Introduction Content 1. Introduction Content Warning pictograms on the machine Illustration of the press Technical data 1.5 Application range and sample adjustments of the heat press Optional equipment Replaceable heating plates Replaceable base plates Safety arrangements of the press 1.10 Safety arrangements at the workspace 1.11 Environmental protection 2.
Illustration of the press 1. Heating plate with safety frame 9. Rotation of the base plate 2. Spiral tube 10. Cooling plate (optional) 3. Emergency button 11. Base plate 4. Air filter with water separator 12. Cover plate 5. START/STOP motion detector 13.
Page 5
16. Control lamp 20. Cooling system (optional) 17. Pressure gauge 21. Compressed air hose 18. Pressure adjustment 22. Power supply cable 19. Cooling system switch 5 / 23 Version 22.02...
Before each work sequence it is needed to do tests for pressing transfers and to check the resistance on washing. Use cotton textiles, polyester or mixed textiles according to the specification of the foil. 1.6 Optional equipment The SCHULZE Air 4 Press can by optionally equipped with: 1. Cooling system 2.Screen print frame mounting 3.
For more details contact Walter Schulze. Safety arrangements of the press The SCHULZE Air 4 Press is equipped with different safety arrangements, to make a safe usage possible. Main fuse 16A The main fuse 16A is in the electrical box. In case of overload it protects the press from damage. If the fuse has been switched off, it must be switched on.
2.1 Notes regarding transportation For transportation, the SCHULZE Air 4 Press is attached to the pallet. The press is packed in a protective film. Immediately after receiving the press, check that the packaging is in good condition and the press is not damaged. If the machine will be sent back to another location at a later date, it should be placed in an identical way on the pallet.
Page 9
Installation of the base plates: Insert the base plate (pictures 1-2). Fix the plate with fastening screws (pictures 3-4). The heating plate must be installed in two people. Instruction for installation of the heating plate: Place the heating plate on the base plate (picture 1). Lift the heating plate by inserting it into the pin (picture 2).
2.4 Power supply voltage The SCHULZE Air 4 Press has to be connected to a voltage of 230 VAC / 50 Hz. The Press is equipped with a power plug. Make sure that the power outlet is in the right condition and that the grounding is connected to the power outlet.
3. Working with the heat press 3.1 Programming of the electronics After switching on the press, the display shows the currently set program parameters and the press warms up to the set temperature. By pressing the icon displaying the current temperature or press time, you enter the settings where you can change these values with "+" or "-"...
3.2 Transfer counter The SCHULZE Air 4 Press is equipped with a transfer counter. The display shows the number of transfers made (picture 1). By holding down the counter button you enter the counter settings. You can use the buttons (picture 2) to change the counter value or reset the counter (picture 3.3 Error reports...
3.5 Belt tension adjustment The SCHULZE Air 4 Press is equipped with a belt, the tension of which can be precisely adjusted. The tension is regulated by a knob under the base plate. The belt is tensioned by turning the knob to the right. By turning the knob to the left, the belt tension is released.
3.8 Safety frame In order to ensure optimum safety, the SCHULZE Air 4 Press is equipped with a safety frame (picture 1). This prevents burns and hand injury caused by the heating plate. When the safety frame is activated (during operation), the heating plate is automatically raised to the upper position (picture 2).
4), which must be unscrewed to set the desired frame height. 3.11 Instruction for hoof mounting (optional) In the SCHULZE Air Press 4, it is possible to install hooves. The hooves have a special cutout that allows for full application of the shirt on the baseplate.
If the press is not working after switching on, check the main fuse in the press. Activation of the main fuse can only be done by an authorized person, after agreeing the failure with the press supplier. The 16A fuse is located in the SCHULZE Air 4 Press electronic box (picture 1).
4.4 Instruction for replacement of the display The touch display is located on the control panel on the press arm. The display may only be replaced by an authorised person after the failure has been agreed with the press supplier. Before replacing the display, switch the press off, remove the plug from the socket and wait for the press to cool down.
4.6 Instruction for replacement of the thermal fuse The thermal fuse has to be replaced by an authorized person and after consulting and confirming the failure with the supplier. The thermal fuse is situated on the heat plate under the cover of the heat press in the left corner. The thermal fuse prevent over-burning of the heat plate, if the temperature gets over the save temperature limit.
Page 19
2. The heating plate is not connected 2. Connect the heat plate to the press The display shows Error temp 2 1. Short circuit on the temperature sensor 1. Replace the temperature sensor 2. Short-circuit on the temperature sensor 2. Replace the temperature sensor wires wires The display shows Error temp 3 1.
5.3 Warranty terms and conditions SCHULZE heat presses and machines used for screen printing have a warranty for 24 months. This warranty includes the whole construction of the machine, mechanical elements, electronic device and covers. Expandable parts, fuses and safety covers are not included in the warranty terms.
CONFORMANCE DECLARATION nr AIR4/05/22/01 Manufacturer ROMANIK Andrzej Romanik ul. Przemysłowa 10 84 - 240 Reda, Poland hereby declares that the following machine: Heat press SCHULZE Air 4 Press is compliant with the specifications of the followings EC directives: Machinery (2006/42/EC)
