- Page 2 CONTENTS 01/ Safety Instructions ....................2 02/ Technical Specifications ..................4 03/ Control Panel ......................6 04/ How To Set The Unit ....................7 4.1 Main Functions ....................7 4.2 Home Position Adjustment ................. 17 05/ Control By Universal DMX Controller .............. 19 5.1 DMX512 Connection ...................
- Page 3 01/ Safety Instructions Please read the instruction carefully which includes important information about the installation, usage and maintenance. WARNING Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction manual. Important: Damages caused by the disregard of this user manual are not subject to warranty.
- Page 4 DO NOT touch any wire during operation as there might be a hazard of electric shock. Avoid entanglement of the power cord with other wires. In the event of serious operating problem, stop using the unit immediately. Never turn on and off the unit time after time.
- Page 5 02/ Technical Specifications Power Voltage 100-240V~ 50/60Hz Power Consumption 255W G3FS587-U1208N273273 (WW) Light Source G3FS716-J1208N273273e (CW) G3FS1008-J1208 N273273e (NW) 3000K (WW) Color Temperature 5700K (CW) 4000K (NW) Zoom Range 10°-40° 0-100% smooth dimming; outstanding strobe effect with variable Dimmer/Strobe speed 540°...
- Page 6 Photometric Diagram: - 5 -...
- Page 7 03/ Control Panel 1. Display To show the various menus and the selected function MENU To enter into move backward or leave the menu UP To go backward to move up in the menu 2. Buttons DOWN To go forward to move down in the menu ENTER To perform the desired functions 3.
- Page 8 04/ How To Set The Unit 4.1 Main Functions To access the control menus, press the [MENU] button. Navigate the menu structure, using the [ENTER], [ UP] and [ DOWN] buttons. To select a menu option or to confirm a selection, press the [ENTER] button. ...
- Page 9 MENU SUBMENU OPTIONS Display Inverse Backlight Switch Display Setting Backlight Intensit 1-10 (Default=10) °C Temperature Unit °F English Language Chinese Auto Test 0-255 Pan Fine 0-255 Tilt 0-255 Tilt Fine 0-255 Fixture Test Manual Test P/T Sp. 0-255 Zoom 0-255 Dimmer 0-255 Dimmer Fine...
- Page 10 DMX Functions Enter the control menu and select DMX Functions, press ENTER. Use the UP/DOWN button to select DMX Address, DMX Channel Mode, DMX State or View DMX Value. DMX Address Select DMX Address, press ENTER. Use UP/DOWN button to select an address, confirm your selection with ENTER.
- Page 11 View DMX Value Select View DMX Value, press ENTER. Use UP/DOWN button to select the desired DMX channel, for which the value is to be displayed. To exit the menu, press MENU, or wait 30 seconds. Fixture Setting Enter the control menu and select Fixture Setting, press ENTER. Use the UP/DOWN button to select Pan Inverse, Tilt Inverse, P/T Feedback, Bl.
- Page 12 Bl. O. P/T Move Select Bl. O. P/T Move, press ENTER. Use UP/DOWN button to select No (blackout while pan/tilt move deactivated) or Yes (blackout while pan/tilt move activated), confirm your selection with ENTER. To exit the menu, press MENU, or wait 30 seconds. Dimmer Curve Select Dimmer Curve, press ENTER.
- Page 13 Display Setting Enter the control menu and select Display Setting, press ENTER. Use the UP/DOWN button to select Display Inverse, Backlight Switch, Backlight Intensity, Temperature Unit or Language. Display Inverse Select Display Inverse, press ENTER. Use UP/DOWN button to select No (display normal) or Yes (display inverted), confirm your selection with ENTER.
- Page 14 Fixture Test Enter the control menu and select Fixture Test, press ENTER. Use the UP/DOWN button to select Auto Test or Manual Test. Auto Test Select Auto Test, press ENTER. The device immediately performs an automatic self-test. To end the automatic self-test and exit the menu, press MENU, or wait 30 seconds.
- Page 15 Fan State Select Fan State, press ENTER. The fan status is displayed. To exit the menu, press MENU, or wait 30 seconds. USB Upgrade File Select USB Upgrade File, press ENTER. The device upgrade file is displayed. To exit the menu, press MENU, or wait 30 seconds. Firmware Version Select Firmware Version, press ENTER.
- Page 16 Select All, press ENTER. Use UP/DOWN button to select No or Yes (the device will run built-in program to reset all to their home positions), confirm your selection with ENTER. To exit the menu, press MENU, or wait 30 seconds. Special Functions Enter the control menu and select Special Functions, press ENTER.
- Page 17 RDM functions: Certain menus of the device and functions can be called up via the RDM protocol. The parameter IDs are implemented as follows for different commands: Command Command Command Parameter ID ‘Discovery’ ‘Set’ ‘Get’ DISC_UNIQUE_BRANCH √ DISC_MUTE √ DISC_UN_MUTE √...
- Page 18 4.2 Home Position Adjustment To access the control menus, press the [MENU] button. To access the offset menus, long-press the [ENTER] button. Navigate the offset menus, using the [ENTER], [ UP] and [ DOWN] buttons. To select a menu option or to confirm a selection, press the [ENTER] button. ...
- Page 19 Dimmer Select Dimmer, press ENTER. Use UP/DOWN button to select a value between 0 and 255, confirm your selection with ENTER. To exit the offset menu, press MENU, or wait 30 seconds. - 18 -...
- Page 20 05/ Control By Universal DMX Controller 5.1 DMX512 Connection 1. At last unit, the DMX cable has to be terminated with a terminator. Solder a 120-ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin XLR-plug and plug it in the DMX-output of the last unit.
- Page 21 5.2 Address Setting If you use a universal DMX controller to control the units, you have to set DMX address between 1 and 512 so that the units can receive DMX signal. Press the MENU button to access the control menus, select DMX Functions, press the ENTER button to confirm.
- Page 22 7 Channels (Mode 1): CHANNEL VALUE FUNCTION 000-255 0°540° TILT 0°200° 000-255 PAN/TILT SPEED 000-255 Fast to Slow ZOOM 000-255 WideNarrow DIMMER 000-255 0%100% 000-255 DIMMER FINE SPECIAL FUNCTION 000-069 Null 070-079 Blackout While Pan/Tilt Move Enable 080-089 Blackout While Pan/Tilt Move Disable 090-139 Null 140-149...
- Page 23 9 Channels (Mode 2): CHANNEL VALUE FUNCTION 000-255 0°540° 000-255 PAN FINE TILT 000-255 0°200° 000-255 TILT FINE PAN/TILT SPEED 000-255 Fast to Slow ZOOM 000-255 WideNarrow DIMMER 000-255 0%100% 000-255 DIMMER FINE SPECIAL FUNCTION 000-069 Null 070-079 Blackout While Pan/Tilt Move Enable 080-089 Blackout While Pan/Tilt Move Disable 090-139...
- Page 24 10 Channels (Mode 3): CHANNEL VALUE FUNCTION 000-255 0°540° 000-255 PAN FINE TILT 000-255 0°200° 000-255 TILT FINE PAN/TILT SPEED 000-255 Fast to Slow ZOOM 000-255 WideNarrow DIMMER 000-255 0%100% 000-255 DIMMER FINE STROBE 000-031 Close 032-063 Open 064-095 Strobe from Slow to Fast 096-127 Open 128-159...
- Page 25 06/ Troubleshooting Following are a few common problems that may occur during operation. Here are some suggestions for troubleshooting: A. The unit does not work, no light and the fan does not work Check the connected power. Measure the voltage. ...
- Page 26 07/ Fixture Cleaning It is absolutely essential that the fixture is kept clean to ensure the maximum light-output and allow the fixture to function reliably throughout its life. The fixture must be cleaned regularly to avoid dust, dirt and smoke-fluid residues building up on or within the fixture. The cleaning frequency depends on the application environment.
- Page 27 - 26 -...
