HVAC System Compatibility
System Compatibility
The Nest Learning Thermostat (4th gen) works
with most 24V systems, including gas, electrical,
oil, forced air, heat pump, and radiant.
Heating: 1, 2 and 3 stages (W1, W2, W3)
Cooling: 1 and 2 stages (Y1, Y2)
Power (C, Rh, Rc)
Wire Terminals
● Y1 W1
●
● Y2 W2/AUX
●
● G ● C
● O/B *
●
● RC
Rh AQ+
● ●
AQ-
●
Networking Requirements
Wi-Fi is required for software updates and remote control with the
Google Home App
Wi-Fi 802.11 b/g/n, 2.4 GHz and 5GHz
Secure: AES-128, SSL/TLS, WEP, WPA/WPA2
(star)
For more information about compatible networks, visit this
link.
Fan (including multi-speed) (G or G1,G2,G3)
Humidifier, dehumidifier (HUM, DEHUM)
HRV, ERV, Exhaust Only, Supply ventilation
Heat pump: with auxiliary/alternate and
emergency heat (O/B, AUX, ALT, E)
HVAC System Compatibility
