SEA TIOS Manual

Industrial sectional door operator

Advertisement

Quick Links

ENGLISH
International registered trademark n. 804888
TIOS
TIOS THREEPHASE
&
INDUSTRIAL SECTIONAL DOOR OPERATOR
SEA
S.p.A.
Zona Industriale Sant'Atto - 64100 - Teramo - ITALY
Telephone: + 39 0 861 588341
www.seateam.com
67411419
REV. 01 - 09/2024

Advertisement

loading
Need help?

Need help?

Do you have a question about the TIOS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SEA TIOS

  • Page 1 ENGLISH International registered trademark n. 804888 TIOS TIOS THREEPHASE & INDUSTRIAL SECTIONAL DOOR OPERATOR S.p.A. Zona Industriale Sant’Atto - 64100 - Teramo - ITALY Telephone: + 39 0 861 588341 www.seateam.com 67411419 REV. 01 - 09/2024...
  • Page 2 International registered trademark n. 804888 Technical specifications Made outside 1. TIOS models specifications TIOS (50 Nm) TIOS (50 Nm) TIOS (150 Nm) Threephase Model Threephase 230V ~ 50/60Hz 230V/400V 3 ~ 50/60Hz Power supply 230V ~ Motor 230V/400V 3 ~...
  • Page 3 International registered trademark n. 804888 Description 1. Components 1) Gear reducer 2) Limit switch device 3) AC motor 4) Manual lift device 5) Chain 6) Clutch Fig.2 2. Installation accessories Picture Name Size Quantity Mounting bracket Dowel Screw Washer Flat washer...
  • Page 4 International registered trademark n. 804888 Installation CAUTION: Before installing the operator, the door must be completely installed and balanced with the torsion spring 1. Standard installation 1) TIOS 2) Control unit box 3) Door 4) Rail 5) Bracket (with bearing inside)
  • Page 5 International registered trademark n. 804888 Fig.10 Fig.11 7) Insert the pin into the slot and tighten the screws 8) Installation completed on the bracket 3. Direct mounting on door shaft Fig.12 4. Mounting with adapter with 1:2 ratio Fig.13...
  • Page 6 International registered trademark n. 804888 Limit switch adjustment CAUTION: To adjust the limit switches, you must first observe the rotation direction of the cams, both in opening and closing, in order to turn them in the appropriate direction during adjustment 1.
  • Page 7 14. Transit through the leaves is allowed only when the gate is fully open. 15. The User must not attempt to repair or to take direct action on the system and must solely contact qualified SEA personnel or SEA service centers. The User can apply only the manual function of emergency.
  • Page 8 International registered trademark n. 804888 SEA S.p.A. Zona Industriale Sant’Atto - 64100 - Teramo - ITALY Tel. +39 0 861 588341 r.a. www.seateam.com...
