OWNER'S & OPERATOR'S
Effective September 24, 2024
6" Power Sweep Auger Models:
Band-On Wells
B11711P - 15' dia. Bins
B11721P - 18' dia. Bins
B11731P - 21' dia. Bins
B11741P - 24' dia. Bins
B11751P - 27' dia. Bins
B11761P - 30' dia. Bins
B11771P - 33' dia. Bins
B11781P - 36' dia. Bins
B11791P - 39' dia. Bins
B11801P - 42' dia. Bins
B11811P - 48' dia. Bins
Hutchinson l Mayrath
6" POWER SWEEP
AUGER
MANUAL
Weld-On Wells
B11716P - 15' dia. Bins
B11726P - 18' dia. Bins
B11736P - 21' dia. Bins
B11746P - 24' dia. Bins
B11756P - 27' dia. Bins
B11766P - 30' dia. Bins
B11776P - 33' dia. Bins
B11786P - 36' dia. Bins
B11796P - 39' dia. Bins
B11806P - 42' dia. Bins
B11816P - 48' dia. Bins
514 W. Crawford
P 785.632.2161
F 785.632.5964
hutchinson-mayrath.com
Publication No. 1030087
Clay Center, KS. USA 67432
TF 800.523.6993
aggrowth.com
Original Instructions
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for AGI Hutchinson Mayrath B11711P
Summary of Contents for AGI Hutchinson Mayrath B11711P
- Page 1 6” POWER SWEEP AUGER OWNER’S & OPERATOR’S MANUAL Effective September 24, 2024 Publication No. 1030087 6” Power Sweep Auger Models: Band-On Wells Weld-On Wells B11711P - 15’ dia. Bins B11716P - 15’ dia. Bins B11721P - 18’ dia. Bins B11726P - 18’ dia. Bins B11731P - 21’...
- Page 3 TABLE OF CONTENTS Page 1 TABLE OF CONTENTS ............................. 1 SAFETY ..............................2 to 4 Intended Use Statement ..........................2 General Safety Statement ..........................2 Safety Alert Symbol, Operate Motor’s Properly ....................2 Prepare for Emergencies, Follow Safety Instructions, Wear Proper PPE ............3 Stay Clear of Moving Parts, Grain Bin Safety, Safety Decals ................
- Page 4 SAFETY Page 2 6” & 8” POWER SWEEP INTENDED USE This product is intended to provide the mechanical Please remember safety equipment provides important means to remove the grain that remains in the bin or protection for persons around a grain handling system storage structure, after all grain that can be emptied that is in operation.
- Page 5 SAFETY Page 3 Prepare for Emergencies Keep emergency numbers for doctors, ambulance service, hospital and fire department near your telephone. Keep a first-aid kit and fire extinguisher handy. Be prepared if a fire starts First Aid Equipment Fire Extinguisher Follow Safety Instructions Carefully read all safety messages in this manual and safety signs on your machine.
- Page 6 SAFETY Page 4 Stay Clear of Moving Parts Keep all shields, covers and safety devices in place at all times. Entanglement in moving chains, rotating impeller arms and sprockets will cause serious injury or death. Wear close fitted clothing. Keep hands, feet and clothing away from moving parts.
- Page 7 GENERAL INFORMATION Page 5 OPERATOR QUALIFICATIONS WARNING! Anyone who will operate or work around this machine shall first read this manual! This manual must be delivered with the equipment to its owner. Failure to read this manual and its safety instructions is a misuse of the equipment. 3.
- Page 8 GENERAL INFORMATION Page 6 General Information (con’t.) MACHINE INSPECTION Our augers are well made and we are proud of our line WARNING! During initial start-up and of equipment. We would like you, as our customer, to break-in period, the operator shall be do your part in using caution and good judgement in aware of any unusual vibrations or using our equipment, as well as any other machinery.
- Page 9 OPERATING PROCEDURES Page 7 ELECTRIC DRIVE POWER REQUIREMENTS WARNING! A main power disconnect switch that can be locked in only the “OFF” position shall be provided. This shall be locked whenever work is being done on the auger. The reset and starting controls must be located so that the operator has full view of the entire operation.
- Page 10 OPERATING PROCEDURES Page 8 FLIGHT SPEED INFORMATION Proper auger flight speed is important for efficient operation of the Power Sweep. 1. If the flight speed is too fast, excessive wear will result. 2. If the flight speed is too slow and the auger flighting is permitted to “load-up”, high torque will be required to turn the auger flighting, this can result in damage to the auger.
- Page 11 OPERATING PROCEDURES Page 9 DESIGNATED WORK AREA ELECTRIC DRIVE SHUTDOWN/LOCKOUT WARNING! Under no circumstances should persons not involved in the WARNING! If the operator must leave operation be allowed to trespass into the work area, or whenever servicing the work area. or adjusting, the auger/conveyor must be stopped and the power It shall be the duty of all operator’s to...
- Page 12 OPERATING PROCEDURES Page 10 FULL LOAD OPERATION To Start Auger Operation WARNING! Observe the work area 1. Start the motor for the unload auger/conveyor before restrictions. augering grain. Make certain everyone is clear of the 2. With unload auger operating, use the control handle area before operating the equipment.
- Page 13 OPERATING PROCEDURES Page 11 FULL LOAD OPERATION (con’t.) WARNING! Do Not enter the bin unless all power driven equipment has been shut down and locked out. Rapidly traveling sweep auger. Keep out of bin when sweep auger is in operation. The center well control pipe is run through the larger intermediate well control pipe.
- Page 14 OPERATING PROCEDURES Page 12 FINAL CLEANOUT The following procedures are recommended for cleaning 3. Shut down and lockout the power source to the the floor of the bin after the sweep auger has removed unload auger and sweep auger. Clean (scoop and as much grain as possible.
- Page 15 LUBRICATION & MAINTENANCE Page 13 GENERAL MAINTENANCE INFORMATION GEARBOX OIL LEVEL Prior to assembly, remove the solid plug from the rear WARNING! Shut off power and lockout side of each gearbox and replace with the provided vent/ before attempting to adjust, service, fill plug.
- Page 16 ASSEMBLY INSTRUCTIONS Page 14 CONCRETE TRENCH LAYOUT Concrete should not be poured around the unloading auger components. For installation of augers into grain bins with concrete floors, a pre-formed trench should be made in the floor that will accept the auger, wells and controls, See illustration below for minimum trench dimensions and relative position of the trench to the center of the bin.
- Page 17 ASSEMBLY INSTRUCTIONS Page 15 UNLOADING AUGER AND BIN WELLS The illustration below shows the typical layout of the center and intermediate wells. The chart and illustration on Page 17 gives the appropriate dimensions for well location according to various bin diameters. For bins with raised metal floors, it is necessary to cut openings in the floor for the center well and intermediate wells.
- Page 18 ASSEMBLY INSTRUCTIONS Page 16 UNLOADING AUGER AND BIN WELLS (con’t.) 2. Use the bin flange as a template to locate and mark the opening’s to be cut out of the bin wall for the unloading tube, the center and intermediate well control pipes, and the clutch control pipe (locate the unload tube opening the same distance below the floor as the auger tube connected to the center well).
- Page 19 ASSEMBLY INSTRUCTIONS Page 17 UNLOADING AUGER AND BIN WELLS (con’t.) 4. Locate the intermediate wells using the chart below to determine distance between the wells (weld-on wells will already be properly positioned, the floor can then be installed around the bin wells). Cut openings in the bin floor for the intermediate wells using the cut-out dimensions shown on Page 15.
- Page 20 ASSEMBLY INSTRUCTIONS Page 18 UNLOADING AUGER AND BIN WELLS (con’t.) 5. Once all wells have been properly positioned, installed, 7. Determine the location on the control pipe where the and supports have been placed beneath the wells, gate clamps will be fastened onto the well gate. Note slide the “unloading flight”...
- Page 21 ASSEMBLY INSTRUCTIONS Page 19 UNLOADING AUGER AND BIN WELLS (con’t.) 10. Now you can secure the lock collar(s) to the control 12. Attach the control pipe to the control gate by sliding pipe (a portion of the collar will be protruding through a 5/16”...
- Page 22 ASSEMBLY INSTRUCTIONS Page 20 ASSEMBLE CONTROL HANDLE 1. On the outside of the bin, position the half-bands around the unload tube with the edge of the one closest to the bin wall approximately 4” (102 mm) from the wall (See illustration below). Attach the “pull bar”...
- Page 23 ASSEMBLY INSTRUCTIONS Page 21 INSTALL CLUTCH CONTROL PIPE 1. For intermediate bin wells that are welded to the unloading housing, bolt the clutch control pipe brackets to the well using two 5/16” x 3/4” bolts and nylon locknuts (See illustration below). For band-on intermediate wells, the 6”...
- Page 24 ASSEMBLY INSTRUCTIONS Page 22 INSTALL SWEEP FLIGHT & BACK SHIELD WARNING! Be cautious when working with metal materials. Wear appropriate personal protective gear, i.e. gloves, safety glasses, ear protection, etc. Some of the parts used in assembly are heavy and awkward. Use assistance when handling these parts.
- Page 25 ASSEMBLY INSTRUCTIONS Page 23 INSTALL SWEEP FLIGHT & BACK SHIELD (con’t.) 4. Position the next sweep shield in succession behind the splice plate and align with the previous sweep shield. Note that the bolt for the second set of holes in the bearing assembly will pass through the splice plate and the sweep shield as shown in the illustration on the previous page and below.
- Page 26 ASSEMBLY INSTRUCTIONS Page 24 INSTALL DRIVE WHEEL Install the drive wheel as detailed below. For 6” Sweeps 1. Pump approximately 2 oz. of a good quality (59.15 ml) End Wheel f/ 6” Sweeps multi-purposegrease into the sweep wheel drive enclosure (See “Lubrication Section” on Page 13). 5/16”...
- Page 27 ASSEMBLY INSTRUCTIONS Page 25 CREATE CROWN f/ SWEEP SHIELDS If your sweep has multiple sweep sections, it will be necessary to create a “crown” at the mid-way point of the shields. After sweep shields have been installed, loosen the bolts on all shield splices and the bolt securing the pivot bracket to the gearbox.
- Page 28 ASSEMBLY INSTRUCTIONS Page 26 SELF-ADJUSTING END WHEEL BRACKET KITS KIT PART NO’s. 1052396 (w/o Wheel) for 7” O.D. FLIGHTS KIT PART NO’s. 1052397 (with wheel) for 7” O.D. FLIGHTS KIT PART NO’s. 1052398 (w/o wheel) for 9” O.D. FLIGHTS KIT PART NO’s. 1052399 (with wheel) for 9”...
- Page 29 ASSEMBLY INSTRUCTIONS Page 27 SELF-ADJUSTING END WHEEL BRACKET KITS (con’t.) 4. Install the end wheel mount bracket to the end of the sweep shield (7” sweeps use 5/16” x 3/4” bolts, flat washers and nylon locknuts; 9” sweeps use 3/8” x 3/4” bolts, flat washers and nylon locknuts). 5.
- Page 30 PARTS LIST TABLE of CONTENTS Page 28 PARTS LIST TABLE of CONTENTS Decals and Safety Signs ...................... P-1 Center Well Components ..................... P-2 Sweep Flight & Shield Components .................. P-3 Unloading Tube Components .................. P-4 to P-5 Bin Flange & Clutch Components ..................P-6 Sweep Wheel ........................
- Page 31 PARTS LIST Page P-1 SAFETY DECALS & SIGNS CE Serial No. Plate Ref. Part Description 1002303-1 Decal: Warning, Do Not Enter Bin Unless All Power Is Disconnected 1002304-1 Decal, Danger, Rapidly Traveling Sweep Auger 1025080 CE Decal, Rotating Auger 1025077 CE Decal, General Caution 1030423 Decal, IMPORTANT: Before Filling Bin..
- Page 32 PARTS LIST Page P-2 CENTER WELL COMPONENTS 14 11 All Items shown are used with both the 6” & 8” Models unless otherwise indicated. Ref. Part Ref. Part Description Description 1030110 Power Well Weldment f/ 6” Models 6818D Bearing, 2-Hole Flange, 1” Bore 1029970 Power Well Weldment f/ 8”...
- Page 33 PARTS LIST Page P-3 SWEEP FLIGHT & SHIELD COMPONENTS End Wheel f/ 6” Sweeps Apply Anti-Seize Apply Anti-Seize Apply End Wheel Anti-Seize f/ 8” Sweeps 6” Components 8” Components Ref. Part Ref. Part Description Description 1030225 Enclosed Sweep Wheel Assy. 1045372 Sweep Drive Wheel f/ 8”...
- Page 34 PARTS LIST Page P-4 UNLOADING TUBE COMPONENTS Band–On Weld–On Intermediate Wells Intermediate Wells 23 24 23 24 Existing 18 19 Hardware All Items shown are used with both the 6” & 8” Models unless otherwise indicated. Ref. Part Ref. Part Description Description 5048A1...
- Page 35 PARTS LIST Page P-5 UNLOADING TUBE COMPONENTS (con’t,) Ref. Part Ref. Part Description Description 50471A1 Clamp f/ Center Well Gate 8” Unload Tube (con’t.) 6815P 6” Connecting band x 12” long (15) 1018175-R Unload Tube f/ 30’ Bin, 15’-6” lg (14) 8815P 8”...
- Page 36 PARTS LIST Page P-6 BIN FLANGE & CLUTCH CONTROL COMPONENTS All Items shown are used for both the 6” & 8” Models unless otherwise noted. Ref. Part Ref. Part Description Description 1030243 Flange, Upper Bin (f/ 6” Models) - - - Clutch Control Pipe (con’t.) 1030241 Flange, Upper Bin (f/ 8”...
- Page 37 PARTS LIST Page P-7 4:1 RATIO SWEEP WHEEL COMPONENTS Wheel f/ 6” Models Wheel f/ 8” Models Ref. Part Ref. Part Description Description 1015481 Bushing, 1” x 1 1/4” 1015477 Bushing, 1” x 1 1/2” I.D. O.D. I.D. O.D. 4 3/8” (111 mm) long 4 3/8”...
- Page 38 PARTS LIST Page P-8 SELF-ADJUSTING SWEEP END WHEEL BRACKET KITS Apply Existing Anti-Seize Bolt 10 9 Ref. Part Ref. Part Description Description 1045372 Sweep End Wheel f/ 7” Flight 1031978 Bolt, 1/2-13 x 6-1/2” G5 PLT 1045373 Sweep End Wheel f/ 9” Flight 33025 Washer, 1/2”...
- Page 39 PARTS LIST Page P-9 TORQUE CHART General Torque Specification Table Use the Following Torques When Special Torques Are Not Given Note: These values apply to fasteners as received from supplier, dry, or when lubricated with normal engine oil. They do not apply if special graphited or moly-disulphide greases or other extreme pressure lubricants are used.
- Page 40 514 W. Crawford Street, Clay Center, Kansas, 67432 USA Toll Free: 1-800-523-6993 Phone: 1-785-632-2161 Fax: 1-785-632-5964 Website: www.hutchinson-mayrath.com AGI Clay Center is a Division of Ag Growth International Inc. 198 Commerce Drive, Winnipeg, Manitoba, R3P )26 Phone: 1-204-489-1855 Fax: 1-204-488-6929 Website: www.aggrowth.com...
- Page 41 Goods shall be limited to 90 days. Subject to AGI’s sole discretion, if the Goods, or a component thereof, are found to have a default in materials and/or workmanship within the Warranty Term, AGI will, at its own option and expense, repair or replace the subject Goods or refund the purchase price for the applicable Goods.
- Page 42 Buyer is or may be responsible (“Indemnitors”) shall fully indemnify, save and hold AGI, its agents, employees, officers, directors, partners and related entities harmless from and against all liability, damage, loss, claims, demands, actions and expenses of any nature whatsoever, including, but not limited to reasonable attorney’s fees which arise out of or are...
- Page 44 MANUFACTURED BY HUTCHINSON I MAYRATH 514 W. Crawford Street TF 800.523.6993 Clay Center, Kansas P 785.632.2161 USA 67432 F 785.632.5964 hutchinson–mayrath.com E 2024 Ag Growth International. All rights reserved aggrowth.com...
