Ultimaker Factor 4 Repair Manual
Material station
Hide thumbs
Also See for Factor 4:
- Quick start manual (44 pages) ,
- Installation and user manual (28 pages) ,
- Repair manual (5 pages)
Advertisement
Quick Links
Repair manual
Material Station
The Material Station is an integrated part of the UltiMaker Factor 4 and is engineered as a complete sub-module.
The Material Station contains the interior assembly with material bays and interface, the prefeeders, and
electronics.
Although it is a complex assembly, removing the Material Station module is quick and simple. The entire system
can be taken out of the machine in minutes. When the Material Station needs repair work, this can be done
outside the printer for better access to components. In case of an issue, swap the complete Material Station for a
replacement module for minimal downtime.
Requirements
Level
•
Operator level:
ordinary, instructed, or skilled
•
Service level: 1
Notes
•
Some components must be disconnected. Turn off the printer and disconnect the power cable before
starting this procedure.
•
During this process, sensitive electronic components will be exposed. Make sure not to touch the mainboard
at the back of the printer, or take ESD measures just in case to prevent damaging the PCBA.
•
To remove the Material Station, you need at least 650 mm of clearance behind the printer.
•
If the printer must be moved or rotated to get access to the back and reach the required clearance, take the
appropriate safety precautions.
•
Before starting this procedure, prepare a surface to place the Material Station on after removal. The surface
must be flat, stable, and at least 550 x 300 mm.
•
Ensure that no materials are still loaded to the print head. For the greatest ease of use, remove all material
spools from the Material Station before starting.
Tip: With the UltiMaker Factor 4 Service plan, a hot swap service is included. Simply remove the old Material
Station module, install the replacement module, and place the old Material Station in the packaging that the
replacement came in for reduced downtime and quick return shipment.
UltiMaker Factor 4
Tools
•
Torx 20 screwdriver
•
Hex 2 mm screwdriver
•
Blue tape (optional)
•
Container for small parts
Repair manual – Material Station
Parts
•
70-228673
Material Station module
EN-V1.1-240523
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Ultimaker Factor 4
Summary of Contents for Ultimaker Factor 4
- Page 1 Repair manual Material Station The Material Station is an integrated part of the UltiMaker Factor 4 and is engineered as a complete sub-module. The Material Station contains the interior assembly with material bays and interface, the prefeeders, and electronics. Although it is a complex assembly, removing the Material Station module is quick and simple. The entire system can be taken out of the machine in minutes.
- Page 2 Factor 4 frame. Factor 4 frame, and place it on a stable surface. Tip: Keep the bolts somewhere safe so they do not get Note: Be aware of the weight of the Material Station when lost.
- Page 3 Use the Torx 20 screwdriver and the two M4x8 bolts Move the gray flatwire cable from the Material Station to secure the module to the brackets in the Factor 4 up through the right gap in the frame. Connect it to the frame.
- Page 4 11. Place the back cover panel Align the back panel with the printer. Use the Hex 2 screwdriver and the six M4x10 flathead bolts to secure it in place. Finished! UltiMaker Factor 4 Repair manual – Material Station EN-V1.1-240523...
- Page 5 Turn on the printer Reconnect the power cable at the back of the UltiMaker Factor 4 and turn on the printer with the power switch. Wait for the printer to finish booting up completely.
