MorphoWave Compact
Quick User Guide
2018_2000035854 – V1
All descriptions, illustrations, and specifications in this brochure should be
considered approximate and may relate to optional equipment or feature
IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED

Advertisement

Table of Contents
loading

Related Manuals for Idemia MorphoWave Compact

Summary of Contents for Idemia MorphoWave Compact

  • Page 1 MorphoWave Compact Quick User Guide 2018_2000035854 – V1 All descriptions, illustrations, and specifications in this brochure should be considered approximate and may relate to optional equipment or feature IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 2 Table of Contents Color Step Content Overview Wiring Three Communication Four SDAC (Single Door Access Control) Five Administration Software Seven Enrollment Eight Optional features IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 3 Power Ground. Note that all connections of the MorphoWave Compact terminal described hereafter are of SELV (Safety Electrical Low Voltage) type. This symbol means do not dispose of your product with your other household waste. Instead, you should protect human health and the environment by handing over your waste equipment to a designated collection point for the recycling of waste electrical and electronic equipment.
  • Page 4 Contactless card reader (MIFARE Classic, MIFARE Plus, DESFire, HID® Iclass*, HID® PROX*) Intercom system Optional Wifi Universal connectivity (Gigabit Ethernet, Wi-Fi interface RS485/422, Wiegand, Dataclock) Anti-tamper sensor * Depending on product version IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 5 MorphoWave Compact terminal Wall Mounting Plate Documentation package ® ® ® ® Electronic documentation is provided in Adobe Acrobat format (PDF). Adobe Acrobat Reader is available at http://www.adobe.com. IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 6 Terminal Implementation To secure an access, IDEMIA recommends installing the MorphoWave Compact terminal as a part of a typical Access Control system, which consists of the components described below. The MorphoWave Compact terminal Its role is to process the access request from the user. It performs access right checks using one-to-many biometric identification or one-to-one biometric verification, and/or RF card authentication, and/or PIN check.
  • Page 7 Note: One user must be enrolled in the terminal database, in order to be able to perform biometric check. IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 8 Identifier on the keypad, or a Wiegand frame is received from an external device stored on the contactless card or in the user record in the terminal’s local database (**) IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 9 General precautions Do not expose the terminal to extreme temperatures. When the environment is very dry, avoid synthetic carpeting near the MorphoWave Compact terminal, to reduce the risk of unwanted electrostatic discharge. Areas containing combustibles Do not install the terminal in the vicinity of gas stations or any other installation containing flammable or combustible gases or materials.
  • Page 10 Backup of the Date/Time of the terminal: the volatile settings (such as date/time) of the terminal are protected against power failure, by a dedicated component during a least 24 hours (at 25 C) without external power supply. IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 11 If sharing power between devices, each unit must receive 2.5 A (e.g. two units would require a 12 VDC, 5 A supply). A battery backup or uninterrupted power supply (UPS) with built-in surge protection is recommended. IDEMIA recommends using a 24V power supply and AWG16 gauge Maximum distance (meters) Gauge Section cable.
  • Page 12 A maximum of 31 devices may be installed on the same line.  The maximum total cable length is 4000 ft. (1200m).  The cable must be dedicated to this installation and not used for any other purpose IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 13 Another conductor should be used for Signal Ground (Black / Red wire - 11). The maximum total cable length is 4000 ft. (1200m). The cable must be dedicated to this installation and not used for any other purpose IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 14 Use a category 6 shielding cable (120 Ohms) or better. It is strongly recommended station to insert a repeater unit every 90 m. Static mode is enabled by default on MorphoWave Compact terminals (factory setting) : IP=192.168.1.10, Gateway=192.168.1.254, Mask= 255.255.254.0 WLAN option...
  • Page 15 For 18 AWG, the maximum cable distance is 500 ft. (150m); for 20 AWG, the maximum is 300 ft. (90m); for 22 AWG, the maximum is 200 ft. (60m). All controller output shall be open drain or 5 V +/- 5% IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 16 Data WIEGAND_OUT0 Green Clock WIEGAND_OUT1 White Data Clock In Data WIEGAND_IN0 Green / Red WIEGAND_GND Black / Red Data Clock Out Card present GPO0 Yellow (Legacy Morpho Mode) IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 17 If door contact is not used, GPI1 (17) and GPO1 (18) shall be connected together Power supply from electrical source shall be switched off before starting the installation. IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 18  The internal relay is designed for 100.000 cycles. If more cycles are needed, an external relay driven by GPO must be used. IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 19 Language Settings: user interface language selection, Network Settings: LAN or WLAN parameters Password Settings: terminal administration password modification Boot assistant at next boot: Display this screen on next boot. IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 20 Terminal Restart security terminal For security reasons, it is highly recommended to change the devices default password to a custom password. USB key Information management about terminal IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 21 “Please Send Link for MBTB” in the subject of your e-mail. A link to download the software will be e-mailed to you. Other countries : please contact your sales representative. IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 22 Software for Terminal Remote Administration MorphoWave Compact Series terminals are fully compatible with: MorphoManager application (version 12 or higher) IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 23 User’s record expiry date User to include in white list or in VIP list User specific access rules definition MorphoWave Compact terminal allows you to capture up to 8 fingers per user. Note: Refer to User enrollment section in MorphoWave Compact Administration Guide.
  • Page 24 Local Enrollment Process 2/2 NB: To complete enrollment, two waves are required. IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 25 Slide your hand from right to left or left to right IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 26 5. Do not place 2 hands inside 6. Do not place your hand on the 13. Do not swipe your hand too fast cover IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 27 User ID), and starts the authentication The PIN code is entered using a numeric keypad process, as defined by the terminal settings. displayed on the LCD touch screen. IDEMIA - 2018_2000035854 – V1 IDEMIA DOCUMENT – REPRODUCTION AND DISCLOSURE PROHIBITED...
  • Page 28 Time and Attendance feature MorphoWave Compact Series terminals support an optional Time and Attendance (T&A) feature. For this, the terminal adds a specific T&A information to each identification or authentication record stored in the embedded event log database. This information is provided by the user through a specific screen displayed during identification or authentication process.
  • Page 29 Date / Time synchronization The MorphoWave Compact Series terminal clock has a +/- 10 ppm typical time deviation at +25°C (roughly +/- 1sec per day). At lower and higher temperature, deviation may be greater (maximum : 8 seconds per 48 hours).
  • Page 30 / downgrade limitations, the recommendations, the potential restrictions… North and South America: you may obtain these document by e-mailing support.bioterminals@idemia.com with your name, phone number, MorphoWave Compact serial number and “Send Links For MorphoWave Compact Documents” in the subject line.
  • Page 31 Copyright © 2018, IDEMIA. All rights reserved. www.idemia.com Reproduction in whole or in part in any form or medium without the express written permission of IDEMIA is prohibited. The trademarks identified herein are the trademarks of registered trademarks of IDEMIA, or other third party.
