Summary of Contents for Schulze BluePRESSLine Mug 4
- Page 1 Instruction manual Version 10.01 Heat press BluePRESSLine Mug 4 Version 10.01 1/11...
-
Page 2: Table Of Contents
1. Introduction 1.1 Content 1. Introduction 1.1 Content 1.2 Illustration of the heat press 1.3 Technical Data 1.4 Exchangeable heating element 1.5 Safety arrangements of the heat plate 1.6 Safety arrangements at the workspace 2. Initiation 2.1 Tips for transport 2.2 Installation of the heat press 2.3 Power supply 2.4 Initiation of the heat press... -
Page 3: Illustration Of The Heat Press
95 mm 1.5 Safety arrangements of the heat press The BluePRESSLine MUG 4 is equipped with different safety arrangements, to make a safe usage possible. Main fuse 10A The 10A fuse is located on the left side of the press. In Falleeiner congestion, protects the press from an injury. -
Page 4: Safety Arrangements At The Workspace
2.3 Power supply The BluePRESSLine MUG 4 has to be connected to a voltage of 230VAC/ 50Hz. The press is equipped with a plug. Make sure that the power outlet is in the right condition and that the grounding is connected to the power outlet. -
Page 5: Working With The Heat Press
If you want to check upp the adjusted time press the - button 3.2 Bugfixing of the electronic devices The electronic devices of the BluePRESSLine MUG 4 heat press control the main functions of the press. Here is a list of possible messages: ERR.1 –... -
Page 6: Apply A Transfer Film To A Cup
3.4 Apply a transfer film to a cup Insert the cup with the transfer film Press the cup into the heating Continue to press the cup down while into the press. element. closing the press with the lever. The press will heat up to the programmed temprature and the count the preset time down. -
Page 7: Exchange The Heating Band
3.6 Exchange the heating band Before you can change the heating band, switch off the heat press and pull out the plug. The heating band must be cool. Put the first press to the side (photo 1). Unscrew the cover (photo 1 and 2). Pull out the power (photo 3). Screw the fixation of the heating element (photo 4). -
Page 8: Maintenance
4. Maintenance 4.1 Maintenance If it is necessary you can grease the movable elements Before you can start greasing the heat press must be deactivated and cool. Pull out the plug. You can use a usual car grease. 4.2 Replacing the main fuse If the heat press do not work and the main switch is glowing, check the main fuse. -
Page 9: Troubleshooting
4.4 Troubleshooting Problem Cause Debugging main f use 10 A ist def ect Exchange main f use 10 A Grüner Schalter leuchtet aber: if the main f use is okay , than the electronic dev ices are def ect display doesn´t glow Exchange electronic dev ices heat plate doesn´t f uel Display shows Err 1,... -
Page 10: Connection Diagram
4.5 Connection diagram Version 10.01 10/11... -
Page 11: Testing Report
EN 292-1 EN 292-2 safety of machines EN 60204-1 electrical equipment of machines Berlin , .._____________________________ Peter Meidinger President All SCHULZE heat presses are exempt from the waste disposal law under reg. no. DE 231060054. Version 10.01 11/11...
