CAUTION: If you do not install a module or a power supply in a slot, you must keep the slot filler
panel in place. If you run the chassis with an uncovered slot, the system will overheat.
CAUTION: Static electricity can damage the chassis and other electronic devices. To avoid
damage, keep static-sensitive devices in their static-protective packages until you are ready to
install them.
CAUTION: Before plugging a cable into any port, be sure to discharge the voltage stored on the
cable by touching the electrical contacts to ground surface.
CAUTION: To avoid damaging blade and chassis, do not push the blade into a slot or pull the blade
from a slot using the ejector handles.
Faulty core routing blade indicators
Confirm that you need to replace the blade before continuing. The following events may indicate that a
core routing blade is faulty:
• The status LED on the core switch blade is lit steady amber, or the power LED is not illuminated.
• The slotShow command does not show that the core switch blade is enabled.
• Any of the following messages display in errShow output or errShowAll output for root-capable
administrators:
– "Slot unknown" message relating to a core switch slot
– Core switch blade errors or I2C timeouts
– FRU: FRU_FAULTY messages for a core switch blade
– FAULTY (xx) with an associated code used by support
– Configuration loader messages or "Sys PCI config" messages
– Generic system driver messages ("FABSYS")
– Platform system driver messages ("Platform")
– EM messages that indicate a problem with a core switch blade
– Function fail messages for the core switch master
See Using Monitoring Commands and the Fabric OS Command Reference Manual for output examples and
additional information on Fabric OS commands.
For more information about error messages, refer to the Fabric OS Message Reference Manual.
Time and items required
The replacement procedure for the core switch blade takes approximately 30 minutes. The following
items are required to replace the core switch blade.
• Electrostatic discharge (ESD) grounding strap
• Workstation computer
• Replacement blade or filler panel
• No. 1 Phillips screwdriver
• QSFP transceivers (as needed)
• Optical cables (as needed)
Note: For information about the transceivers that are qualified for this Brocade device, see the Supported
Transceivers and Cables discussion in this guide.
Replacing a core routing blade
Use the following procedures in this section to replace routing blades:
