Summary of Contents for Eneo HDB-2080MIR
- Page 1 INSTALLATION AND OPERATION MANUAL HDB-2080MIR...
-
Page 2: Table Of Contents
Table of contents 1. Safety Instructions and Notes…....................... 2. General Descriptions................……………………………... 3. Supplied Items..................……………………………... 4. Part names…………………………….…...........…………………………... 5. Installation Instructions..................……………………... 6. Setup Menu ……………................…………………………... 7. Specifications ………………………………………………..............8. Dimensional Drawings ……………………………………………............ - Page 3 WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture. The symbol is intended to alert the user to the presence of important operating and maintenance(servicing) instructions in the literature accompanying the unit. The symbol is intended to alert the user to the presence of uninsulated "dangerous voltage"...
-
Page 4: Safety Instructions And Notes
1. Safety Instructions and Notes • Please read this safety and operating instructions before putting the camera into operation. • Keep the manual in a safe place for later reference. • Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in. - Page 5 • Smart Motion Zoom in combining with Pointing Zoom. • Scale down the image to 720p without loss of field of view • Top performance at low light sensitivity (Sense-up On) • Improved Noise figure with the enhanced 3D-NR • D-WDR, BLC/HLC, Digital Zoom(1.1x~8x) •...
-
Page 6: Supplied Items
3. Supplied Items • 1x Weatherproof Bullet camera • 1x Installation and Operating Instructions • 1x Mounting template • 1x ⓓ Sunshield panel with ⓐ Fixing screw for Sunshield panel • 1x Easy Bracket • 1x ①3mm Hex L-wrench • 4x ②anchors •... -
Page 7: Part Names
4. Part Names 4.1 Front view ⓓ ⓔ ⓐ ⓕ ⓖ ⓑ ⓗ ⓒ ⓘ ⓖ Sunshield panel ⓐ Fixing screw for Sunshield(x2) ⓓ Bracket Foot ⓗ Bracket Lock ⓑ IR LED ⓔ Foot mount Hole(x4) ⓘ OSD cover ⓒ Window ⓕ... -
Page 8: Installation Instructions
4.3 Easy Bracket ⓝ ⓝ Peg for Easy Bracket Hook(ⓛ) ⓞ Wall Mount hole(x4) ⓟ Bracket foot fixing hole(x4) ⓞ ⓟ CAUTION Easy Bracket can not be installed on the ceiling. When it is installed on the wall, ⓝPeg for Easy bracket Hook must be placed upwardly. 5. - Page 9 5.2. Power Supply Connections Camera can work with either 24AC or 12VDC, dual voltage power. It is strongly required the polarity-matched connection for 12VDC supply, otherwise IR LEDs will not operate at night. Primary and secondary grounds are completely isolated to avoid the possible ground-loop problems. In case that HD-SDI Inputs are not supported in Monitor, please use HD-SDI Converter to connect HD- SDI cable with Monitor.
- Page 10 5.3. Limit of pan and tilt 1. Pan limit Pan is limited to +/- 90°. 2. Tilt limit Tilt is limited to 0°(2°) min ~ 90° max. for wall(ceiling) installation respectively with reference to the ceiling when the inclination of camera module is 0°, that is, the image is aligned horizontally.
-
Page 11: Setup Menu
6. Setup Menu 6.1 Camera setup in the menu Setup menu can be accessed and controlled by OSD control joy stick on the side of camera. Five commands are available with the joy stick. The design of OSD could be different according to the Model. SYMBOL descriptions for joystick operation;... - Page 12 6.2 MAIN menu Press ● to enter the setup menu for about 1 second. ↵ MENU V3.07 1. EXPOSURE ↵ DC↵ 2. LENS 3. FOCUS ADJ. 4. SCENE ENHANCE NORMAL 5. 3D-NR ↵ 6. DAY/NIGHT AUTO↵ ↵ 7. PICT ADJUST ↵...
- Page 13 Enables to set OFF, LOW, MID and HIGH. 3D-NR is a very sophisticated and powerful time-based noise reduction technology by monitoring the noise for the several video frames and defining 3D-NR and eliminating them consecutively at low light. Higher setting reduces noise much more but results in losing the sharpness and the tail effect or the motion blur for the fast moving target at low light.
- Page 14 6.3 EXPOSURE EXPOSURE SHUTTER AUTO BRIGHTNESS |:::::::|::::::| 10 SENS-UP |::::::::|:::::| 12 RETURN RET↵ EXPOSURE Default Descriptions Can set EXPOSURE MODE to AUTO, MANUAL and Flickerless. AUTO – Optimizes the video level by controlling the iris and the shutter speed automatically. MANUAL –...
- Page 15 6.4 LENS MANUAL MODE OUTDOOR MODE DEBLUR RETURN RET↵ RETURN RET↵ Lens Default Descriptions Lens can be selected either DC or MANUAL lens. OURDOOR Lens MUST be set to DC for the best image when DC iris lens is installed. OUTDOOR DC or MANUAL- OUTDOOR, INDOOR, DEBLUR type...
- Page 16 6.5 FOCUS ADJ. Usually cameras are installed in the day time and FOCUS ADJ. they often become OUT OF FOCUS at night time and IN FOCUS again at next day time. This problem can occur at any cameras regardless of types or manufacturers. DN DWELL FOCUS ADJ.
- Page 17 6.7 PICT ADJUST PICTURE WHITE BAL |:::::::|::::::| 10 SHARPNESS COLOR GAIN |:::::::|::::::| 10 GAMMA 0.50 SHADING RETURN RET↵ PICTURE Default Descriptions ATW, ATWext, ONE PUSH and MANUAL are available for the white balance modes. ATW – White balance is continuously working along with the color temperature changes in the range of 2,000K~8,500K.
- Page 18 6.8 SPECIAL PICTURE MIRROR/FLIP PRIVACY MOTION ↵ PIXEL DEFECT ↵ TITLE SET DISPLAY DEFOG POINTING ZOOM RETURN RET↵ SPECIAL Default Descriptions Reverses the video left and right and/or up and down by MIRROR/FLIP. OFF - Normal display without mirroring or flipping Hor.
- Page 19 Detects and compensates the white pixels which becomes defective. Once CALIBRATE is selected, the pixel calibration is initiated with lens closed and can’t cancel. THRESHOLD – Defines the level of detection and low value detects more pixels. Be sure to set the value so that the pixels are uniformly blinking PIXEL DEFECT over the entire screen.
- Page 20 6.8.1 SMART MOTION ZOOM SMART MOTION ZOOM crops and enlarges the certain area defined by a yellow window to the full sized image when the motion is detected in the black window. SMART MOTION ZOOM window can be re-sized by adjusting D-ZOOM RATIO and moved by H-POINTER and V-POINTER.
- Page 21 6.8.2 POINTING ZOOM This camera has a very useful and powerful feature, POINTING ZOOM, which can zoom in/out any area. UNLIKE the conventional zoom which can zoom in/out the center area of image only, by the flexible zoom location and area, POINTING ZOOM differentiate its usefulness from others. That is, a conventional camera installed on the corner of ceiling can zoom the center of the floor in a room and result in losing the image of door on the side wall.
- Page 22 6.9 SYSTEM SYSTEM EU(PAL) TV SYSTEM ↵ 1080P RESOLUTION COMM. SETUP ENG☟ LANGUAGE FACTORY DEFAULT RETURN RET↵ SYSTEM Default Descriptions Selects HDTV standards for US(NTSC) or EU(PAL). TV SYSTEM By this selection, 2 analog video output switches to NTSC or PAL accordingly. 1080P and 720P are available.
-
Page 23: Specifications
. Specifications 207504 HDB-2080MIR Imaging Sensor Sony Exmor 1 / 2.9" Progressive Scan CMOS Sensor Effective Pixels 1,936(H) x 1,097(V) Min. Illumination 0.0005 Lux @ (AGC MAX, DSS x2) Output Video Resolution 1920x1080(30p/25p), 1280x720(30p/25p) TV system EU(50Hz)(switchable to US(60Hz)) Sync. System... -
Page 24: Dimensional Drawings
8. Dimensional Drawings (Unit: mm)
