System Component
Media types
USB
Fabric services
Extension
FICON
Inter-chassis link (ICL)
Fibre Channel
System Component
Fibre Channel ports
Description
FC64-48 port blade: Supports IBM hot-pluggable 4x32Gb/s SWL QSFP+,
4x16Gb/s SWL QSFP+, 128Gb/s CWDM4 2 km QSFP28 for 4x32GbE
connectivity, 40GbE-QSFP+ for 40GBASE SR4 10GBASE 4x10GbE SR CNA
connectivity, 40GbE QSFP+ for bidirectional 40GbE SR CNA connectivity, and
100GbE QSFP28 for 4x25GbE SR4 CNA connectivity.
FC32-X7-48 port blade: Supports IBM hot-pluggable 32 Gb/s SWL/LWL/ELWL
SFP28, 16 Gb/s SWL SFP+ and 10 Gb/s SWL/LWL SFP
FC32-64 port blade: Supports IBM hot-pluggable 4x32Gb/s SWL QSFP+,
4x16Gb/s SWL QSFP+, 128Gb/s CWDM4 2 km QSFP28 for 4x32GbE
connectivity, 40GbE-QSFP+ for 40GBASE SR4 10GBASE 4x10GbE SR CNA
connectivity, 40GbE QSFP+ for bidirectional 40GbE SR CNA connectivity, and
100GbE QSFP28 for 4x25GbE SR4 CNA connectivity.
FC32-48 port blade: Supports IBM hot-pluggable 32Gb/s SWL/LWL/ELWL
SFP28, 16Gb/s SWL/LWL/ELWL SFP+, 10Gb/s SWL/LWL SFP.
SX6 extension blade: Supports hot-pluggable IBM 32Gb/s SWL/LWL SFP28,
16Gb/s SWL/LWL/ELWL SFP+, 10Gb/s SWL/LWL SFP, 1GbE copper SFP, 1GbE
1000Base-SX/LX/CWDM SFP, 10GbE SR/LR SFP+, 10GbE tunable DWDM 80-
km SFP+, and 40GbE SR4/LR4/ER4 QSFP.
CR64-4 and CR64-8 core routing blades: Supports IBM, hot-pluggable Gen 7
ICL SWL QSFP, 4x32 Gb/s SWL QSFP and 4x32 Gbp/ 2KM QSFP for ICL
connections. 16G QSSPs are not supported.
One USB port per control processor for firmware download, support save, and
configuration upload or download.
Adaptive Networking (Ingress Rate Limiting, Traffic Isolation, QoS); Advanced
Performance Monitoring; BB credit recovery; Advanced Zoning (default
zoning, port/WWN zoning, broadcast zoning); Dynamic Path Selection (DPS);
Extended Fabrics; Fabric Vision; FDMI; FICON CUP; Flow Vison; Frame
Redirection; FSPF; Integrated Routing; IPFC; ISL Trunking; Management
Server; N_Port Trunking; NPIV; NTP v3; Port Fencing; Registered State
Change Notification (RSCN); Reliable Commit Service (RCS); Simple Name
Server (SNS); syslog; Virtual Fabrics (logical switch, logical fabric); target-
driven zoning; peer zoning.
Supports DWDM, CWDM, and FC-SONET devices; Fibre Channel, in-flight
compression (LZO) BB credit recovery; Extension trunking, FICON Extension,
IP Extension, Adaptive Rate Limiting (ARL), data compression, Fast Write,
read/write Tape Pipelining, QoS.
FICON cascading; support for lossless DLS; FICON CUP; Advanced
Accelerator for FICON (IBM z/OS Global Mirror and read/write Tape
Pipelining). FICON connectivity is not supported on the FC32-64 blade.
Chassis-to-chassis linkage through connectors on the core routing (CR) blade.
Description
SAN256B-7 Director: Up to 192 64Gb/s or 256 32Gb/s ports, universal FC
(E_Port, EX_Port, F_Port, M_Port, D_Port, FICON) and Ethernet.
