STX2 & XTA 10 Series
Portable Grain Auger
Operator's Manual
This manual applies to:
AGI Westfield STX2 10 (61)
AGI XTA 10 (61)
AGI Hutchinson STX2 10 (61)
AGI Mayrath STX2 10 (61)
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
LOOKING FOR PARTS?
Check out our online
Parts Catalog!
Part Number: 31137 R2
Revised: November 2024
Original Instructions

Advertisement

loading
Need help?

Need help?

Do you have a question about the STX2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AGI STX2 Series

  • Page 1 STX2 & XTA 10 Series Portable Grain Auger Operator’s Manual This manual applies to: AGI Westfield STX2 10 (61) AGI XTA 10 (61) AGI Hutchinson STX2 10 (61) AGI Mayrath STX2 10 (61) LOOKING FOR PARTS? Check out our online Parts Catalog! Read this manual before using product.
  • Page 2 This product has been designed and manufactured to meet general engineering standards. Other local regulations may apply and must be followed by the operator. All personnel must be trained in the correct operational and safety procedures for this product. Use the sign-off sheet below to record initial and periodic reviews of this manual with all personnel.
  • Page 3 STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER CONTENTS 1. Introduction ............................5 1.1 Serial Number Location......................5 1.2 Intended Use ..........................6 1.2.1 Misuse ........................6 2. Safety............................... 7 2.1 Safety Alert Symbol and Signal Words..................7 2.2 General Safety Information....................... 7 2.3 Rotating Flighting Safety ......................
  • Page 4 7.16 Check/Adjust the Truss Cables....................48 7.17 Adjust the Mover Kit Ram and Travel Speed................ 49 7.18 Adjusting the Mover Kit Pinion Gear ..................50 7.19 Change the Hydraulic Oil....................... 51 8. Troubleshooting............................ 52 9. Specifications ............................56 10. AGI Limited Warranty......................... 57 31137 R2...
  • Page 5 Keep this manual handy for frequent reference and to review with new personnel. A sign-off form is provided on the inside front cover for your convenience. If any information in this manual is not understood or if you need additional information, please contact AGI or your representative for assistance.
  • Page 6 1. INTRODUCTION STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 1.2. Intended Use The auger is intended for use as listed below and described throughout this manual. Use in any other way is considered contrary to the intended use and is not covered by the warranty. Intended use for the auger •...
  • Page 7 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2. Safety 2.1. Safety Alert Symbol and Signal Words This safety alert symbol indicates important safety messages in this manual. When you see this symbol, be alert to the possibility of injury or death, carefully read the message that follows, and inform others.
  • Page 8 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2.3. Rotating Flighting Safety • KEEP AWAY from rotating flighting. • DO NOT remove or modify flighting guards, doors, or covers. Keep in good working order. Have replaced if damaged. •...
  • Page 9 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2.7. Work Area Safety • Have another trained person nearby who can shut down the auger in case of accident. • Do not allow any unauthorized persons in the work area. •...
  • Page 10 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2.9. Raising and Lowering the Auger • Before raising/lowering/moving/adjusting the auger, make sure the area around the auger is clear of obstructions and/or untrained personnel. Never allow anyone to stand on or beneath the auger when it is being placed.
  • Page 11 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2.12. Towing the Auger The auger is not intended for transport on public roads. If it requires transport on a public roadway, the following steps should be taken: • Check with local authorities regarding transport on public roads. Obey all applicable laws and regulations.
  • Page 12 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2.13.1 Gas Engine Safety Power Source • Keep guards in place and secure. • Properly ventilate surrounding area. • Never fill the fuel tank with the engine running, while smoking, or near an open flame.
  • Page 13 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2.13.3 Hydraulic Power Safety Power Source • Refer to the rules and regulations applicable to the power source operating the hydraulic system. • Do not connect or disconnect hydraulic lines while system is under pressure.
  • Page 14 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2.14. Tire Safety Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion that may result in serious injury or death. •...
  • Page 15 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2.16. Personal Protective Equipment The following Personal Protective Equipment (PPE) should be worn when operating or maintaining the equipment. Safety Glasses • Wear safety glasses at all times to protect eyes from debris. Coveralls •...
  • Page 16 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 2.17. Safety Equipment The following safety equipment should be kept on site. Fire Extinguisher • Provide a fire extinguisher for use in case of an accident. Store in a highly visible and accessible place.
  • Page 17 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 2. Safety Decal Locations 20804 20803 17113 19960 20807 20813 20817 20811 31137 R2...
  • Page 18 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 3. Safety Decal Locations P1513136 20803 Figure 4. Hydraulic Steering Safety Decal Locations 28128 20806 31137 R2...
  • Page 19 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 5. Hydraulic Winch Safety Decal Locations 20810 20806 31137 R2...
  • Page 20 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Table 1. Safety Decals Part Number Description 20817 DANGER ELECTROCUTION HAZARD To prevent death or serious injury: • When operating or moving, keep equipment away from overhead power lines and devices. •...
  • Page 21 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Table 1 Safety Decals (continued) Part Number Description 20803 (inside) WARNING MISSING GUARD HAZARD To prevent serious injury or death, shut off power and reattach guard before operating machine. 20804 WARNING ENTANGLEMENT HAZARD...
  • Page 22 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Table 1 Safety Decals (continued) Part Number Description 20807 WARNING To prevent serious injury or death: • Read and understand the manual before assembling, operating, or maintaining the equipment. •...
  • Page 23 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Table 1 Safety Decals (continued) Part Number Description 20811 WARNING UPENDING HAZARD To prevent death or serious injury: • Anchor intake end and/or support discharge end to prevent upending. •...
  • Page 24 2. SAFETY STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Table 1 Safety Decals (continued) Part Number Description P1513136 WARNING CONTENTS MAY BE UNDER PRESSURE As part of the fuel vapour retention system, it is normal for your tank to expand from internal pressure. Use the vent screw to relieve pressure and before refueling.
  • Page 25 3. FEATURES STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 3. Features discharge and upper drive chain pulley guarding cable bridge belt idler shaft guarding belt tension adjustment cable adjustment manual holder hydraulic winch track reversible gearbox control hydraulic HDSP kit intake and intake guarding Also included: electric clutch, and light kit 31137 R2...
  • Page 26 4. TRANSPORT STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 4. Transport When transporting, follow all safety precautions and use a proper tow vehicle to help ensure safe transport of the auger. 4.1. Transport Safety • Check with local authorities regarding transport on public roads.
  • Page 27 4. TRANSPORT STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 4.2. Transport Preparation • Do not tow faster than 20 mph (32 km/h). Table 2 references the acceptable transport speed as per the ratio of tractor weight versus auger weight. See Specifications (Section 9.
  • Page 28 4. TRANSPORT STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Do not transport with the over-center handles engaged or damage to the mover kit motors will occur. Figure 7. Pin Position 4.4. Connect the Auger to the Towing Vehicle Follow all safety precautions when transporting the auger and use a proper towing vehicle.
  • Page 29 4. TRANSPORT STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 8. Typical Safety Chain and Hitch Connection 4.4.1 Enclosed Hopper When equipped: Attach both hooks to the loops on the hopper and cross the chain underneath the tow bar to prevent the auger from digging into the road surface or upsetting (should a breakaway occur).
  • Page 30 5. PLACEMENT STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 5. Placement 5.1. Placement Safety • The auger is not insulated, keep away from overhead power lines. Electrocution can occur without direct contact. • Anchor intake end before using. •...
  • Page 31 5. PLACEMENT STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 10. Typical Grain Auger Placement for Filling Bins KEEP AWAY! OVERHEAD WIRES wheel chocks Under Hopper Bottom Bins 1. Position the intake hopper between the hopper bin vertical legs. 2.
  • Page 32 5. PLACEMENT STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 11. Wheel Over-Center Handle Positions Engaged Disengaged 2. Set and run the gas engine at approximately half throttle. 3. Refer to the controls shown in Figure 4. Before moving the auger into position: a.
  • Page 33 5. PLACEMENT STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER • Allow the hydraulic oil to warm before using the self-propelled kit. Failure to warm the hydraulic oil can damage the pump or other components. When Operation of the Mover Kit is Complete: Place the mover kit into transport position.
  • Page 34 6. OPERATION STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 6. Operation For optimal operation, follow the safety precautions, checklists, and instructions in this section. 6.1. Operation Safety • Keep away from rotating and moving parts, including the flighting, drive components, shafts, and bearings.
  • Page 35 6. OPERATION STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 6.3. Engage/Disengage Manual Belt • To engage belt, secure locking pin on handle to the tensioner push rod. • To disengage belt, disconnect locking pin on handle from the tensioner push rod and turn clockwise. Figure 13.
  • Page 36 6. OPERATION STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 6.5. Operation — Gas Engine Models When equipped: 1. If the drive belts are tight, disengage the belts. 2. Start the gas engine. Follow instructions provided with the gas engine for specific starting instructions. 3.
  • Page 37 6. OPERATION STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 6.7. Emergency Shutdown In an emergency situation: 1. Shut down the power source immediately and lock out all power. 2. Stop the flow of material (if applicable). 3. Ensure the machine components come to a stop before inspecting. 4.
  • Page 38 6. OPERATION STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 6.11. Shutdown When operation has been completed: 1. Once the auger is clear of grain, lower it fully and lock out the power source. 2. Clean out any remaining grain from the auger with a vacuum or sweep out. 3.
  • Page 39 • After maintenance is complete, replace all guards, service doors, and/or covers. • Use only genuine AGI replacement parts or equivalent. Use of unauthorized parts will void warranty. If in doubt, contact AGI or your local dealer. Before attempting maintenance of any kind: •...
  • Page 40 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 7.2. Maintenance Schedule Follow the maintenance procedures below. Keep records of the hours the auger has been operated and the maintenance performed. Daily: Section 7.3 – Visually Inspect the Auger on page 40 Section 7.4 –...
  • Page 41 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 6. Inspect all moving or rotating parts to see if anything has become entangled in them. Remove any entangled material. 7. Inspect hydraulic hoses and fittings for leaks and wear. Fix or replace where necessary. 8.
  • Page 42 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 7.6. Inspect and Service the Hydraulic Winch and Lift Cable Place the auger in the fully lowered position with the cable slack. To Inspect the Lift Cable: 1. Inspect the cable for damage such as fraying, kinking, or unwinding. Replace if damaged (see below). 2.
  • Page 43 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 7.9. Adjust the Upper Drive Chain Note Improper adjustment of the drive chain will result in premature wear. 1. Loosen the bolts and remove the cover plate. 2. Check upper drive chain for tightness. Chain should have maximum deflection of 1/8" from factory. 3.
  • Page 44 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 17. Upper Chain Drive Zerk & Intake Zerk 7.11. Clean and Wash the Equipment When Equipped: Open the cleanout door of the enclosed hopper. Figure 18. Enclosed Hopper Cleanout Door 1.
  • Page 45 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 19. Distance Between Electric Clutch and Guard Attach Plate 1-1/4" 3. Move the pulleys to the required positions for alignment. 4. Tighten the hub set screws to secure pulleys. 5.
  • Page 46 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 7.13. Tension the Drive Belts 1. Open guard cover and push on the center of the belt span with a force of approximately 10 lbs. 2. The belts will deflect approximately 2" (51 mm) when properly tensioned. Figure 21.
  • Page 47 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 7.14. Replace the Drive Belts 1. Open the guard cover. Remove enclosed belt guards (if equipped). 2. Fully loosen the drive belts. 3. Remove and replace the old belts. Figure 23.
  • Page 48 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 7.16. Check/Adjust the Truss Cables Check the Truss Cables: Check tube for straightness, no slack in the cables, and a just noticeable upward deflection of the discharge end. During operation, it is normal that for the tube to deflect downward. If required, adjust cables by following the procedure below: 1.
  • Page 49 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 25. Typical Cable Truss Assembly cable clamp eyebolt nuts truss cable eyebolt anchor cable return bracket cable truss cable eyebolt 7.17. Adjust the Mover Kit Ram and Travel Speed Place the auger on level surface and fully lower the intake and discharge ends.
  • Page 50 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Figure 26. Control Valve Adjustment STROKE LIMITER SCREW PRESSURE RELIEF VALVE STROKE LIMITER SCREW 7.18. Adjusting the Mover Kit Pinion Gear The pinion gear must mesh fully with the ring gear to provide maximum contact. 1.
  • Page 51 7. MAINTENANCE STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 7.19. Change the Hydraulic Oil Change the hydraulic oil to remove any accumulation of dirt or condensation in the system. Do not over-fill the reservoir. Leave space to allow for level fluctuation. Refer to Section 9.
  • Page 52 The following section covers some causes and solutions to some of the problems that may be encountered. If there is a problem that is difficult to solve, even after having read through this section, please contact your representative or AGI. Have this manual and the serial number available. Auger Cause...
  • Page 53 8. TROUBLESHOOTING STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Bent flighting sections. Support auger and remove all flighting sections. Check for straightness of flight stubs by rolling across flat concrete section. Straighten stub or replace as necessary. Take care not to bend flighting when reinstalling.
  • Page 54 Tube is misaligned. Loose truss cables. Tighten cables as required. (when equipped) Incorrect shear bolt type. Replace with correct part number. AGI Shear bolts fail repeatedly. shear bolts are specifically designed to provide correct driveline protection. Shear bolt hole worn out-of- Frequent use of the incorrect shear bolt round.
  • Page 55 8. TROUBLESHOOTING STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER Hydraulic winch will Relief valve pressure set too Adjust relief valve pressure, refer to Ram not raise auger. low. and Travel Speed Adjustment. Oil level is too low. Check oil level. Pump is worn out.
  • Page 56 9. SPECIFICATIONS STX2 & XTA 10 SERIES – PORTABLE GRAIN AUGER 9. Specifications Specification 10-61 10" (254 mm) Tube Size CAPACITIES Up to 6000 Bu/Hr Unloading Rate (212 m³/Hr) TRANSPORT DIMENSIONS Length 61'6" (18.7 m) 8' (2.44 m) Width Height 14'4"...
