Safety Instructions These safety instructions are intended to prevent hazardous situations and/or equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for safety and must be followed in addition to International Standards (ISO/IEC) , and other safety regulations.
Page 4
Safety Instructions Caution 1.The product is provided for use in manufacturing industries. The product herein described is basically provided for peaceful use in manufacturing industries. If considering using the product in other industries, consult SMC beforehand and exchange specifications or a contract if necessary. If anything is unclear, contact your nearest sales branch.
Names and functions of parts Pilot air supply port: P1 Discharge port AIR SUP FLUID OUT Suction port Pilot air supply port: P2 FLUID IN AIR SUP Foot (Option) Description Functions Suction port (FLUID IN) Sucks the fluid to be transferred. Connect suction piping. Discharge port (FLUID Discharges the fluid taken in the pump.
Precautions 1. Caution on Design Warning 1. Confirm the specifications. - Give careful consideration to operating conditions such as the application, fluid and environment, and use the product within the operating ranges specified in this catalog. - The product is provided for physical, chemical and industrial equipment. 2.
Page 7
9. The pump cannot transfer gas. Do not allow it to idle for a long time. If the pump is operated for a long time without any fluid inside or in a gas-fluid mixed state, the diaphragm may be damaged or the life may be shortened. Do not continue idling for 3 minutes or longer.
Page 8
4. Air Supply Warning 1. Use clean air. Do not use compressed air that includes chemicals, synthetic oils containing organic solvents, salinities or corrosive gases, etc., as it can cause damage or malfunction. 2. Pay attention to avoid freezing when operating the product in low temperatures. The equipment operates while expanding the compressed air.
Page 9
3. Use appropriate protective equipment. When touching the process pump for maintenance, wear protective equipment such as gloves which are compatible with the fluid used. There is a risk of chemical burns. 4. Do not disassemble the product, as disassembly will invalidate the product's warranty.
Page 10
7. Caution on Handling Caution 1. Do not lubricate the air operated type. Warning 1. Test before using with the actual equipment. Test the pump before using it with the actual equipment. Even if there is no problem in a short-term test, the liquid may penetrate through the fluoropolymer diaphragm causing malfunction in the pump air circuit.
Applicable Fluids Material and Fluid Compatibility Check List for Process Pumps - The data below is prepared based on data provided by the material manufacturers. - SMC assumes no responsibility for the accuracy of the data or for any damages arising from the data.
Performance Curve 1) Flow Rate Characteristics Selection from Flow Rate Characteristic Graph (PA(P)3313) Required specification example: Find the pilot air pressure for a discharge rate of 6 L/min, a discharge pressure of 0.25 MPa, and a cycle of 4 Hz. <The transfer fluid is fresh water (viscosity 1 mPa·s, specific gravity 1.0).>...
Page 14
2) Air Consumption Calculating Air Consumption Required specifications example: Find the pilot air consumption for a discharge rate of 6 L/min, a cycle of 4 Hz and a pilot air pressure of 0.25 MPa. Selection procedures: 1. In the graph for air consumption (4 Hz), start at a discharge rate of 6 L/min. 2.
Page 15
3) Viscosity Characteristics (Flow rate correction for viscous fluids) Selection from Viscosity Characteristic Graph Required specification example: Find the pilot air pressure for a discharge rate of 2.7 L/min, discharge pressure of 0.25 MPa and a viscosity of 100 mPa·s. Selection procedures: 1.
Working Principle Air supply port (AIR SUP) 5 port solenoid valves Discharge port (FLUID OUT) Pump chamber A Pump chamber B Check valve Shaft Suction port (FLUID IN) Diaphragm A Diaphragm B Drive chamber A Drive chamber B 1. When air is supplied to P1 port, it enters drive chamber A. 2.
Piping and Operation Caution Maintain the proper tightening torque for fittings and mounting bolts, etc. Looseness can cause problems such as fluid and air leaks, while over tightening can cause damage to threads and parts, etc. Starting and Stopping Refer to circuit example Note 1) 1.
