Introduction 1.1 Content 1. Introduction 1.1 Content 1.2 Warning pictograms on the machine 1.3 Construction of the machine 1.4 Technical data 1.5 Safety arrangements of the heat press 1.6 Safety arrangements at the workplace 1.7 Environmental protection Initiation Notes regarding transportation Assembly of the heat press Power supply Initiation of the heat press...
Page 3
Warning pictograms on the machine Version 22.01 3 / 12...
Page 4
Construction of the machine Main switch Heat plate Elekctronic device Pressing arm Base plate with silicon foam Spiral hose Power supply cable Pressure force regulation Gas spring 150 N 10. Main fuse Technical data Outside dimensions :....……….....…...42 x 18 x 40 cm Working area: ..........……………….Ø...
Page 5
After receiving the machine, check the packaging. The testing should be protocoled. If any irregularities regarding functionality or safety are found during the testing, these has to be noted and reported to Walter Schulze GmbH in written form within 7 days.
Page 6
The press do not need a special assemble or additional fixing to the ground. Power supply The BluePRESSLine BALL press has to be connected to the installation 230VAC/50Hz. The device is equipped with a plug. Special attention should be paid to presence of the socket and presence of connected safety circuit inside.
Page 7
With the ECO mode you will save power. If the ECO mode 1, 2 or 3 is actived, the electronic devices will control the progress of work of the heat press. In case of a longer pause at the working procedure on the heat press, the ECO mode start automatically. The heat decreases and reduce the energy consumption.
Page 8
On the heat press are situated 4 points, which has to bee greased every 200 hours of working. After greasing lift and low the pressing arm slowly to spread the lubricant: On the bottom part of the pressing arm by the steel body of the machine (photo 1). At the point, where the pressing arm and the steel body are connected (photo 2).
Page 9
First turn off the heat press, remove the plug from the socket and wait, till the heat press gets cold. Unscrew the screw, which is connecting the heat plate with the press arm (zdjęcia 1-3). Put the heat plate on the base plate. (zdjęcie 4) unscrew the four screws, which are situated on the flat steel bar.
Page 10
Troubleshooting Problem Cause Debugging main fuse 6 A is defect Exchange main fuse 6 A Green switch blink, but: If main fuse is okay, than check Exchange electronic devices display doesn´t glow plate doesn´t heat thermal fuse on heatplate is defect Exchange thermal fuse heatpress doesn´t heat up to adjusted temperature even if the red diode glows...
Page 11
4.9 Warranty terms and conditions Schulze heat presses and machines used for screen printing have a warranty for 24 months. This warranty includes the whole construction of the machine, mechanical elements, electronic device and covers. Expandable parts, fuses and safety covers are not included in the warranty terms. Thermo fuses, temperature sensor, switches and buttons and all springs in the machines have a warranty for 6 months.
Page 12
CONFORMANCE DECLARATION nr BPLBALL/07/22/01 Manufacturer ROMANIK Andrzej Romanik ul. Przemysłowa 10 84 - 240 Reda, Poland hereby declares that the following machine: Heat press SCHULZE BluePRESSLine BALL is compliant with the specifications of the followings EC directives: Machinery (2006/42/EC) Low Voltage (2014/35/EU)
