Specification
IEC 60825-1:2007
IEC 60825-2:A2/2010
Serial Port Specifications (Pinout RJ-45)
Pin
1
2
3
4
5
6
7
8
Serial Port Specifications (Protocol)
Parameter
Baud
Data bits
Parity
Flow control
Memory Specifications (Per CP Blade)
Memory
Main memory
Boot flash
Compact flash
Regulatory Compliance (EMC)
• 2014/30/EU
• AS/NZS CISPR 32 (Australia) (Class A)
Standards Approval
Pass
Signal
Not supported
Not supported
UART1_RXD
GND
GND
UART1_TXD
Not supported
Not supported
Value
9600
8
None
None
Note: Flow control is enabled on customer
terminal servers.
Type
DDR3 MiniDIMM
On-board NAND
eUSB
Description
The name and publication date of
the standard
Description
N/A
N/A
Receive data
Logic ground
Logic ground
Transmit data
N/A
N/A
Size
16 GB
4 MB
16 GB
Appendix A. Product specifications 213
