 60, 61 CAPACITOR 4,7nF 500V XY CAPACITOR 100u/50V 7–26 BREAS MEDICAL Doc. No. 003259 En Issue: X-1... - Page 69 R1, 4, 5, 9, 10, 13, 20, RESISTOR 4k7 1% R2, 18 RESISTOR 3k3 1% R3, 27, 31 RESISTOR 8K2 1% R11, 12, 29 RESISTOR 1K5 1% VARISTOR S14K300 RESISTOR 15K 1% RESISTOR 470R 1% Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–27...
- Page 70 R82, 83 RESISTOR 0R1 0,6W R85, 86 RESISTOR 47R O,6W R88, 89 RESISTOR 100R 1% RESISTOR RXE185 / 3.5 A fuse (wire type) FUSE HOLDER Schurter 5x20m TRANSFORMER 12uH PLA10 TRANSFORMER ETD34-3F3 7–28 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
-
Page 71: Component List - Mda Board
C244 CAPACITOR 100uF/25V CV-GX C246 CAPACITOR 4,7uF/35V ELYT D55 C273 CAPACITOR 10uF/50V MVKF55 C282-284, 203, 204 CAPACITOR 100nF X7R D200, 202, 204, 209 DIODE BAS32 D203, 212, 213, 219 DIODE BAS85 Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–29... - Page 72 R220, 221 RESISTOR 24K9 R228, 231, 260, 271, 310 RESISTOR 2k2 1% R239 RESISTOR 100R 1% R240 RESISTOR 0,22R 3W AC03 R241-244 RESISTOR 4k7 1% R246, 247, 249, 250 RESISTOR 10k 1% 7–30 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
- Page 73 IC MC33035DW U208 IC NE555 U209, 212 IC LM358D U210 IC LM2597M-12 U213 IC LM317 VR202 SENSOR KTY81-220 X201 CONNECTOR ANGLED 8P X202 CONNECTOR 1x14POLE X203, 204 CONNECTOR 2P X205 CONNECTOR 8P Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 7–31...
- Page 74 ELECTRONICS PV 101+/PV 102+ Service Manual Reference Description Quantity X207 CONNECTOR ANGLED 2P 7–32 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
-
Page 75: Fault Tracing
• MDA board faulty. sensor. 2 Replace MDA board or flow sensor. Alarms for mask-off • Leakage from patient circuit/ • Check the tubes and mask 2.6.6 (PV 102+ only). mask. for leakage. Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 8–1... - Page 76 FAULT TRACING PV 101+PV 102+ Service Manual 8–2 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
-
Page 77: Appendices
(mandatory field A 3.5 A fuse (wire link type) has replaced the former PTC fuse, in upgrade from order to avoid risk of disturbances due to ambient temperature. R020296 to R230389) Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 9–1... - Page 78 APPENDICES PV 101+/PV 102+ Service Manual 9–2 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
-
Page 79: Service Record For Breas Pv 101+/Pv 102
PV 101+/PV 102+ Service Manual APPENDICES Service Record for BREAS PV 101+/PV 102+ Use a photocopy of this service record for the maintenance inspection described in chapter 2 in this service manual. Use the reverse side for comments and notes. - Page 80 Checking the accessories 2.6.6 ..Adjusting the settings for the patient 2.6.7 ..Notes ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
-
Page 81: Returning Products To Breas
APPENDICES Returning products to BREAS You may need to return the device or any components or accessories to BREAS, for example, for service, warranty, upgrade or repair. If so, follow the instructions below to ensure that the correct action is taken and to avoid unnecessary delays. - Page 82 APPENDICES PV 101+/PV 102+ Service Manual 9–6 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
-
Page 83: Service Report For Breas Pv 101+/Pv 102
PV 101+/PV 102+ Service Report for BREAS PV 101+/PV 102+ BREAS Ref. No:__________ Customer information Customer name:........................Customer address:.................................................... Phone:..........................Reference person:........................ Customer reference number: ....................Product information Model: ....... Serial No:......Operating hours: ......h Error /Complaint / Accessories ............................. - Page 84 PV 101+/PV 102+ Information from BREAS Date received by BREAS:...... Signature ........... Repair Warranty Update Charge Other Action taken: _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ Parts used: Pcs: Price: _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ _______________________________________________________________________ Operating hours from BREAS:_____________h Date returned to customer: ________________ Signature:____________________...
- Page 85 PV 101+/PV 102+ Service Manual APPENDICES Notes ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ Doc. No. 003259 En Issue: X-1 BREAS MEDICAL 9–9...
- Page 86 PV 101+/PV 102+ Service Manual Notes ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ ___________________________________________________________________ 9–10 BREAS MEDICAL Doc. No. 003259 En Issue: X-1...
- Page 87 PV 101+ OPERATING MANUAL BREAS MEDICAL...
- Page 88 BREAS MEDICAL...
- Page 89 PV 102+ OPERATING MANUAL BREAS MEDICAL...
- Page 90 BREAS MEDICAL...
Need help?
Do you have a question about the PV 102+ and is the answer not in the manual?
Questions and answers
