- Page 1 Laptop Extension Holder SKU:STAND-PM01A/STAND-PM01M Instruction Manual Assembly Video & Product Info Extension + Monitor | Extension Only | STAND-PMO1M STAND-PMO1A www.vivo-us.com/products/stand-pm01m www.vivo-us.com/products/stand-pm01a...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
- Page 3 Package Contents A (x1) B (x1) Monitor Holder Included Hardware & Tools S-B (x2) T-A (x1) S-A (x2) M5 Washer 3mm Allen Wrench M5x6mm Screw Weight Capacity: 2.2lbs (1kg)
- Page 4 Monitor Mounting Options Option 1: On Top of Laptop Pages 5-7 Option 2: To Right of Laptop Pages 8-11 Option 3: To Left of Laptop Pages 12-15...
- Page 5 ASSEMBLY STEPS Option 1 Monitor Mounted on Top of Laptop STEP 1 Attach Laptop Holder (A) to Leg (B) using M5x6mm Screws (S-A), M5 Washers (S-B), and 3mm Allen Wrench (T-A), using the holes shown below. Ensure Knob (B1) is oriented in the same direction as Thumbscrews (A1) STEP 2...
- Page 6 STEP 2 Cont’d Slide the Monitor Holder onto the top of your laptop making sure Leg (B) is on the bottom. Firmly re-tighten the bottom two Thumbscrew (A1). STEP 3 Tilt your laptop screen to your desired viewing angle. Loosen the Knob (B1) on Leg (B) and extend the Leg down to your desktop.
- Page 7 TIPOVER WARNING DO NOT ANGLE LEG INWARD LEG MUST EXTEND OUTWARD FOR STABILITY OF ASSEMBLY STEP 4 Insert your Monitor into the top of Monitor Holder (A). Firmly re-tighten the upper two Thumbscrews (A1).
- Page 8 Option 2 Right Side Mounted Monitor STEP 1 Attach Monitor Holder (A) to Leg (B) using M5x6mm Screws (S-A), M5 Washers (S-B), and 3mm Allen Wrench (T-A), using the holes shown below. Ensure Knob (B1) is oriented in the same direction as Thumbscrews (A1)
- Page 9 STEP 2 Loosen the four Thumbscrews (A1) on Monitor Holder (A). Slide the Monitor Holder onto the right of your laptop making sure Leg (B) is on the bottom.
- Page 10 STEP 2 Cont’d Firmly re-tighten the right two Thumbscrews (A1) onto your laptop. STEP 3 Tilt your laptop screen to your desired viewing angle. Loosen the Knob (B1) on Leg (B) and extend the Leg down to your desktop. Re-tighten the Knob.
- Page 11 TIPOVER WARNING DO NOT ANGLE LEG INWARD LEG MUST EXTEND OUTWARD FOR STABILITY OF ASSEMBLY STEP 4 Insert your Monitor into the right of Monitor Holder (A). Firmly re-tighten the remaining two Thumbscrews (A1).
- Page 12 Option 3 Left Side Mounted Monitor STEP 1 Attach Laptop Holder (A) to Leg (B) using M5x6mm Screws (S-A), M5 Washers (S-B), and 3mm Allen Wrench (T-A), using the holes shown below. Ensure Knob (B1) is oriented in the same direction as Thumbscrews (A1)
- Page 13 STEP 2 Loosen the four Thumbscrews (A1) on Monitor Holder (A). Slide the Monitor Holder left the top of your laptop making sure Leg (B) is on the bottom.
- Page 14 STEP 2 Cont’d Firmly re-tighten the left two Thumbscrews (A1) onto your laptop. STEP 3 Tilt your laptop screen to your desired viewing angle. Loosen the Knob (B1) on Leg (B) and extend the Leg down to your desktop. Re-tighten the Knob.
- Page 15 TIPOVER WARNING DO NOT ANGLE LEG INWARD LEG MUST EXTEND OUTWARD FOR STABILITY OF ASSEMBLY STEP 4 Insert your Monitor into the top of Monitor Holder (A). Firmly re-tighten the remaining two Thumbscrews (A1).
- Page 16 LAST UPDATED: 07/05/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
