KTI Networks KGS-510F Datasheet

KGS-510F
Product Highlights :
Compact design

Web management

SFP Fiber support

802.1Q Tagged VLAN support

QoS WFQ support

Port link aggregation function

Port mirroring function

Web Smart 6-Port Gigabit Ethernet Switch
with 1 mini-GBIC Port
Key Features :
Provides 5 10/100/1000Mbps Gigabit Ethernet ports and 1 SFP port

Provides in-band web-based management interface

All copper ports support auto-negotiation and auto-MDI/MDI-X detection

Provides full wire speed forwarding

Supports 802.3x flow control for full-duplex and backpressure for half-duplex

Provides port status, statistic monitoring and control function

Supports port-based and 802.1Q Tag-based VLAN

Provides QoS function

Provides port link aggregation (trunking) function

Provides port mirroring function

Specifications :
Standard IEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1Q
Network Ports 5 10/100/1000Mbps Gigabit copper ports
Shielded RJ-45, auto-negotiation, auto-MDI/MDI-X support
1 1000Mbps Gigabit fiber SFP port
SFP supports standard SFP fiber transceiver installation
Network Cables 10/100Mbps : Cat.5 up to 100m,1000Mbps : Cat.5e or higher up to 100m
MAC Address Table 8K entries
Buffer Memory 112KB
VLAN Port based VLAN, 8021Q Tag-based VLAN
Port Link Aggregation Trunking groups : 2 max., Ports/group : 2
QoS 4 priority queues, Classification : Port-based, 802.1p, IP DSCP
LED Indication Per unit :
Per copper port :
SFP port :
Management Support Web browser software
Management Objects System settings, port status/statistics, port control, VLAN, QoS,
Link aggregation, port mirroring, Firmware upgrade
Environment Operating temperature : 0
Storage temperature :
Humidity :
Dimension 144 x 104.5 x 26 mm (WxDxH)
DC IN Jack Rating +7.5V/1A, Consumption 3.6W max. @7.5V
Approval FCC Class A, CE mark Class A
power
1000M,100M, 10M speed/link/activity status
1000M speed/link/activity status, Optical link status
O O
C ~40 C
O O
-20 C ~85 C
10%~90% non-condensing
080110
