- Page 1 MTop Slim (V3) - Installation guide Product version Module version Mobile version Document version: V1.4...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION ................................. 3 RECOMMENDATIONS ............................... 3 General precautions ..............................3 Cleaning precautions ..............................3 Warning ..................................3 SAFETY INSTRUCTIONS ..............................4 Europe information ............................... 4 Caution ................................... 4 USA information ................................4 GENERAL DESCRIPTION ..............................5 Product version: ................................5 Module Version: ................................ -
Page 3: Introduction
INTRODUCTION We thank you for choosing a fingerprint acquisition terminal from IDEMIA. The MTop Slim provides an effective solution for the fingerprint acquisition of 4 fingers simultaneously, of two thumbs and of rolled fingers. Among a range of alternative biometric technologies, the use of fingerprints has significant advantages: each fingerprint constitutes an unalterable physical signature which develops before birth and preserves until death. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS This product is planned for being installed according to the EN IEC 62368-1:2020 + A11: 2020. The power supply is carried out by the standard USB link of the PC with a nominal voltage of 5V DC (as shown on the product label: 5V Europe information Hereby declares that the MTop Slim has been tested and found compliant with the following... -
Page 5: General Description
GENERAL DESCRIPTION Product version: Acquisition type indicators Acquisition Status indicators Orange means harder pression on related finger is requested Acquisition surface Roll acquisition surface 2 mounting holes for M3 screw USB trapdoor, to be able to change USB cable if necessary. Tightening torque of associated screws (*4): 0.2 Nm 5/13... -
Page 6: Module Version
Module Version: Micro USB2 connector Roll acquisition surface Mobile version The USB cable of the mobile version has a USB-C connector Roll acquisition surface 6/13... -
Page 7: Recommended Device Installation (Only For Product Version)
RECOMMENDED DEVICE INSTALLATION (ONLY FOR PRODUCT VERSION) Example of integration for ergonomic acquisitions To optimize the ergonomic of Thumb acquisition, it is advised to set up the product a bit over the table (and fixed on the table, thanks to the 2 mounting holes defined just before), as shown below or using a riser (part number 293775646) Example of integration for ergonomic acquisitions Drawing to drill the table:... - Page 8 Use two M3 screws to maintain the product to the table. Choose a screw length = table thickness + 3 to 5.5mm. Fix them gently without exceeding max force of 0.9 Nm, and with M3 washers (1,1 mm thickness +/-0,1 mm) between the terminal and the support 8/13...
-
Page 9: Example Of An Integration With Product Surface Protection
Example of an integration with product surface protection Transparent protective element Product Figure 1: example of integration into a kiosk 9/13... -
Page 10: Technical Characteristics
TECHNICAL CHARACTERISTICS Product version Device Configuration MTOP Slim R: Slap and roll Finger Print scanner, at 500 ppi IQS Appendix F certified, with VERIF license Part Number The MTOP Slim R is identified by a part number 293764669 – “MTOP Slim R V3 (x1)” Man Machine Interface Two-colored LEDs &... -
Page 11: Mobile Version
Mobile version Device Configuration MTOP Slim mobile: Slap and roll Finger Print scanner, at 500 ppi IQS Appendix F certified, with VERIF license Part Number The MTOP Slim module is identified by a part number 293790445- “MTOP Slim Mobile PR (emballé)”... -
Page 12: Operating Conditions
Operating conditions Operating Temperature: -10°C to +50°C. Relative Humidity:10%<RH<80%. Storage -40°C to +70°C. RH < 90%. Light We recommend the MTop Slim installation within controlled lighting conditions (300-1500 Lux). Avoid direct exposure of sensor to sunlight or intensive UV lights. Both may degrade the performances of the sensor on a long time period (even when device not powered). -
Page 13: Support
APAC (Asia & Pacific) Email : support.bioterminals.in@idemia.com Phone : +91 8929 159 665 India Email : support.bioterminals.in@idemia.com Phone: +91 1800 120 203 020 For security features queries Report all security features related queries at psirt@idemia.com Copyright ©2023 IDEMIA www.idemia.com 13/13...
