3. Hold the splitting material with the two retaining
claws (6) on the operating arm on the right (4) and
the operating arm on the left (19). Make sure that
the log is placed centrally to the splitting wedge
(3).
4. Press down the control lever on the right (5) and
the control lever on the left (18) simultaneously.
5. Move the operating arm on the right (4) and the
operating arm on the left (19) approx. 2 cm away
from the splitting material as soon as the splitting
wedge (3) penetrates. This prevents damage to
the retaining claws (6).
6. Drive the splitting wedge (3) down until the log is
split.
7. If the log has not been completely split during the
first splitting stroke, proceed as described in sec-
tion 11.6.
11.5 Starting position log lifter (7) (Fig. 17, 17a)
Note
This is used as a second guard arm when not using
the trunk lifter.
1. Put the trunk lifter (7) in the resting position.
2. Secure the log lifter (7) with the log lifter lock (26).
11.6 Remove jammed log (Fig. 1)
Note:
Split through jammed wood using the swivel ta-
ble, knock it out against the splitting direction or
remove it by moving the splitting wedge upwards.
m ATTENTION!
Danger of injury!
The swivel table must engage in the locking hook!
m ATTENTION!
Danger of injury!
There is a danger of knotty logs becoming jammed dur-
ing the splitting process. Please note that the wood is
under a lot of tension when it is removed and parts of
your body can be crushed in the split crack.
- Do not reach into the log splitter when it is running.
- Do not put any objects into the log splitter while it is
running (e.g. hammer or similar).
1. If the log is not completely split during the first split-
ting stroke, carefully move the splitting wedge (3)
with the log to the upper position using the control
lever on the right (5) and the control lever on the
left (18).
48 | GB
2. Swivel in the swivel table (8) by foot until the lock-
ing hook (9) engages.
3. Now carry out a second splitting stroke until the
log is completely split.
4. Remove the log and swivel the swivel table (8)
away with your foot.
11.7 Restart protection in the event of a power fail-
ure (zero voltage trigger)
In the event of a power failure, unintentional removal
of the plug or a defective fuse, the device switches off
automatically.
To switch on again, proceed as described in section
10.5.
11.8 End of work (Fig. 1, 12)
1. Move the splitting column (2) to the bottom posi-
tion.
2. Release the control lever on the left (18).
3. Actuate the stop lever (21).
4. Switch off the motor (17) (see section 10.5) and
disconnect the mains plug.
5. Swivel in the swivel table (8) by foot until the lock-
ing hook (9) engages.
6. Close the bleed screw (15).
7. Protect the device from moisture!
8. Observe the general maintenance information.
12. Maintenance and repairs
m WARNING!
Danger of injury!
The device can start unexpectedly and cause injuries.
- Switch the motor off before performing any mainte-
nance work.
- Disconnect the mains plug before carrying out any
maintenance work.
m WARNING!
Health hazard!
Inhalation of oil vapours can cause serious damage to
health, unconsciousness and in extreme cases death.
- Do not inhale oil vapours.
- Operate the device outdoors only.
NOTE
Product damage
If the product is operated without or with too little hy-
draulic oil, this can lead to hydraulic pump damage.
