- Page 1 Document No. PAB-OM-N002-A PRODUCT NAME Process Pump MODEL / Series / Product Number ＰＢ１０１１Ａ ＰＢ１０１３Ａ...
- Page 2 Contents Safety Instructions ............................... 2 Model Indication and How to Order ......................... 4 Names and Functions of Product Parts ......................5 Piping and Operation ............................6 Working Principle ..............................7 Precautions ................................8 1．Caution on Design .............................. 8 2．Mounting ................................9 3．Piping ..................................
- Page 3 Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
- Page 4 Safety Instructions Caution We develop, design, and manufacture our products to be used for automatic control equipment, and provide them for peaceful use in manufacturing industries. Use in non-manufacturing industries is not covered. Products we manufacture and sell cannot be used for the purpose of transactions or certification specified in the Measurement Act.
- Page 5 Model Indication and How to Order...
- Page 6 Supplies air of set pressure. Connect the air piping. (AIR SUP) Air exhaust port Exhausts pilot air. (Only for PB1011A) (AIR EXH) Manual The pump operates one time per push. (Only for PB1011A) Lead wires of solenoid valve . Lead wires...
- Page 7 Piping and Operation Caution Be sure that the discharge port <FLUID OUT> is on top when the pump is mounted. Supply clean air that has passed through a filter or mist separator, etc., to the air supply port <AIR SUP>. Air that contains debris or drainage, etc., will have an adverse effect on the built-in solenoid valve, and will cause malfunction of the pump.
- Page 8 Due to this movement, the fluid on the suction port <FLUID IN> passes through the check valve and is sucked into the pump chamber. The PB1011A transfers the fluid continuously by suction and discharge in turn by repeating ON/OFF of the built-in solenoid valve. The PB1013A air-operated type is operated by the ON/OFF operation of an...
- Page 9 - When transferring a coagulable liquid, take measures to prevent it from coagulating in the pump. - Flammable fluid cannot be used with the process pump with built-in solenoid valve (PB1011A). Do not use in an environment where flammable fumes are present or where flammable liquid may get stuck to the product.
- Page 10 Take measures to ensure that water droplets from condensation are not splashed onto any electric parts or equipment. 12. PB1011A (Built-in solenoid valve) Refer to “Handling Precautions for SMC Products” (M-E03-3) for the usage of the solenoid valve. Caution 1.
- Page 11 ４．Air supply Warning 1. Use clean air. Do not use compressed air that includes chemicals, synthetic oils containing organic solvents, salinities or corrosive gases, etc., as it can cause damage or malfunction. 2. Pay attention to avoid freezing when operating the product in low temperatures. The equipment operates while expanding the compressed air.
- Page 12 ６．Maintenance Warning 1. Perform maintenance after consulting the operation manual. Obtain the operation manual for the equipment from SMC or our distributor and have sufficient knowledge of the equipment before performing maintenance. Incorrect handling may cause damage or malfunction of the equipment or system. 2.
- Page 13 Operating Diaphragm Model discharge numberof cycles inside pump Method material per cycle A in service life B (wetted part) Built-in solenoid PB1011A Approx. 30 million valve PTFE Approx. 9mL 0.004L cycles PB1013A Air operated ７．Lubrication Caution 1. The pump can be used without lubrication.
- Page 14 ８．Caution on Handling Warning 1. Test before using with the actual equipment. Test the pump before using it with the actual equipment. Even if there is no problem in a short-term test, the liquid may penetrate through the fluoropolymer diaphragm causing a malfunction in the pump air circuit.
- Page 15 6. Compatibility is indicated for fluid temperatures specified for the respective products (50℃ or less). Table symbols ○: Can be used. ×: Cannot be used. —: Can be used under certain conditions. Model PB1011A PB1013A Body material PP, SUS316...
- Page 16 Specifications Model PB1011A PB1013A Actuation Built-in solenoid valve Air operated Main fluid suction discharge port Rc, NPT, G 1/8” Female thread Port size Supply port Rc, NPT, G 1/8” Female thread Pilot air Exhaust port M5 x 0.8 female thread －...
- Page 17 Performance Curve Flow Rate Characteristics PB1011A Cycle (1 Hz) Cycle (5 Hz) Cycle (7 Hz) PB1013A Cycle (1 Hz) Cycle (5 Hz) Cycle (7 Hz) Selection from Flow Rate Characteristic Graph Required specification example: Find the pilot air pressure for a discharge rate of 600 mL/min and a discharge pressure of 0.15 MPa for builtin solenoid valve type.
- Page 18 Air Consumption Calculating Air Consumption Find the air consumption for operation with a 5 Hz switching cycle and pilot air pressure of 0.35 MPa from the air consumption graph. Selection procedures: 1. Look up from the 5 Hz switching cycle to find the intersection with SUP = 0.35 MPa. 2.
- Page 19 Viscosity Characteristics Selection from Viscosity Characteristic Graph Required specifications example: Find the pilot air pressure and pilot air consumption for a discharge rate of 270 mL/min, discharge pressure of 0.15 MPa, and a viscosity of 15 mPa·s. Selection procedures: 1. First, find the ratio of the amount of discharge against clear water when viscosity is 15 mPa·s from the graph to the left.
- Page 20 ● Basically, it is not recommended to disassemble the process pump. However, if this is necessary, be sure to follow the instructions in the maintenance procedure. ● When carrying out this work, wear appropriate protective equipment. Description PB1011A PB1013A Diaphragm kit KT-PB1A-9...
- Page 21 Dimensions Built-in Solenoid Valve PB1011A Air Operated PB1013A...
- Page 22 Troubleshooting If any abnormality is found, perform checks according to the following list Warning - Discharge dangerous fluid from the pump. - Do not return the pump with dangerous fluid left in it. If the product is to be returned, please refer to the 9.
- Page 23 Possible cause Remedy Phenomenon A lot of air bubbles come out - Air is sucked from the suction side - Prevent suction. from the discharge side (OUT (IN port). port). - Sealing failure of fitting at suction - Ensure sufficient sealing. side (IN port).
- Page 24 Revision history 2011-04-06 Initial release 2024-10-30 Rev. A Tel: + 81 3 5207 8249 Fax: +81 3 5298 5362 https://www.smcworld.com Note: Specifications are subject to change without prior notice and any obligation on the part of the manufacturer. © SMC Corporation All Rights Reserved...
