Features
The ATF697FF evaluation board provides the following features:
On-board power supply circuitry
4 external power supply
On-board reset
ATF697FF module sample
On-board memories
Processor application memories : SDRAM, SRAM and parallel EEPROM
Reconfigurable unit configuration memory : Serial EEPROM
Configurable clocks
Status indicators
Power
ATF697FF Error, Boot, Run
DSU activity
Reset Board, processor, reconfigurable unit
Reconfigurable unit configuration specific press buttons
User interface
LCD display – 16 bits color – 240 x 320 pixels
5 press buttons
4 LEDs
1 potentiometer
Communication interface
1x RS-232 serial interface
2x CAN links
2x Space Wire ports
Test Facilities
2x 180 pins expansion connectors for additional mezzanine
3x 40 pins expansion connectors on the reconfigurable unit I/Os
1x 16 pins expansion connector for processor PIO
1 Debug Support Unit connector (DSU) for ATF697FF LEON2 SPARC processor
debugging
On board Space Programmer unit
ATF697FF Evaluation Board
Evaluation Board ATF697FF V2.1 [USER GUIDE]
ATF697FF
USER GUIDE
41002D – AERO 01/16

Advertisement

loading
Need help?

Need help?

Do you have a question about the ATF697FF and is the answer not in the manual?

Questions and answers

Summary of Contents for Atmel ATF697FF

  • Page 1 3x 40 pins expansion connectors on the reconfigurable unit I/Os  1x 16 pins expansion connector for processor PIO  1 Debug Support Unit connector (DSU) for ATF697FF LEON2 SPARC processor debugging  On board Space Programmer unit Evaluation Board ATF697FF V2.1 [USER GUIDE]...
  • Page 2 This document describes the evaluation board V2.1 dedicated to ATMEL ATF697FF configurable processor. The ATF697FF is a multi-chip module made of an ATMEL AT697F die together with an ATMEL ATF280F die. This allows extension of the 32-bit SPARC® V8 processor functionalities by adding a user dedicated area made of a 280 Kgate FPGA.
  • Page 3 Board display ..................34 2.13.4 Reconfigurable units dedicated press buttons ........35 2.14 UART interface....................35 2.14.1 Serial link 1 ..................35 2.14.2 Serial link 2 ..................36 2.15 CAN interface ....................37 Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 4 Clocks test points ................39 2.17.3 System test points ................40 2.18 Expansion connector ..................41 3. Appendix A – Space Programmer Update ........44 4. Revision History ................45 Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 5 Overview Figure 1-1 ATF697FF Evaluation board v2.1 Deliverables The ATF697FF evaluation board is delivered with:  1x LCD screen 240x320 pixel, 16bits color deep  6x Bumpers Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 6 1x Reconfigurable Unit reset LED 1x Processor reset LED 1x Reconfigurable Unit OTS press button 1x Reconfigurable Unit CHECKn press button 3x LEDs for ATF697FF board activity (run, boot, error). Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 7 Hardware description Block diagram Following figure gives an overview of specific modules connected with only one device of the ATF697FF: processor part or reconfigurable unit part. Figure 2-1 ATF697FF Evaluation Kit Processor and r econfigurable u nit diagram Processor user...
  • Page 8 Some evaluation kit features are connected to both processor and reconfigurable unit parts. Following diagram shows how these modules are arranged together. Figure 2-2 ATF697FF Evaluation Kit common parts diagram Reset management Serial EEPROM ATF697FF management monitoring I²C status ATF697FF...
  • Page 9 3V3 source selection Supply Resets 5V direct power HMI LEDs 5V source selection HMI buttons EXT power 8-12V FPGA Configuration 240x320 buttons switches Legend: Connector: Power: HMI: Board configuration: Memory: Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 10 SW20.4 Configure the processor as the master and reconfigurable unit as the slave SW20.5 Disable monitoring SW20.6 LCD display use serial connection SW20.7 N.C. SW20.8 N.C. SW20.9 N.C. SW20.10 N.C. Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 11 Power supplies sources With the default configuration, the ATF697FF Evaluation Kit shall be powered from the 2.1mm Jack connector with an 8V to 12V power supply source. A power supply source capable to deliver up to 10W shall be used (10W figure can be achieved when daughter boards are connected to the expansion connectors).
  • Page 12 2.4.2 Power supplies current measurement The ATF697FF Evaluation Board offers the possibility to have an overview of the power consumption of components. Current measurement test points are arranged according to the following drawing: Figure 2-5 Current probe footprint 2.54mm 2.54mm 2.54mm...
  • Page 13 Current and voltage test pads are accessible close to power supply regulations as shown in the following figures: Figure 2-8 Power supply indicators Processor pll (1,8V) PROC 1V8 FPGA 1V8 FPGA 3V3 Device 1V8 Board 1V8 Device 3V3 Board 3V3 Device 1V25 Board 5V Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 14 EEPROM SEREN A1 (AT17) PIO 6 LCD CS EEPROM SEREN A2 (AT17) PIO 7 ADC CS EEPROM SEREN B (AT69) PIO 8 HMI PB ENTER I2C DATA PIO 9 Reconfigurable unit reset control Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 15 SW20.5 should be “ON” to connect ERRORn (from processor) to IO763 (reconfigurable unit pin 115)  PIO3 should be “ON” to allow PIO11 to be connected to INIT (reconfigurable unit pin 294) Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 16 2.6.2.1 PROM Overview The ATF697FF processor is able to work with two bus widths: 8 bits or 32 bits. In both cases, the processor can use the EDAC mode. If EDAC is enabled on the PROM 32, the processor needs 8 more bits so total bus length is 40 bits in this case.
  • Page 17 Enabled IMPORTANT: PROM8 is not recognized by GRMON. The ATF697FF processor PROM bus width is configured at reset time according to PIO[1:0] value. Under reset the processor samples PIO[1:0] and reports its value to the memory configuration register MCFG1. Figure 2-12 PROM implantation...
  • Page 18 2.6.2.4 PROM Expansion The ATF697FF processor can control up to 512Mbytes of PROM. The evaluation board can handle up to 16M bytes of PROM code. For applications that need more PROM capacity, it is possible to extend the total PROM capacity by connecting a daughter board to the expansion connectors.
  • Page 19 Bottom side 2.6.3.3 RAM Expansion The ATF697FF processor can control up to 1Gb of SRAM and/or SDRAM. For applications that need more RAM capacity, it is possible to extend the total RAM capacity by connecting a daughter board to the expansion connectors.
  • Page 20 2.7.2 Memory organization overview Reconfigurable unit in master mode: The reconfigurable unit embedded in the ATF697FF requires up to 4Mbits memory for its configuration. The 4 Mbits of serial EEPROM memory are built around two space qualified devices:  Four cascaded AT17LV010 devices (1Mbit / device) ...
  • Page 21 PIO 12 B EEPROM selection SW8 PIO 2 B PIO 7 B DEMUX PIO 6 B PIO 5 B ATF697FF Processor Legend: ATF697FF I²C User interface switch Chip select Connector EEPROM ready Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 22 MEZZANINE SERIAL EEPROM 2.7.4 AT17 cascade Figure 2-17 AT17 cascade schematic [2] CS1 A2 = 1 [1] CS1 A2 = 0 [4] CS4 A2 = 1 [3] CS4 A2 = 0 Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 23 AT17 (3) connected to CS2_AT17 and with the A2 line driven to ‘GND’ shall be addressed,  to finish the AT17 (4) connected to CS2_AT17 and with the A2 line driven to ‘VDD’ shall be addressed. Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 24 Five clocks are created by an on board clock generator (CDCE925 circuit family). The circuit can be configured through different ways:  By the processor.  By the space programmer (the method is explained in appendix C). Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 25 SW19.3 OFF: SKEW0 disabled ON: SKEW0 enable SKEW 1 SW19.4 OFF: SKEW1 disabled ON: SKEW1 enable SW19.6 OFF: processor use on-board 25MHz clock ON: processor use Clock EXT IN 1 Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 26 Evaluation Kit Reset The following figure shows a general view of reset mechanism of the evaluation kit: Figure 2-19 Reset overview Note: reset signals are all active at low level. Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 27 PWR_1V8 Alternat reset Mezzanine connector Figure 2-21 Processor reset diagram ATF697FF Processor reset button Board reset Logical RESET Select Master [SW20.4 = OFF] Watchdog reset [SW19.5 = ON] IO259_LDC WDOG Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 28 By using SW37.5, it’s possible to connect processor Watchdog pin WDOG (pin 148) to the processor reset module. Table 2-12 Watchdog configuration Name Switch number Function Processor pin OFF: disconnect WDOG pin to reset module Watchdog SW19.5 ON: connect WDOG pin to reset module Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 29 (by detecting INIT signal low while CCLK is running) Otherwise, the led is OFF. The following flowchart describes the behavior of the internal signal which control the leds behavior. Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 30 A DSUBRE Press button to allow the user to put the processor in debug mode. The ATF697FF processor Debug Support Unit is based on a RS232 serial link connected to a host platform. The ATF697FF evaluation board includes all the required hardware to manage the RS232 communication and the debug facilities.
  • Page 31 Multi channels ADC 2.12 The ATF697FF evaluation board embeds 8 channels 12bits Analogue to Digital Converter from Analogue Devices: the AD7888. The device is connected to the processor and the reconfigurable unit through SPI connection as shows le following table:...
  • Page 32 ADC channel Sampled signal 3.3V Voltage supplying ATF697FF Consumed current by 3.3V by the ATF697FF 1.8V Voltage supplying ATF697FF Consumed current by 1.8V by the ATF697FF Voltage from SMB connector N.C. The current measurement is done through a 0.01 ohm resistor. Because the measured differential signal is very small, an amplifier used as non inverted differential boost the signal to allow good conversion of the ADC.
  • Page 33 Accessible through FPGA Accessible through Processor Table 2-17 LEDs mapping HMI device Processor connection Reconfigurable unit ATF697FF pin HMI_LED0 PIO0_A N.C. N.C. HMI_LED1 PIO1_A N.C. N.C. HMI_LED2 N.C. IO665 HMI_LED3 N.C. IO679 Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 34 IO537 HMI_LCD_D4 Data bus D4 IO553 HMI_LCD_D5 Data bus D5 IO563 HMI_LCD_D6 Data bus D6 IO567 HMI_LCD_D7 Data bus D7 IO573 (1): To use this function, PIO3 should be low Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 35 Figure 2-27 R econfigurable u nit button implementation UART interface 2.14 The ATF697FF evaluation board includes all the required hardware to manage a RS232 communication. Hardware flow control (CTS & RTS) are not implemented on this Evaluation Kit. 2.14.1 Serial link 1 Serial link 1 is available on the board through the UART 1 connector.
  • Page 36 Serial link 2 is available through the expansion connector only and is only 3.3V tolerant. If serial link 2 is connected to a RS232 interface on an expansion board, a line driver (like MAX3232) has to be implemented to adapt voltage. Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 37 CAN interface 2.15 The evaluation kit embeds two serial CAN links in one standard DB9 connector. An ATA6660-TAPY transceiver converts and adapts ATF697FF signals to standard CAN serial interface. Table 2-21 CAN ATF697FF mapping Serial link name Processor connection Reconfigurable unit...
  • Page 38 Function DIN+ SIN+ SOUT- DOUT- DIN- SOUT+ DOUT+ The SpaceWire interfaces are connected to the ATF697FF reconfigurable unit LVDS interface as defined in the following tables: Table 2-24 SPW1 assignment ATF697FF reconfigurable unit signals Signal name ATF697FF pin FPGA_ILVDSA1 DIN1+...
  • Page 39 Current measurement test points are arranged according to the following drawing: Figure 2-28 Press button implementation 2.54mm 2.54mm 2.54mm R shunt 0.01R B, C 2.17.2 Clocks test points Figure 2-29 Clock test points Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 40 2.17.3 System test points Figure 2-30 System test points ERRORn / CLK / BEXC FCKA / CCLK / GCK7 / D0 GCK3 GCK5 INIT FPGA test pad: Processor test pad: Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 41 IO677 IO669 IO759 IO763 FPGA_RESETn INIT IO671 IO673 IO765 IO767 IO677 IO683 IO771 IO777 CS0n IO685 IO687 IO779 IO783 IO265_HDC IO691 IO693 IO785 IO787 EEPROM_SEREN IO259_LDC IO697 IO703 IO791 IO793 Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 42 HMI_LED1 BOARD_5V N.C. RWE2 HMI_LED2 N.C. RWE3 HMI_LED3 PROM_WIDHT_SEL SDCLK BEXC SELECT_MASTER SDRAS BRDY ALTERNATE_RESET SDCAS PB_RESET_PROC SDWE N.C. SDDQM0 HMI_PB_ENTER SDDQM1 HMI_PB_DOWN SDDQM2 HMI_PB_UP SDDQM3 HMI_PB_RIGHT SDCS0 HMI_PB_LEFT SDCS1 Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 43 35.6mm 71.2mm Diam. 2.7mm 102.7mm Figure 32 Expansion connector mechanical drawing Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 44 Appendix A – Space Programmer Update See troubleshooting document (41044B) if a space programmer firmware update is needed. Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
  • Page 45 Table 4-1 Board history Version Comments 41002A Release with Board V1.2 41002B Release with Board V2.1.1 41002C Add section to update Space Programmer firmware 41002D Add section for led Run, boot & fail Evaluation Board ATF697FF V2.1 [USER GUIDE] 41002D – AERO 01/16...
