AK-10 Installation Guide
Part Names
SUNSHIELD BOLT
SUNSHIELD
DUAL WINDOW
FRONT CASE
Installation Instructions
1. Before installation, determine where the cables will be connected to the junction box.
2. Locate the mounting template at the installation position and drill the ceiling or wall.
3. Fix the junction box base with the mounting screws according to the location of the installation hole. (It is possible to
assemble by changing the mount cap and cable gland)
Mounting Screw:
4x30mm
Safety Rope
BRACKET
REAR CASE
Plastic Anchor:
6x30mm
Open Driver
(Mount Cap)
CABLE GLAND
MOUNT CAP
JUNCTION BOX
BASE, COVER
EN
