AGI UTX Series Operator's Manual

Portable u-trough grain auger
Hide thumbs Also See for UTX Series:
Table of Contents

Advertisement

Quick Links

Download this manual
UTX Series
Portable U-Trough Grain Auger
Operator's Manual
This manual applies to the following brands and models:
Westfield UTX44 and AGI UTX44
Original Instructions
Read this manual before using product. Failure to
follow instructions and safety precautions can
result in serious injury, death, or property
damage. Keep manual for future reference.
Part Number: 31083 R1
Revised: April 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UTX Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AGI UTX Series

Summary of Contents for AGI UTX Series

  • Page 1 UTX Series Portable U-Trough Grain Auger Operator’s Manual This manual applies to the following brands and models: Westfield UTX44 and AGI UTX44 Original Instructions Read this manual before using product. Failure to Part Number: 31083 R1 follow instructions and safety precautions can...
  • Page 2 We strongly recommend that all personnel associated with this equipment be trained in the correct operational and safety procedures required for this product. This product has been designed and constructed according to general engineering standards, other local regulations may apply and must be followed by the operator. Use the sign-off sheet below to record initial and periodic reviews of this manual with all such personnel.

  • Page 3: Table Of Contents

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER CONTENTS 1. Introduction ............................5 1.1 Serial Number Location......................5 1.2 Intended Use ..........................6 1.2.1 Misuse ........................6 2. Safety............................... 7 2.1 Safety Alert Symbol and Signal Words..................7 2.2 General Product Safety ......................7 2.3 Rotating Flighting Safety ......................
  • Page 4 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 6.7 Use of Grain Spreaders ......................35 6.8 Shutdown ..........................35 6.9 Operating the Auger with Fertilizer ..................35 6.10 Storage........................... 35 7. Maintenance ............................37 7.1 Maintenance Safety ........................ 37 7.2 Maintenance Schedule......................37 7.3 Visually Inspect the Auger.......................

  • Page 5: Introduction

    1.1. Serial Number Location The serial number location for your auger can be seen in the figure below. Provide the serial number to AGI or your representative auger when ordering parts or requesting service or other information. Please record this information in the table below for easy reference.

  • Page 6: Intended Use

    1. INTRODUCTION UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 1.2. Intended Use The auger is intended for use as listed below and described throughout this manual. Use in any other way is considered as contrary to the intended use. The auger should be operated, maintained, serviced, and repaired only by persons who are familiar with its particular characteristics and understand the relevant safety procedures.

  • Page 7: Safety

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY 2 2 . . S S a a f f e e t t y y 2.1. Safety Alert Symbol and Signal Words This safety alert symbol indicates important safety messages in this manual. When you see this symbol, be alert to the possibility of injury or death, carefully read the message that follows, and inform others.

  • Page 8: Rotating Flighting Safety

    2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2.3. Rotating Flighting Safety • KEEP AWAY from rotating flighting. • DO NOT remove or modify flighting guards, doors, or covers. Keep in good working order. Have replaced if damaged. • DO NOT operate the auger without all guards, doors, and covers in place.

  • Page 9: Work Area Safety

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY 2.7. Work Area Safety • Have another trained person nearby who can shut down the auger in case of accident. • The work area should be kept clear of bystanders, including children.

  • Page 10: Raising And Lowering The Auger

    2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2.9. Raising and Lowering the Auger • Before raising/lowering/moving/adjusting the auger, make sure the area around the auger is clear of obstructions and/or untrained personnel. Never allow anyone to stand on or beneath the auger when it is being placed.

  • Page 11: Towing The Auger

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY 2.12. Towing the Auger The auger is not intended for transport on public roads. If it requires transport on a public roadway, the following steps should be taken: • Check with local authorities regarding transport on public roads. Obey all applicable laws and regulations.

  • Page 12: Gas Engine Safety

    2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2.13.1 Gas Engine Safety Power Source • Keep guards in place and secure. • Properly ventilate surrounding area. • Never fill the fuel tank with the engine running, while smoking, or near an open flame. Always shut down and allow engine to cool before filling with fuel.

  • Page 13: Hydraulic Power Safety

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY 2.13.2 Hydraulic Power Safety Power Source • Refer to the rules and regulations applicable to the power source operating your hydraulic drive. • Do not connect or disconnect hydraulic lines while system is under pressure.

  • Page 14: Tire Safety

    2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2.14. Tire Safety Failure to follow proper procedures when mounting a tire on a wheel or rim can produce an explosion that may result in serious injury or death. • DO NOT attempt to mount a tire unless you have the proper equipment and experience to do the job.

  • Page 15: Personal Protective Equipment

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY 2.16. Personal Protective Equipment The following Personal Protective Equipment (PPE) should be worn when operating or maintaining the equipment. Safety Glasses • Wear safety glasses at all times to protect eyes from debris.

  • Page 16: Safety Equipment

    2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2.17. Safety Equipment The following safety equipment should be kept on site: Fire Extinguisher • Provide a fire extinguisher for use in case of an accident. Store in a highly visible and accessible place.
  • Page 17 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY Figure 2. Safety Decal Locations 20804 20804 20803 Figure 3. Safety Decal Locations P1513136 20803 17113 20807 20813 20811 19960 20817 31083 R1...
  • Page 18 2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Figure 4. Safety Decal Locations (HD Hydraulic Steering) 28128 20806 Figure 5. Safety Decal Locations (Hydraulic Winch) 20810 20806 31083 R1...
  • Page 19 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY Table 1. Safety Decals Part Number Description 20817 DANGER ELECTROCUTION HAZARD To prevent death or serious injury: • When operating or moving, keep equipment away from overhead power lines and devices.
  • Page 20 2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Table 1 Safety Decals (continued) Part Number Description 20803 (inside) WARNING MISSING GUARD HAZARD To prevent serious injury or death, shut off power and reattach guard before operating machine. 20804 WARNING...
  • Page 21 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY Table 1 Safety Decals (continued) Part Number Description 20807 WARNING To prevent serious injury or death: • Read and understand the manual before assembling, operating, or maintaining the equipment. • Only trained personnel may assemble, operate, or maintain the equipment.
  • Page 22 2. SAFETY UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Table 1 Safety Decals (continued) Part Number Description 20811 WARNING UPENDING HAZARD To prevent death or serious injury: • Anchor intake end and/or support discharge end to prevent upending. • Intake end must always have downward weight.
  • Page 23 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 2. SAFETY Table 1 Safety Decals (continued) Part Number Description P1513136 WARNING CONTENTS MAY BE UNDER PRESSURE As part of the fuel vapour retention system, it is normal for your tank to expand from internal pressure. Use the vent screw to relieve pressure and before refueling.

  • Page 24: Features

    3. FEATURES UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 3 3 . . F F e e a a t t u u r r e e s s This section covers the main features of the auger. Item Description...

  • Page 25: Transport

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. TRANSPORT 4 4 . . T T r r a a n n s s p p o o r r t t Before continuing, ensure you have completely read and understood this manual’s Safety section, in addition to the safety information in the section(s) below.

  • Page 26: Transport Preparation

    4. TRANSPORT UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4.2. Transport Preparation 1. It is not recommended that the auger be transported faster than 20 mph (32 km/h). Table 2 references the acceptable transport speed as per the ratio of tractor weight versus auger weight. See Specifications (Section 9.

  • Page 27: Connect The Auger To The Towing Vehicle

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 4. TRANSPORT Do not transport with the over-center handles engaged or damage to the mover kit motors will occur. Figure 7. Pin Position 4.4. Connect the Auger to the Towing Vehicle Follow all safety precautions when transporting the auger and use a proper towing vehicle.
  • Page 28 4. TRANSPORT UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Figure 8. Typical Safety Chain and Hitch Connection Offset Hitch Tractor Drawbar Safety Chain Hitch Pin Grip Clip 31083 R1...

  • Page 29: Placement

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 5. PLACEMENT 5 5 . . P P l l a a c c e e m m e e n n t t Before continuing, ensure you have completely read and understood this manual’s Safety section, in addition to the safety information in the section(s) below.

  • Page 30: Positioning The Auger With A Mover Kit

    5. PLACEMENT UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Figure 9. Typical Grain Auger Placement for Filling Bins KEEP AWAY! OVERHEAD WIRES wheel chocks Under Hopper Bottom Bins 1. Confirm that hopper is centered between the hopper bin vertical legs. This ensures that the operator has adequate clearance.
  • Page 31 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 5. PLACEMENT Figure 10. Wheel Over-Center Handle Positions Engaged Disengaged 2. Set and run the gas engine at approximately half throttle. 3. Refer to the controls shown in Figure 4. Before moving the auger into position: •...

  • Page 32: Hydraulic Winch Operation

    5. PLACEMENT UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER • Allow the hydraulic oil to warm before using the self-propelled kit. Failure to warm the hydraulic oil can damage the pump or other components. When Operation of the Mover Kit is Complete: Place the mover kit into transport position.

  • Page 33: Operation

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 6. OPERATION 6 6 . . O O p p e e r r a a t t i i o o n n Before continuing, ensure you have completely read and understood this manual’s Safety section, in addition to the safety information in the section(s) below.

  • Page 34: Operation - Gas Engine Models

    6. OPERATION UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 6.3. Operation - Gas Engine Models When Equipped with a Gas Engine: 1. If the drive belts are tight, disengage the belts. 2. Start the gas engine. Follow instructions provided with the gas engine for specific starting instructions.

  • Page 35: Bin Level Indicators

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 6. OPERATION 6.6. Bin Level Indicators These augers are fast and bins fill up quickly. A full bin will cause auger to plug, which can damage the flighting and other drive components. Installing quality grain-level indicators on your bins will allow you to monitor bin filling and help prevent damage to your auger.
  • Page 36 6. OPERATION UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 3. Inspect all moving or rotating parts to see if anything has become entangled in them. Remove any entangled material. 4. Touch up all paint nicks and scratches to prevent rusting.

  • Page 37: Maintenance

    • After maintenance is complete, replace all guards, service doors, and/or covers. • Use only genuine AGI replacement parts or equivalent. Use of unauthorized parts will void warranty. If in doubt, contact AGI or your local dealer. Before attempting maintenance of any kind: •...

  • Page 38: Visually Inspect The Auger

    7. MAINTENANCE UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Annually: Section 7.5 – Check the Gearbox Oil on page 39 Section 7.7 – Adjust the Upper Drive Chain on page 40 Section 7.9 – Clean and Wash the Equipment on page 41 As Required: Section 7.6 –...

  • Page 39: Lubricate The Equipment

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 7. MAINTENANCE 7.4. Lubricate the Equipment Your equipment can operate at top efficiency only if clean fluids and lubricants are used. Use clean containers to handle all fluids and lubricants. Store them in an area protected from dust, moisture, and other contaminants.

  • Page 40: Adjust The Upper Drive Chain

    7. MAINTENANCE UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 7.7. Adjust the Upper Drive Chain Note Improper adjustment of the drive chain will result in premature wear. 1. Loosen the bolts and remove the cover plate. 2. Check upper drive chain for tightness. Chain should have maximum deflection of 1/8" from factory.

  • Page 41: Clean And Wash The Equipment

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 7. MAINTENANCE Figure 13. Upper Chain Drive Zerk 7.9. Clean and Wash the Equipment 1. Clean out excess grain from all areas of the auger. 2. Remove the intake cleanout cover to make sure water can drain from the auger trough and intake, then wash the trough with a water hose or pressure washer until all dirt, mud, debris, or residue is gone.
  • Page 42 7. MAINTENANCE UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Figure 15. Distance Between Electric Clutch and Guard Attach Plate 1-1/4" Triple Electric Clutch 3. Move the pulleys to the required positions for alignment. 4. Tighten the hub set screws to secure pulleys.

  • Page 43: Tension The Drive Belts

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 7. MAINTENANCE 6. Reattach and secure the guard covers. 7. Check the belt tension. 7.11. Tension the Drive Belts 1. Open the guard cover and push on the center of the belt span with a force of approximately 10 lbs.

  • Page 44: Replace The Drive Belts

    7. MAINTENANCE UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 7.12. Replace the Drive Belts 1. Remove the guard cover. 2. Fully loosen the drive belts. 3. Remove and replace the old belts. 4. Align the drive belts as described in Belt Alignment.

  • Page 45: Inspect And Service The Hydraulic Winch And Lift Cable

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 7. MAINTENANCE 7.14. Inspect and Service the Hydraulic Winch and Lift Cable Place auger in fully lowered position with cable slack. 1. Inspect the cable for damage such as fraying, kinking, or unwinding. Replace if damaged (see below).

  • Page 46: Pinion Gear Adjustment

    7. MAINTENANCE UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Figure 20. Control Valve Adjustment Travel Speed Adjustment To control the speed of the mover, the cushion valve can be adjusted: • screwed in for increased speed. • screwed out for decreased speed.

  • Page 47: Change The Hydraulic Oil

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 7. MAINTENANCE Figure 22. Pinion Gear Adjustment Nut 7.17. Change the Hydraulic Oil Change the hydraulic oil to remove any accumulation of dirt or condensation in the system. Do not over-fill the reservoir. Leave space to allow for level fluctuation. Refer to Section 9.

  • Page 48: Troubleshooting

    8. TROUBLESHOOTING UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 8 8 . . T T r r o o u u b b l l e e s s h h o o o o t t i i n n g g Shut down and lock out all power sources before diagnosing any of the causes or attempting any of the solutions below.
  • Page 49 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 8. TROUBLESHOOTING necessary. Take care not to bend flighting when reinstalling. Obstruction in auger trough. Visually inspect for cloth or trash wrapped around flighting, or buildup of gum from oily crops such as flax or canola.
  • Page 50 8. TROUBLESHOOTING UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Low gear oil level. Inspect the gearbox, replace if damaged or add oil if not damaged. Upper chain drive loose. Tighten the chain as required. Incorrect shear bolt type. Replace with correct part number. AGI Shear bolts fail repeatedly.
  • Page 51 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 8. TROUBLESHOOTING Problem Cause Solution Valve is leaking. Loose/cracked fittings. Tighten/replace fittings. Worn hose. Replace hose. Valve spools are worn. Replace valve. Machine operates Oil is hot. Check oil level and add if required.
  • Page 52 8. TROUBLESHOOTING UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER Problem Cause Solution Drive belts jumping off Motor misaligned. Ensure drive and driven pulleys are pulleys. correctly aligned. Belt tension inadequate. Adjust tension. Using a lower horsepower See Specifications for recommended motor than recommended.

  • Page 53: Specifications

    UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 9. SPECIFICATIONS 9 9 . . S S p p e e c c i i f f i i c c a a t t i i o o n n s s...

  • Page 54: Agi Limited Warranty

    1 1 0 0 . . A A G G I I L L i i m m i i t t e e d d W W a a r r r r a a n n t t y y This warranty relates to AGI Augers (the “Product”) sold by AGI, (referred to herein as the “Seller”) and applies only to the first user of the Product (meaning a purchaser directly from the Seller or from an authorized dealer or distributor of the Product, referred to herein as the “Buyer”).
  • Page 55 UTX SERIES – PORTABLE U-TROUGH GRAIN AUGER 10. AGI LIMITED WARRANTY 31083 R1...
  • Page 56 P.O. Box 39 Rosenort, Manitoba, R0G 1W0 Canada Phone: (866) 467-7207 (Canada & USA) or (204) 746–2396 Fax: (866) 768-4852 Website: www.grainaugers.com Email: sales@grainaugers.com ©Ag Growth International Inc. 2020 Printed in Canada If you have any comments or questions on this manual, or find an error, email us at comments@aggrowth.com. Please include the part number listed on the cover page in your message.
