PREPARING YOUR GRAPHIC CARD
STEP 1
REMOVING FACTORY PROVIDED BACKPLATE
Remove all encircled screws using Phillips screwdriver. All heat
sink assembly screws should be removed, including self-adhesive
washers on both sides of the PCB (if present).
STEP 1
STEP 2
REMOVING STOCK COOLER
Remove all encircled screws using Phillips screwdriver (4 springs)
and 4mm hex socket. All heat sink assembly screws should be
removed, including self-adhesive washers on both sides of the PCB
(if present). After you remove the housing do not forget to unplug
the fans.
STEP 2
