20-03797-10
15-03801-90
Brackets must be confi gured for Passenger or Driver-Side as shown.
1
Driver-Side Orientation
Using a 15mm Socket assemble Lateral mount onto
Linkage assembly. Do not tighten bolts yet. Note:
Drivers side shown. Mirror for passenger side.
2
19-03783-90
15-03802-90
15mm
Ford F150
(Fits all Beds /Cabs)
2009-Current
19-03810-90
19-03341-90
19-03563-90
11-03639-90
Passenger-Side Orientation
Using a 13mm Socket assemble Frame mount onto
Lateral mount. Torque bolts to 16 ft-lbs.
3
PART NUMBER:
75402-01A
Torque wrench
13mm
15mm
T25 Torx
13mm
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AMP Research BedStep2
Summary of Contents for AMP Research BedStep2
- Page 1 PART NUMBER: Ford F150 75402-01A (Fits all Beds /Cabs) 2009-Current Torque wrench 19-03810-90 19-03341-90 19-03783-90 20-03797-10 19-03563-90 15-03802-90 15-03801-90 13mm 15mm T25 Torx 11-03639-90 Brackets must be confi gured for Passenger or Driver-Side as shown. Driver-Side Orientation Passenger-Side Orientation Using a 13mm Socket assemble Frame mount onto Using a 15mm Socket assemble Lateral mount onto Lateral mount.
- Page 2 Step 2 to 20ft-lbs. Note: Drivers side shown To deploy the step, press down using your foot on the To retract, gently kick up on the underside of the step outside edge of the step pad. pad. AMP RESEARCH RUNNIG BOARDS SIDE STEPS...
