- Page 1 Portable Monitor/Tablet Stand SKU: STAND-PMM1A Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/stand-pmm1a...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.
-
Page 3: Package Contents
Package Contents A (x1) B (x1) Base Mount Included Hardware & Tools S-A (x1) S-B (x2) M6x16mm M4x6mm Thumbscrew Flathead Screw Tools Needed: Weight Capacity: 3.3lbs (1.5kg) Phillips Screwdriver... -
Page 4: Assembly Steps
ASSEMBLY STEPS STEP 1 Unfold Base (A) and pull Post into upright position. Lock Post into its upright position using the M6x16mm Thumbscrew (S-A). -
Page 5: Assembly Options
STEP 2 Assembly Options: Option #1: Above Stand (8-12” Height) Install Mount (B) to Base (A) using the M4x6mm Flathead Screws (S-B) using the lower holes on bottom extension of Mount. Tighten with a Phillips screwdriver. Lower Holes NOTE: Make sure the bottom of Mount (B) is parallel to the desktop during installation. - Page 6 Assembly Options - Cont’d Option #2: Below Stand (2-6” Height) Install Mount (B) to Base (A) using the M4x6mm Flathead Screws (S-B) using the upper holes on Mount. Tighten with a Phillips screwdriver. Upper Holes NOTE: Make sure the bottom of Mount (B) is parallel to the desktop during installation.
- Page 7 STEP 3 Loosen the Adjustment Knob on the side of the Base Post to adjust the height of the stand. Once you’ve reached your desired height, tighten the Knob. Adjustment Post...
- Page 8 STEP 4 Set your monitor on the Mount. While holding onto the Mount with one hand, loosen the Adjustment Lever to make minor adjustments to the Mount angle, bringing it slightly forward if desired. Re-tighten Lever to lock angle in place. NOTE: If the monitor is not level after installation, remove monitor.
- Page 9 How to Use the Adjustment Lever The Adjustment Lever is designed for easy hand-tightening of joints without full 360 clearance with other tools. In some cases, the position of the Lever may need to be adjusted to ensure the joint is fully locked. 1.
- Page 10 Folding the Stand for On the Go Use Step 1: Lower the Stand Use the height adjustment knob to lower the stand to its lowest height setting. Step 2: Loosen Screw & Fold Post Forward Loosen the M6x16mm Thumbscrew and fold the Post down to a collapsed point.
- Page 11 Step 3: Loosen Lever & Knob & Fold Mount Loosen the Adjustment Lever and Secondary Knob, then fold the Mount portion under the base. Step 4: Re-tighten Lever Tighten the Adjustment Lever to secure stand in folded position.
-
Page 12: Last Updated
LAST UPDATED: 03/19/24 REV1 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
