Idemia MorphoWave Compact Quick User Manual

Hide thumbs Also See for MorphoWave Compact:

Advertisement

Quick Links

Download this manual
MorphoWave Compact
Quick User Guide
All descriptions illustrations, and specifications in this brochure should be
considered approximate and may relate to optional equipment or feature

Advertisement

loading
Need help?

Need help?

Do you have a question about the MorphoWave Compact and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Idemia MorphoWave Compact

Summary of Contents for Idemia MorphoWave Compact

  • Page 1 MorphoWave Compact Quick User Guide All descriptions illustrations, and specifications in this brochure should be considered approximate and may relate to optional equipment or feature...
  • Page 2 MorphoWave Compact terminal Wall Mounting Plate Documentation package ® ® ® ® Electronic documentation is provided in Adobe Acrobat format (PDF). Adobe Acrobat Reader is available at http://www.adobe.com. IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 3 Power Ground. Note that all connections of the MorphoWave Compact terminal described hereafter are of SELV (Safety Electrical Low Voltage) type. This symbol means do not dispose of your product with your other household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment.
  • Page 4 Table of Contents Color Step Content Overview Wiring Three Communications Four SDAC (Single Door Access Control) Five Software Administration Seven Capture basics Eight Optional features IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 5 ® Plus, DESFire, HID iClass*, HID Seos, HID PROX*) Optional Wifi Intercom system interface Universal connectivity (Gigabit Ethernet, RS485/422, Wiegand, Dataclock) Anti-tamper sensor * Depending on product version IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 6 Terminal Implementation To secure an access, IDEMIA recommends installing the MorphoWave Compact terminal as a part of a typical Access Control system, which consists of the components described below. The MorphoWave Compact terminal Its role is to process the access request from the user. It performs access right checks using one-to-many biometric identification or one-to-one biometric verification, and/or RF card authentication, and/or PIN check.
  • Page 7 Note: One user must be enrolled in the terminal database, in order to be able to perform biometric check. IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 8 Identifier on the keypad, or a Wiegand frame is received from an external device stored on the contactless card or in the user record in the terminal’s local database (**) IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 9 General precautions Do not expose the terminal to extreme temperatures. When the environment is very dry, avoid synthetic carpeting near the MorphoWave Compact terminal, to reduce the risk of unwanted electrostatic discharge. Areas containing combustibles Do not install the terminal in the vicinity of gas stations or any other installation containing flammable or combustible gases or materials.
  • Page 10 ECO Mode On top of the standard Stand-by mode, MorphoWave Compact provides an ECO Mode When ECO Mode setting is ON :  green light of the sensor is switched off after 30s  the 2 proximity sensors (on each side of the product) are activated, allowing automatic detection of the hand to...
  • Page 11 STAND-BY mode STAND-BY Green mode lightning OFF ECO mode Green Sensor Green lightning OFF camera OFF lightning OFF Sensor Time out camera OFF selectable from 30s to 360s IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 12 Backup of the Date/Time of the terminal: the volatile settings (such as date/time) of the terminal are protected against power failure, by a dedicated component during at least 24 hours (at 25 C) without external power supply. IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 13 If sharing power between devices, each unit must receive 2.5 A (e.g. two units would require a 12 VDC, 5 A supply). A battery backup or uninterrupted power supply (UPS) with built-in surge protection is recommended. IDEMIA recommends using a 24V power supply and AWG16 gauge Maximum distance (meters) Gauge Section cable.
  • Page 14 A maximum of 31 devices may be installed on the same line.  The maximum total cable length is 1200m (4000 ft.)  The cable must be dedicated to this installation and not used for any other purpose IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 15 Another conductor should be used for Signal Ground (Black / Red wire - 11). The maximum total cable length is 4000 ft. (1200m). The cable must be dedicated to this installation and not used for any other purpose IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 16 Use a category 6 shielding cable (120 Ohms) or better. It is strongly recommended to insert a repeater unit every 90 m. Static mode is enabled by default on MorphoWave Compact terminals (factory setting) : IP=192.168.1.10, Gateway=192.168.1.254, Mask= 255.255.254.0 Terminal Block Ethernet connection Extreme care must be taken while connecting Ethernet wire to the block board since low quality...
  • Page 17 For 18 AWG, the maximum cable distance is (150m) 500 ft. ; for 20 AWG, the maximum is 90m (300 ft.) ; for 22 AWG, the maximum is 60m (200 ft.) All controller output shall be open drain or 5 V +/- 5% IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 18 Data WIEGAND_OUT0 Green Clock WIEGAND_OUT1 White Data Clock In Data WIEGAND_IN0 Green / Red WIEGAND_GND Black / Red Data Clock Out Card present GPO0 Yellow (Legacy Morpho Mode) IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 19 If door contact is not used, GPI1 (17) and GPO1 (18) shall be connected together Power supply from electrical source shall be switched off before starting the installation. IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 20  The internal relay is designed for 100.000 cycles. If more cycles are needed, an external relay driven by GPO must be used. IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 21 Software for Remote Administration and Enrollment Terminals are compatible with MorphoManager application, version 15.5 or higher IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 22 Language Settings: user interface language selection, Network Settings: LAN or WLAN parameters Password Settings: terminal administration password modification Boot assistant at next boot: Display this screen on next boot. IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 23 Configuration with a script hosted on a USB dongle not possible The default configuration is recommended by IDEMIA for operations. To use the features non available by default, the On-demand security state can be unlocked with MorphoBioToolBox. This shall not be done unless the end customer is made aware and an assessment on the system security is done.
  • Page 24 This Windows application can also be used for the full terminal configuration. Starting from version 16, MorphoManager can also configure the TLS communication of a terminal as soon as the latter has a valid IP address. IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 25 User specific access rules definition Optionnally, a contactless card can be created. MorphoWave Compact terminal allows you to capture up to 8 fingers per user. Please refer to the User enrollment section in the Administration Guide. “Local enrollment” shall not be used in a secure system, where it should be performed on an enrolment station (a PC with a dedicated application such as MorphoManager).
  • Page 26 Local Enrollment Process 2/2 NB: To complete enrollment, Allow to set the minimum of two waves are quality threshold required. Allow to change the current hand to enroll (left /right) IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 27 Place your hand between the cover and the optical sensor the front of the scanner Slide your hand from right to left or left to right Slightly spread apart your fingers IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 28 (left to right of the optical side of the scanner optical sensor or fingertip to sensor palm) IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 29 The PIN code is entered using a numeric keypad extract and type of card. displayed on the LCD touch screen. IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 30 Time and Attendance feature MorphoWave Compact terminals support an optional Time and Attendance (T&A) feature. For this, the terminal adds a specific T&A information to each identification or authentication record stored in the embedded event log database. This information is provided by the user through a specific screen displayed during identification or authentication process.
  • Page 31 Use dry air spray to remove the dust out of the sensor glass Firmware release  To get the best of our technology, we recommend you to download and install the last firmware release (please refer to last page) IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 32 Release note : for each firmware version, a release note is published describing the new features, the supported products, the potential known issues, the upgrade / downgrade limitations, the recommendations, the potential restrictions… IDEMIA - 2018_2000035854 – V5 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 33 Copyright © 2022, IDEMIA. All rights reserved. www.idemia.com Reproduction in whole or in part in any form or medium without the express written permission of IDEMIA is prohibited. The trademarks identified herein are the trademarks of registered trademarks of IDEMIA, or other third party.
