APPLICATION
Toyota Tundra Double Cab/Regular Cab
1
2
9
8
(Bracket D)
(Bracket A)
Drivers Side
Configuration
1
Using a 12mm socket or wrench loosen both brake cable
brackets. Note: Passenger side only has one bracket
to remove.
2
REALTRUCK TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 8:00 AM - 5:00 PM EST
Designed and manufactured by AMP Research
Patent Protected. Please see our product site for applicable patents. www.realtruck.com/b/amp-research/
© 2024 AMP Research • Three-year limited warranty. • Professional installation is recommended.
www.realtruck.com
3
4
(Bracket C)
12
10
11
(Bracket G)
Passenger Side
Configuration
12mm
• Made in Mexico
®
MODEL YEAR
2007-2021
5
(Bracket E)
13
14
18
Bolt Bracket A up to bed support rib.
3
1/4
PART NUMBER
75409-01A
6
7
(Bracket F)
(Bracket B)
16
15
19
20
Tools Needed
1/4" Drill Bit
Torque wrench
17/32" Drill Bit
10mm 12mm 13mm 15mm
M10 Screw
IM75409 rev 04.30.24
17
T25
M8 Screw
13 &15mm
Advertisement
Related Manuals for AMP Research BedStep2 REALTRUCK 75409-01A
Summary of Contents for AMP Research BedStep2 REALTRUCK 75409-01A
- Page 1 REALTRUCK TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 8:00 AM - 5:00 PM EST Designed and manufactured by AMP Research • Made in Mexico ® Patent Protected. Please see our product site for applicable patents. www.realtruck.com/b/amp-research/ © 2024 AMP Research • Three-year limited warranty. • Professional installation is recommended. www.realtruck.com IM75409 rev 04.30.24...
- Page 2 Mark hole to be drilled in frame. Remove Bracket A. Center Punch hole, pre drill using an 1/8” drill. Drill to 17/32”. Reinstall Bracket A to bed support rib. Install provided bolt With Rivet Nut Tool held in place with 19mm wrench, tighten Hex Bolt until Rivet Nut deforms and secures into rivet nut installed in step 5.
- Page 3 Install Bracket G onto Bracket F and use provided bolts, Use provided shorter flange head bolt and tighten Bracket F to Bracket B. Torque to 16 ft-lbs with 13mm socket. washer and nut to attach bracket to Front support rib. Using a 14mm socket or wrench torque body mount bolt from step 5.
- Page 4 Set step pad into center position and tighten screws. Set “Bracket E” and “Bracket D” together using provided Tighten to 5 ft-lbs. flange head screw tighten bolts. Tighten bolts from Step 6 and 9. Torque to 16ft-lbs. Using 15mm socket or wrench install bolts into linkage Slide linkage assembly into slot and hole and slide into assembly.
- Page 5 AMERICAN DESIGNED & ENGINEERED Thank you for your recent Realtruck Purchase. REGISTER YOUR PRODUCT TODAY FOR FASTER SERVICE & PRODUCT UPDATES Please visit: https://realtruck.com/warranty-registration/ or scan the QR Code Product Registration Benefits: • Ensure we have your purchase receipt and product info in our system which is required for warranty.
- Page 6 ® Here’s what you should know... OPERATION The AMP Research BedStep is foot operated and deploys and retracts with a nudge of your foot. ® To deploy, press down using your left foot, on the forward outside corner of the step pad.
